2/16/241001Z
|
!FDC 4/6155 2I0 PART 1 OF 3 ODP MADISONVILLE RGNL,
MADISONVILLE, KY.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
TAKEOFF OBSTACLE NOTES: RWY 5, VEGETATION 52 FT FROM DER, 272 FT
RIGHT OF CENTERLINE, 422 FT MSL.
TERRAINS BEGINNING 65 FT FROM DER, 269 FT LEFT OF CENTERLINE, UP TO
421 FT MSL.
TERRAINS BEGINNING 170 FT FROM DER, 271 FT LEFT OF CENTERLINE, UP
TO 426 FT MSL.
TERRAIN 261 FT FROM DER, 439 FT LEFT OF CENTERLINE, 427 FT MSL.
TERRAINS BEGINNING 312 FT FROM DER, 439 FT LEFT OF CENTERLINE, UP
TO 432 FT MSL.
TERRAINS BEGINNING 461 FT FROM DER, 441 FT LEFT OF CENTERLINE, UP
TO 434 FT MSL.
TERRAINS BEGINNING 611 FT FROM DER, 503 FT LEFT OF CENTERLINE, UP
TO 438 FT MSL.
TERRAINS BEGINNING 727 FT FROM DER, 393 FT LEFT OF CENTERLINE, UP
TO 439 FT MSL.
TREE 940 FT FROM DER, 622 FT LEFT OF CENTERLINE, 442 FT MSL.
TREE 1081 FT FROM DER, 584 FT LEFT OF CENTERLINE, 456 FT MSL.
TREE 1232 FT FROM DER, 719 FT LEFT OF CENTERLINE, 469 FT MSL.
TREE 2302 FT FROM DER, 910 FT LEFT OF CENTERLINE, 492 FT MSL.
OTHER DATA REMAINS AS PUBLISHED. 2402161001-2602161001EST
END PART 1 OF 3
!FDC 4/6155 2I0 PART 2 OF 3 ODP MADISONVILLE RGNL,
MADISONVILLE, KY.
RWY 23, TERRAINS BEGINNING 17 FT FROM DER, 293 FT RIGHT OF
CENTERLINE, UP TO 468 FT MSL.
TERRAIN 69 FT FROM DER, 352 FT LEFT OF CENTERLINE, 442 FT MSL.
TREE, TERRAIN BEGINNING 110 FT FROM DER, 289 FT LEFT OF CENTERLINE,
UP TO 451 FT MSL.
TREE 223 FT FROM DER, 492 FT LEFT OF CENTERLINE, 453 FT MSL.
TREE 370 FT FROM DER, 497 FT LEFT OF CENTERLINE, 461 FT MSL.
TREE 392 FT FROM DER, 497 FT LEFT OF CENTERLINE, 464 FT MSL.
POLE, TERRAINS BEGINNING 450 FT FROM DER, 430 FT RIGHT OF
CENTERLINE, UP TO 28 FT AGL/475 FT MSL.
TREES, TERRAINS, POLE, BUILDING BEGINNING 609 FT FROM DER, 320 FT
RIGHT OF CENTERLINE, UP TO 61 FT AGL/532 FT MSL.
TREE, TERRAIN BEGINNING 845 FT FROM DER, 515 FT RIGHT OF
CENTERLINE, UP TO 537 FT MSL.
TREES, TERRAINS, TRANSMISSION LINES, POLES, TRAVERSE WAY BEGINNING
897 FT FROM DER, 119 FT RIGHT OF CENTERLINE, UP TO 65 FT AGL/538 FT
MSL.
POLE 962 FT FROM DER, 753 FT LEFT OF CENTERLINE, 470 FT MSL.
BUILDING, POLES, TRANSMISSION LINES BEGINNING 968 FT FROM DER, 503
FT LEFT OF CENTERLINE, UP TO 35 FT AGL/475 FT MSL.
OTHER DATA REMAINS AS PUBLISHED. 2402161001-2602161001EST
END PART 2 OF 3
!FDC 4/6155 2I0 PART 3 OF 3 ODP MADISONVILLE RGNL,
MADISONVILLE, KY.
TREE 1189 FT FROM DER, 447 FT LEFT OF CENTERLINE, 495 FT MSL.
TREES, POLE BEGINNING 1203 FT FROM DER, 21 FT LEFT OF CENTERLINE,
UP TO 504 FT MSL.
TREE 2919 FT FROM DER, 1098 FT LEFT OF CENTERLINE, 512 FT MSL. ALL
OTHER DATA REMAINS AS PUBLISHED. 2402161001-2602161001EST
END PART 3 OF 3
|
