CLARE COUNTY - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

80D
CLARE COUNTY
PublicPUB

2 miles NW of HARRISON, MI
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
44° 03' 08"N 84° 48' 47"W
1142' MSL
2142' MSL
05W
None Listed
LANSING (LAN)
LAKE HURON
MINNEAPOLIS (ZMP)
5/16/24-6/13/24
KHTL (19nm) VFR
11:53 PM EDT
Clear
10sm
53°F
50°F
30.19"Hg
290° 3kts
AO2 SLP222 T01170100
KHTL 010353Z AUTO 29003KT 10SM CLR 12/10 A3019 RMK AO2 SLP222 T01170100
Add Your Business

80D FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.8 122.8

No communication frequencies available for this airport.

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

  • No Documents

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

  • No Documents

Terminal Area Forecast

KMBS (45nm)
Fri, 5/31 7:29 PM EDT
Fri, 5/31 8:00 PM EDT - Sat, 6/1 8:00 PM EDT
VFR
8:00 PM EDT - 11:00 AM EDT
Few 25,000'
6sm
180° 5kts
VFR
11:00 AM EDT - 7:00 PM EDT
Broken 25,000'
6sm
170° 10kts
VFR
7:00 PM EDT - 8:00 PM EDT
Overcast 15,000'
6sm
200° 7kts
KMBS 312329Z 0100/0124 18005KT P6SM FEW250
   FM011500 17010KT P6SM BKN250
   FM012300 20007KT P6SM OVC150
80D
Domestic
5/27/240502Z !LAN 05/453 80D OBST TOWER LGT (ASR 1206444) 440648.20N0844821.00W (3.7NM NE 80D) 1507.9FT (297.9FT AGL) U/S 2405270502-2409240502
4/21/241740Z !LAN 04/347 80D OBST TOWER LGT (ASR 1059602) 435711.80N0844714.50W (6.1NM S 80D) 1372.7FT (300.9FT AGL) U/S 2404211740-2408191740
2/29/241744Z !LAN 02/432 80D RWY 05/23 CLSD 2402291744-2412312359
No
UNATNDD
COUNTY OF CLARE
PO BOX 438
HARRISON, MI 48625-0438
Phone: 989-539-2510
GALE GENE BENSINGER
4875 WILDWOOD DR
HARRISON, MI 48625-9650
Phone: 989-862-5333
LANSING FSS (LAN)
Toll Free: 1-800-WX-BRIEF
LAN
--
ACTVT NSTD LIRL - CTAF.
N/A
Yes
Yes
No
Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
8
0
0
0
0
0
None
None
None
None
None

Runway 05/23

3000 ft. x 100 ft.
TURF
Poor
NONE


--
--
--
--
  Runway 05 Runway 23
True Heading 48°228°
Traffic Pattern
Markings
Markings Condition
Latitude 44° 02' 58"N 44° 03' 18"N
Longitude 84° 49' 02"W 84° 48' 32"W
Elevation 1,139' 1,141'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway 09/27

2403 ft. x 100 ft.
TURF
Poor
NONE


--
--
--
--
  Runway 09 Runway 27
True Heading 93°273°
Traffic Pattern Left Left
Markings
Markings Condition
Latitude 44° 03' 17"N 44° 03' 16"N
Longitude 84° 49' 04"W 84° 48' 32"W
Elevation 1,142' 1,141'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway 18/36

2978 ft. x 50 ft.
ASPH
Poor
NONE
NSTD

--
--
--
--
  Runway 18 Runway 36
True Heading 181°1°
Traffic Pattern Left Left
Markings BSC BSC
Markings Condition GOOD GOOD
Latitude 44° 03' 16"N 44° 02' 47"N
Longitude 84° 48' 47"W 84° 48' 47"W
Elevation 1,141' 1,138'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights No No
Runway End Identifier Lights No No
A110-3DEER & LRG BIRDS ON & INVOF ARPT.
A110-5FOR CD CTC MINNEAPOLIS ARTCC AT 651-463-5588.
A110-6RWY 05 DTHR 1700 FT, EXTDS BYD RWY MIDPT.
CLARE COUNTY (IATA: 80D) is a public airport located in HARRISON, MI.
