JACUMBA - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

L78
JACUMBA
PublicPUB

1 miles E of JACUMBA, CA
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
32° 36' 57"N 116° 09' 56"W
2844' MSL
3844' MSL
13E
None Listed
SAN DIEGO (SAN)
LOS ANGELES
LOS ANGELES (ZLA)
5/16/24-6/13/24
KNJK (28nm) VFR
11:56 AM PDT
Clear
10sm
96°F
55°F
29.83"Hg
090° 7kts
AO2 SLP117 T03560128 $
KNJK 121856Z 09007KT 10SM CLR 36/13 A2983 RMK AO2 SLP117 T03560128 $
Add Your Business

L78 FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
-- 122.9

No communication frequencies available for this airport.

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

  • No Documents

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

  • No Documents

Terminal Area Forecast

KNJK (28nm)
Wed, 6/12 7:58 AM PDT
Wed, 6/12 8:00 AM PDT - Thu, 6/13 8:00 AM PDT
VFR
8:00 AM PDT - 4:00 PM PDT
Sky Clear
6sm
29.70"Hg
150° 5kts
VFR
4:00 PM PDT - 10:00 PM PDT
No Clouds
6sm
29.70"Hg
250° 15kts
Gusts 25kts
Moderate, Clear Air, Occasional: 39,000 - 5,000'
VFR
10:00 PM PDT - 8:00 AM PDT
No Clouds
6sm
29.73"Hg
320° 9kts
Moderate, Clear Air, Occasional: 39,000 - 9,000'
TAF KNJK 1215/1315 15005KT 9999 SKC QNH2971INS
   FM122300 25015G25KT 9999 520005 QNH2969INS
   FM130500 32009KT 9999 520009 QNH2974INS TX43/1223Z TN25/1313Z FS30130
L78
Domestic
5/8/241735Z !SAN 05/032 L78 OBST TOWER LGT (ASN 2010-AWP-386-OE) 323752N1160915W (1.1NM NNE L78) 3075FT (170FT AGL) U/S 2405081735-2408082359
5/8/241734Z !SAN 05/031 L78 OBST TOWER LGT (ASN 2010-AWP-392-OE) 323752N1161102W (1.3NM NW L78) 3180FT (146FT AGL) U/S 2405081734-2408082359
5/8/241733Z !SAN 05/030 L78 OBST TOWER LGT (ASN 2013-AWP-5749-OE) 323748N1160839W (1.4NM NE L78) 3169FT (134FT AGL) U/S 2405081733-2408082359
5/8/241730Z !SAN 05/028 L78 OBST TOWER LGT (ASN 2010-AWP-383-OE) 323752N1160829W (1.5NM NE L78) 3228FT (167FT AGL) U/S 2405081730-2408082359
No
UNATNDD
COUNTY OF SAN DIEGO
1960 JOE CROSSON DRIVE
EL CAJON, CA 92020-1142
Phone: 619-956-4800
MEADOW CHASE
SAN DIEGO COUNTY AIRPORTS, CROSSON DRIVE
EL CAJON, CA 92020
Phone: 760-788-3366
SAN DIEGO FSS (SAN)
Toll Free: 1-800-WX-BRIEF
SAN
--
--
N/A
Yes
Yes
No
Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
None
None
None
None
Glider Towing

Runway 07/25

2562 ft. x 60 ft.
ASPH
Good
NONE


12,000lbs
--
--
--
  Runway 07 Runway 25
True Heading 83°263°
Traffic Pattern Left Right
Markings BSC BSC
Markings Condition GOOD GOOD
Latitude 32° 36' 56"N 32° 36' 59"N
Longitude 116° 10' 11"W 116° 09' 41"W
Elevation -- --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights No No
Runway End Identifier Lights No No
A110-10ALL ACFT AVOID OVERFLIGHT US/MEXICAN BDR WO AUTH.
A110-11NOISE ABATEMENT; AVOID OVERFLYING RESIDENTIAL COMMUNITY 1/2 MI W.
A110-12RCMD RWY TO RAMP TRSN, ASPH TO SOFT DIRT, AT TWY STUB MIDFIELD, ALL OTHER AREAS ASPH TO GRVL.
A110-13HEL SKID/RUN-ON LDG AND AUTO-ROTATIONS PROHIBITED.
A110-14RDO EQUIPPPED ACFT SHALL SELF-ANNC ON CTAF PRIOR TO LDG OR TKOF.
A110-15PN TO OBTAIN VEHICLE ACES TO AP, CALL 619-956-4800.
A110-16PPR ALL MIL ACFT CTC AMGR.
A110-17FOR CD CTC LOS ANGELES ARTCC AT 661-575-2079.
A110-4WIND PMTG, RCMD LAND RWY 07 AND DEPART RWY 25 DUE TO 480 FT HILL 1 MI E OF AP.
A110-6FRQ GLD ACT DRG WKENDS, PWRD ACFT BE ALERT FOR GLD TFC LAUNCHING FRM FLD AND OPERG ON AND IN VCNTY OF AP, SFC TO 18000 FT MSL.
A110-7RAPIDLY RISING TRRN ALL QUADS.
A110-8OCNL WILDLIFE ON AND IN VCNTY OF AP.
A110-9CONTIGUOUS ADIZ IN VCNTY AND ALONG INTL BDRY, LCTD APRXLY 615 FT S OF RWY 07-25.
JACUMBA (IATA: L78) is a public airport located in JACUMBA, CA.
