| Domestic |
|
3/4/251941Z
|
!SJT 03/107 23R OBST TOWER LGT (ASR 1304672) 290423.22N0985851.79W (4.4NM SSW 23R) 957FT (330FT AGL) U/S 2503041941-2504181941
|
|
2/25/252035Z
|
!SJT 02/329 23R OBST TOWER LGT (ASR 1235422) 290646.00N0991020.50W (12.3NM W 23R) 1111.9FT (338.9FT AGL) U/S 2502252035-2505260500
|
|
2/25/250632Z
|
!SJT 02/314 23R OBST TOWER LGT (ASR 1211158) 290312.60N0990124.90W (6.7NM SW 23R) 1009.8FT (256.9FT AGL) U/S 2502250632-2503120532
|
|
9/18/241311Z
|
!SJT 09/214 23R NAV HHH NDB U/S 2409181311-2503182111EST
|
| FDC |
|
7/3/241456Z
|
!FDC 4/7072 23R PART 1 OF 2 ODP DEVINE MUNI, DEVINE, TX.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1...
TAKEOFF OBSTACLE NOTES: RWY 17: TERRAIN 21 FT FROM DER, 312 FT
RIGHT OF CENTERLINE, 705 FT MSL.
TERRAIN 48 FT FROM DER, 472 FT RIGHT OF CENTERLINE, 708 FT MSL.
TREE, TERRAIN BEGINNING 141 FT FROM DER, 338 FT RIGHT OF
CENTERLINE, UP TO 41 FT AGL/746 FT MSL.
TREES BEGINNING 148 FT FROM DER, 379 FT LEFT OF CENTERLINE, UP TO
59 FT AGL/752 FT MSL.
TREES BEGINNING 419 FT FROM DER, 490 FT RIGHT OF CENTERLINE, UP TO
752 FT MSL.
TREES BEGINNING 1197 FT FROM DER, 352 FT LEFT OF CENTERLINE, UP TO
756 FT MSL.
TREE 1333 FT FROM DER, 122 FT LEFT OF CENTERLINE, 759 FT MSL.
TREE 1334 FT FROM DER, 295 FT LEFT OF CENTERLINE, 762 FT MSL.
TREES BEGINNING 1431 FT FROM DER, 20 FT LEFT OF CENTERLINE, UP TO
45 FT AGL/765 FT MSL.
TREE 1605 FT FROM DER, 131 FT RIGHT OF CENTERLINE, 765 FT MSL.
TREES BEGINNING 1698 FT FROM DER, 8 FT RIGHT OF CENTERLINE, UP TO
49 FT AGL/775 FT MSL..
RWY 35: TERRAIN 26 FT FROM DER, 187 FT LEFT OF CENTERLINE, 675 FT
ALL OTHER DATA REMAINS AS PUBLISHED. 2407031456-2607031456EST
END PART 1 OF 2
!FDC 4/7072 23R PART 2 OF 2 ODP DEVINE MUNI, DEVINE, TX.
MSL.
POLE, TERRAIN, FENCE, TREE BEGINNING 93 FT FROM DER, 335 FT LEFT OF
CENTERLINE, UP TO 40 FT AGL/723 FT MSL.
TREE 222 FT FROM DER, 540 FT RIGHT OF CENTERLINE, 720 FT MSL.
TREE, POLE BEGINNING 323 FT FROM DER, 350 FT RIGHT OF CENTERLINE,
UP TO 725 FT MSL.
TREES BEGINNING 1126 FT FROM DER, 427 FT LEFT OF CENTERLINE, UP TO
732 FT MSL.
TREE 4982 FT FROM DER, 192 FT RIGHT OF CENTERLINE, 839 FT MSL.
TREE 5166 FT FROM DER, 275 FT RIGHT OF CENTERLINE, 829 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2407031456-2607031456EST
END PART 2 OF 2
|
