49B
STURGIS MUNI
PublicPUB

4 miles E of STURGIS, SD
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
44° 25' 07"N 103° 22' 40"W
3255' MSL
4255' MSL
11E
JET A, 100LL
HURON (HON)
CHEYENNE
DENVER (ZDV)
5/16/24-6/13/24
K49B VFR
11:35 PM MDT
Clear
10sm
70°F
46°F
29.90"Hg
Calm
AO2
K49B 130535Z AUTO 00000KT 10SM CLR 21/08 A2990 RMK AO2
Add Your Business

49B FBOs

Promote Listing
C & B Aviation
UNICOM: 122.8
Phone: (605) 347-3356
No Rating Available
0 Reviews (Read | Sign In To Write)
Independent
As of 6/11
 100LL JET A JET A (FSII) MOGAS UL94
Self Serve 6.04 5.22
Full Serve 6.00
Fuel Notes
Prices include tax
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.8 122.8

AWOS-3P

AWOS-3P
605-347-3356
 119.275

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

KRCA (19nm)
Wed, 6/12 9:00 PM MDT
Wed, 6/12 9:00 PM MDT - Fri, 6/14 3:00 AM MDT
VFR
9:00 PM MDT - 4:00 AM MDT
Few 12,000'
6sm
29.82"Hg
VRB° 6kts
VFR
Becoming 4:00 AM MDT - 11:00 AM MDT
Few 11,000'
6sm
29.88"Hg
350° 10kts
VFR
Becoming 11:00 AM MDT - 3:00 AM MDT
Sky Clear
6sm
29.91"Hg
VRB° 6kts
TAF KRCA 130300Z 1303/1409 VRB06KT 9999 FEW120 QNH2981INS
   BECMG 1310/1311 35010KT 9999 FEW110 QNH2987INS
   BECMG 1317/1318 VRB06KT 9999 SKC QNH2990INS TX28/1321Z TN15/1311Z
49B
Domestic
5/31/240848Z !HON 05/104 49B OBST WIND TURBINE LGT (ASN 2019-WTE-7142-OE) 444949N1031250W (25.7NM NNE 49B) 3454FT (315FT AGL) U/S 2405310848-2407150610
FDC
5/29/241132Z !FDC 4/0080 49B IAP STURGIS MUNI, STURGIS, SD.
RNAV (GPS) RWY 11, AMDT 1C...
DELETE NOTE: USE ELLSWORTH AFB ALTIMETER SETTING; WHEN NOT
RECEIVED, USE SPEARFISH ALTIMETER SETTING AND INCREASE ALL MDA 100
FEET, INCREASE LP CAT C VISIBILITY 3/8 SM AND LNAV CAT C VISIBILITY
1/4 SM.
CHANGE PBN REQUIREMENTS NOTE TO READ: RNP APCH - GPS.
ALTERNATE MINIMUMS: STANDARD.
THIS IS RNAV (GPS) RWY 11, AMDT 1D. 2405291132-PERM
5/29/241131Z !FDC 4/0079 49B IAP STURGIS MUNI, STURGIS, SD.
RNAV (GPS) RWY 29, AMDT 1C...
CHANGE PBN REQUIREMENTS NOTE TO READ: RNP APCH - GPS.
DELETE NOTE: USE ELLSWORTH AFB ALTIMETER SETTING, WHEN NOT
RECEIVED, USE SPEARFISH ALTIMETER SETTING AND INCREASE ALL DA 87
FEET AND ALL MDA 100 FEET AND INCREASE LPV CAT A/B VISIBILITY 1/4
MILE, AND LPV (WITH CLIMB GRADIENT) CAT C VISIBILITY 1/2 MILE.
CHANGE BARO-VNAV NOTE TO READ: FOR UNCOMPENSATED BARO-VNAV SYSTEMS,
LNAV/VNAV NA BELOW -21C OR ABOVE 54C.
ALTERNATE MINIMUMS: STANDARD EXCEPT CAT C 1100-3.
THIS IS RNAV (GPS) RWY 29, AMDT 1D. 2405291131-PERM
No
DALGT
FOR ATTENDANT OTR HRS CALL 605-347-3356.
CITY OF STURGIS
1040 SECOND ST STE. 103
STURGIS, SD 57785
Phone: 605-347-4422
ROGER BURNHAM
13345 ALKALI RD
STURGIS, SD 57785
Phone: 605-347-1050
HURON FSS (HON)
Toll Free: 1-800-WX-BRIEF
HON
--
ACTVT MIRL RWY 11/29; PAPI RWY 11 & 29 - CTAF.
N/A
Yes - Lighted
No
No
Hanger, Tie-Down
No
82
6
0
1
0
0
Major
Major
None
None
Crop Dusting
Pilot Instruction

Runway 05/23

3580 ft. x 120 ft.
TURF
Good
NONE


--
--
--
--
  Runway 05 Runway 23
True Heading 61°241°
Traffic Pattern
Markings
Markings Condition
Latitude 44° 25' 02"N 44° 25' 19"N
Longitude 103° 23' 13"W 103° 22' 30"W
Elevation 3,255' 3,225'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway 11/29

5100 ft. x 75 ft.
CONC
Excellent
NONE
MED

12,000lbs
--
--
--
  Runway 11 Runway 29
True Heading 123°303°
Traffic Pattern
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 44° 25' 18"N 44° 24' 51"N
Longitude 103° 23' 01"W 103° 22' 02"W
Elevation 3,244' 3,208'
Threshold Crossing Height 22 ft. AGL 29 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P2L P2L
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1WILDLIFE ON AND INVOF ARPT.
A110-2GCO AVBL ON FREQ 121.725 (4 CLICKS TO ELLSWORTH APPROACH AND 6 CLICKS TO DENVER CENTER)
A110-3FOR CD IF UNA VIA GCO CTC DENVER ARTCC AT 303-651-4257.
A110-4HIGH VOL OF ACFT OPRNG INVOF OF MT RUSHMORE AND CRAZY HORSE MONUMENTS AT OR BLW 7500 FT; PILOTS ARE ADVISED TO MNT 122.85 FOR TFC ADVISORIES.
STURGIS MUNI (IATA: 49B) is a public airport located in STURGIS, SD.
