!FDC 3/4403 20V PART 1 OF 3 ODP MC ELROY AIRFIELD, KREMMLING, CO.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1...
TAKE-OFF MINIMUMS RWY 09, 2600-2 OR STANDARD WITH MINIMUM CLIMB OF
385 FEET PER NM TO 12700.
IN ADDITION TO TAKEOFF OBSTACLE NOTES: ADD: TERRAIN, LIGHT POLES
BEGINNING 16 FT FROM DER, 77 FT LEFT OF CENTERLINE, UP TO 7419 FT
MSL. TRAVERSE WAY, TREE, VEGETATION, TERRAIN BEGINNING 62 FT FROM
DER, 48 FT LEFT OF CENTERLINE, UP TO 7437 FT MSL. VEGETATION 167 FT
FROM DER, 36 FT RIGHT OF CENTERLINE, 7420 FT MSL. TRAVERSE WAY
BEGINNING 286 FT FROM DER, 396 FT LEFT OF CENTERLINE, UP TO 7438 FT
MSL. TRAVERSE WAY 738 FT FROM DER, 371 FT LEFT OF CENTERLINE, 7439
FT MSL. TRAVERSE WAY BEGINNING 852 FT FROM DER, 341 FT LEFT OF
CENTERLINE, UP TO 7440 FT MSL. TRAVERSE WAY BEGINNING 965 FT FROM
DER, 319 FT LEFT OF CENTERLINE, UP TO 7442 FT MSL. TRAVERSE WAY
1076 FT FROM DER, 299 FT LEFT OF CENTERLINE, 7443 FT MSL. TERRAIN
1165 FT FROM DER, 774 FT LEFT OF CENTERLINE, 7445 FT MSL. TERRAIN
1387 FT FROM DER, 857 FT LEFT OF CENTERLINE, 7452 FT MSL. TERRAIN
1490 FT FROM DER, 881 FT LEFT OF CENTERLINE, 7457 FT MSL. TERRAIN
1598 FT FROM DER, 797 FT LEFT OF CENTERLINE, 7458 FT MSL. TERRAIN
BEGINNING 1607 FT FROM DER, 710 FT LEFT OF CENTERLINE, UP TO 7463
FT MSL. TERRAIN 1677 FT FROM DER, 796 FT LEFT OF CENTERLINE, 7465
ALL OTHER DATA REMAINS AS PUBLISHED. 2306011743-2506011743EST
END PART 1 OF 3
!FDC 3/4403 20V PART 2 OF 3 ODP MC ELROY AIRFIELD, KREMMLING, CO.
FT MSL. TERRAIN BEGINNING 1775 FT FROM DER, 797 FT LEFT OF
CENTERLINE, UP TO 7478 FT MSL. TERRAIN BEGINNING 1798 FT FROM DER,
562 FT LEFT OF CENTERLINE, UP TO 7483 FT MSL. TERRAIN BEGINNING
1901 FT FROM DER, 720 FT LEFT OF CENTERLINE, UP TO 7493 FT MSL.
TERRAIN BEGINNING 1995 FT FROM DER, 580 FT LEFT OF CENTERLINE, UP
TO 7499 FT MSL. TERRAIN, TRAVERSE WAY BEGINNING 2119 FT FROM DER,
363 FT LEFT OF CENTERLINE, UP TO 7503 FT MSL. TERRAIN, TRAVERSE WAY
BEGINNING 2198 FT FROM DER, 474 FT LEFT OF CENTERLINE, UP TO 7512
FT MSL. TRAVERSE WAY 2264 FT FROM DER, 882 FT LEFT OF CENTERLINE,
7522 FT MSL. POLE, TRANSMISSION LINE, TRAVERSE WAY, TERRAIN,
ELECTRICAL SYSTEM, VEGETATION BEGINNING 2300 FT FROM DER, 326 FT
LEFT OF CENTERLINE, UP TO 7547 FT MSL. TERRAIN BEGINNING 2572 FT
FROM DER, 390 FT RIGHT OF CENTERLINE, UP TO 7482 FT MSL. TERRAIN,
VEGETATION BEGINNING 2618 FT FROM DER, 905 FT LEFT OF CENTERLINE,
UP TO 7549 FT MSL. POLE 2660 FT FROM DER, 436 FT RIGHT OF
CENTERLINE, 13 FT AGL/7505 FT MSL. TERRAIN 4399 FT FROM DER, 1399
FT LEFT OF CENTERLINE, 7558 FT MSL. TERRAIN BEGINNING 4404 FT FROM
DER, 1398 FT LEFT OF CENTERLINE, UP TO 7626 FT MSL. TREE 4621 FT
FROM DER, 1736 FT RIGHT OF CENTERLINE, 7538 FT MSL. TREE 5016 FT
FROM DER, 1793 FT RIGHT OF CENTERLINE, 7549 FT MSL. TREE, TERRAIN
ALL OTHER DATA REMAINS AS PUBLISHED. 2306011743-2506011743EST
END PART 2 OF 3
!FDC 3/4403 20V PART 3 OF 3 ODP MC ELROY AIRFIELD, KREMMLING, CO.
BEGINNING 5482 FT FROM DER, 1922 FT RIGHT OF CENTERLINE, UP TO 7564
FT MSL. ADD: RWY 27: TRAVERSE WAY, BUILDING BEGINNING 37 FT FROM
DER, 393 FT LEFT OF CENTERLINE, UP TO 7415 FT MSL. FENCE 97 FT FROM
DER, 388 FT RIGHT OF CENTERLINE, 8 FT AGL/7405 FT MSL. TREE,
TRAVERSE WAY, POLE BEGINNING 148 FT FROM DER, 1 FT LEFT OF
CENTERLINE, UP TO 40 FT AGL/7439 FT MSL. POLE, TRAVERSE WAY, TREE
BEGINNING 309 FT FROM DER, 74 FT RIGHT OF CENTERLINE, UP TO 30 FT
AGL/7428 FT MSL. TREE, TRANSMISSION LINE, POLE BEGINNING 742 FT
FROM DER, 25 FT RIGHT OF CENTERLINE, UP TO 48 FT AGL/7446 FT MSL.
TREES BEGINNING 1714 FT FROM DER, 219 FT RIGHT OF CENTERLINE, UP TO
55 FT AGL/7450 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2306011743-2506011743EST
