WALL MUNI - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

6V4
WALL MUNI
PublicPUB

1 miles NW of WALL, SD
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
43° 59' 57"N 102° 15' 13"W
2813' MSL
3813' MSL
10E
None Listed
HURON (HON)
CHEYENNE
DENVER (ZDV)
5/16/24-6/13/24
KPHP (28nm) VFR
1:55 PM MDT
Light Rain
Broken 8,000'
Few 6,500'
10sm
54°F
42°F
29.93"Hg
020° 6kts
AO2 RAB33 SLP131 P0000 T01220056
KPHP 201955Z AUTO 02006KT 10SM -RA FEW065 BKN080 12/06 A2993 RMK AO2 RAB33 SLP131 P0000 T01220056
List Your Business

6V4 FBOs, Flight Schools and Ground Support

No FBOs, flight schools or aircraft ground support businesses are listed for this airport.

6V4 Ground Transportation (Taxi, Limo, Car Service)

No ground transportation services are listed for this airport.

6V4 Hotels

No hotels are listed for this airport.

6V4 Restaurants

No restaurants are listed for this airport.

6V4 Other Airport-Related Businesses

No other airport-related businesses are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.8 122.8

No communication frequencies available for this airport.

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

  • No Documents

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

  • No Documents

Terminal Area Forecast

KRAP (35nm)
Mon, 5/20 11:34 AM MDT
Mon, 5/20 12:00 PM MDT - Tue, 5/21 12:00 PM MDT
VFR
12:00 PM MDT - 5:00 PM MDT
Broken 12,000'
Scattered 6,000'
6sm
360° 13kts
MVFR
Temporary 1:00 PM MDT - 3:00 PM MDT
Light Showers and Rain and Mist
Overcast 2,000'
4sm
Calm
VFR
5:00 PM MDT - 10:00 PM MDT
Broken 3,500'
6sm
020° 9kts
MVFR
10:00 PM MDT - 9:00 AM MDT
Light Showers and Rain and Mist
Overcast 2,100'
4sm
VRB° 4kts
IFR
9:00 AM MDT - 12:00 PM MDT
Mist
Overcast 800'
3sm
350° 12kts
KRAP 201734Z 2018/2118 36013KT P6SM SCT060 BKN120
   TEMPO 2019/2021 4SM -SHRA BR OVC020
   FM202300 02009KT P6SM BKN035
   FM210400 VRB04KT 4SM -SHRA BR OVC021
   FM211500 35012KT 3SM BR OVC008
6V4
Domestic
5/3/241704Z !HON 05/005 6V4 RWY 12/30 CHANGED TO 4418FT X 75FT. DECLARED DIST: RWY 12 TORA 3756FT TODA 3756FT ASDA 4418FT LDA 3756FT. RWY 30 TORA 4418FT TODA 4418FT ASDA 4418FT LDA 3756FT. 2405031704-2408012359
4/16/240528Z !HON 04/092 6V4 OBST TOWER LGT (ASR 1219102) 435247.60N1015739.80W (14.5NM ESE 6V4) 2925.2FT (349.1FT AGL) U/S 2404160528-2405310515
2/7/242245Z !HON 02/019 6V4 SVC PCL RWY 12/30 REDL COMMISSIONED KEY FREQ 122.8 7
TIMES HIGH, 5 TIMES MEDIUM, 3 TIMES LOW INTST 2402072245-PERM
12/8/231700Z !HON 12/018 6V4 RWY 12/30 CHANGED TO RWY 13/31 2312081700-PERM
12/8/231700Z !HON 12/017 6V4 RWY 18/36 CLSD 2312081700-2408151600
No
UNATNDD
CITY OF WALL
PO BOX 314
WALL, SD 57790
Phone: 605-279-2663
CITY OF WALL
PO BOX 314
WALL, SD 57790
Phone: 605-279-2663
HURON FSS (HON)
Toll Free: 1-800-WX-BRIEF
HON
--
LIRL RWY 13/31 OPR DUSK-2200; AFT 2200 ACTVT CTAF.
N/A
Yes - Lighted
Yes
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
12
0
0
0
0
0
None
None
None
None
Crop Dusting

Runway 13/31

3499 ft. x 60 ft.
ASPH
Fair
NONE
LOW

12,000lbs
--
--
--
  Runway 13 Runway 31
True Heading 135°315°
Traffic Pattern Left Left
Markings BSC BSC
Markings Condition FAIR FAIR
Latitude 44° 00' 10"N 43° 59' 46"N
Longitude 102° 15' 33"W 102° 14' 60"W
Elevation 2,800' 2,812'
Threshold Crossing Height 29 ft. AGL 29 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P2L P2L
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway 18/36

1981 ft. x 100 ft.
TURF
Fair
NONE


--
--
--
--
  Runway 18 Runway 36
True Heading 191°11°
Traffic Pattern
Markings NONE NONE
Markings Condition
Latitude 44° 00' 05"N 43° 59' 46"N
Longitude 102° 15' 03"W 102° 15' 08"W
Elevation 2,804' 2,806'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1DEER, ANTELOPE & WATERFOWL ON & INVOF ARPT.
A110-2FOR CD CTC ELLSWORTH APCH AT 605-385-6198, WHEN APCH CLSD CTC DENVER ARTCC AT 303-651-4257.
WALL MUNI (IATA: 6V4) is a public airport located in WALL, SD.
