1I3
SHAWNEE FLD
PublicPUB

3 miles W of BLOOMFIELD, IN
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
39° 02' 34"N 87° 00' 10"W
501' MSL
1501' MSL
01W
None Listed
TERRE HAUTE (HUF)
ST LOUIS
INDIANAPOLIS (ZID)
11/28/24-12/26/24
KBMG (19nm) VFR
6:53 AM EST
Broken 5,500'
10sm
28°F
17°F
30.27"Hg
140° 10kts
AO2 SLP258 T10221083 11017 21028 56012
KBMG 231153Z 14010KT 10SM BKN055 M02/M08 A3027 RMK AO2 SLP258 T10221083 11017 21028 56012
Add Your Business

1I3 FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
-- 122.9

No communication frequencies available for this airport.

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

  • No Documents

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

  • No Documents

Terminal Area Forecast

KBMG (19nm)
Mon, 12/23 6:20 AM EST
Mon, 12/23 7:00 AM EST - Tue, 12/24 7:00 AM EST
VFR
7:00 AM EST - 12:00 PM EST
Scattered 15,000'
6sm
160° 7kts
VFR
12:00 PM EST - 11:00 PM EST
Broken 4,000'
6sm
200° 10kts
Gusts 20kts
VFR
3:00 PM EST - 7:00 PM EST
Light Rain
No Clouds
N/A
Calm
MVFR
11:00 PM EST - 4:00 AM EST
Overcast 1,000'
6sm
220° 8kts
IFR
4:00 AM EST - 7:00 AM EST
Mist
Overcast 700'
1sm
200° 3kts
KBMG 231120Z 2312/2412 16007KT P6SM SCT150
   FM231700 20010G20KT P6SM BKN040
   PROB30 2320/2324 -RA
   FM240400 22008KT P6SM OVC010
   FM240900 20003KT 1SM BR OVC007
1I3
Domestic
12/22/240501Z !HUF 12/608 1I3 OBST TOWER LGT (ASN 2022-AGL-17466-OE) 385743N0870660W (7.2NM SW 1I3) 747FT (265FT AGL) U/S 2412220501-2502050501
12/20/240516Z !HUF 12/537 1I3 OBST TOWER LGT (ASN 2024-AGL-9035-OE) 390219N0870259W (2.2NM W 1I3) 814FT (305FT AGL) U/S 2412200516-2502030515
12/10/241011Z !HUF 12/279 1I3 OBST TOWER LGT (ASR 1270288) 390240.50N0870256.60W (2.2NM W 1I3) 851.0FT (306.1FT AGL) U/S 2412101011-2504091011
11/21/242332Z !HUF 11/376 1I3 OBST TOWER LGT (ASN 2024-AGL-4613-OE) 390728N0865829W (5.1NM NNE 1I3) 828FT (310FT AGL) U/S 2411212332-2501052331
11/19/242212Z !HUF 11/328 1I3 OBST TOWER LGT (ASR 1030267) 391305.00N0865558.00W (11.1NM NNE 1I3) 963.9FT (255.9FT AGL) U/S 2411192212-2412312359
No
UNATTENDED
FOR ARPT ATTNDT CALL 812-384-6232.
SHAWNEE FIELD INC.
3416 W STATE ROAD 54
BLOOMFIELD, IN 47424
Phone: (812) 384-6232
MELINDA HARVEY
3416 W STATE ROAD 54
BLOOMFIELD, IN 47424
Phone: 812-829-5999
TERRE HAUTE FSS (HUF)
Toll Free: 1-800-WX-BRIEF
HUF
Sunset to Sunrise
--
N/A
Yes - Lighted
No
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
Minor
Minor
None
None
None

Runway 18/36

2160 ft. x 150 ft.
TURF
Good
NONE
NSTD

--
--
--
--
  Runway 18 Runway 36
True Heading 180°360°
Traffic Pattern Left
Markings NONE NONE
Markings Condition
Latitude 39° 02' 44"N 39° 02' 23"N
Longitude 87° 00' 10"W 87° 00' 10"W
Elevation 500' 500'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1370'ANTENNA TWR 1 MI NW.
A110-4RY 18/36 HAS A -4 FT SLOPE ON EAST SIDE; NORTH OF RY 18 THR.
A110-5BIRDS ON & INVOF RY.
A110-6ULTRA LGTS ON & INVOF ARPT.
A110-7FOR CD CTC HULMAN APCH AT 812-877-7581.
SHAWNEE FLD (IATA: 1I3) is a public airport located in BLOOMFIELD, IN.
