8/9/232055Z
|
!FDC 3/1389 2K4 PART 1 OF 3 ODP SCOTT FLD, MANGUM, OK. TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG... CHANGE TAKEOFF OBSTACLE NOTES TO READ: NOTE: RWY 17: BUILDING, TRAVERSE WAY BEGINNING 14 FT FROM DER, 425 FT LEFT OF CENTERLINE, UP TO 18 FT AGL/1656 FT MSL. TREE, FENCE, TERRAIN BEGINNING 166 FT FROM DER, 297 FT RIGHT OF CENTERLINE, UP TO 1656 FT MSL. TRAVERSE WAY 286 FT FROM DER, 426 FT LEFT OF CENTERLINE, 1659 FT MSL. TRAVERSE WAY 362 FT FROM DER, 525 FT LEFT OF CENTERLINE, 1660 FT MSL. TRAVERSE WAY 460 FT FROM DER, 495 FT LEFT OF CENTERLINE, 1662 FT MSL. TRAVERSE WAY 464 FT FROM DER, 525 FT RIGHT OF CENTERLINE, 1667 FT MSL. POLES, TRAVERSE WAYS, TREES, VEGETATION BEGINNING 477 FT FROM DER, 75 FT RIGHT OF CENTERLINE, UP TO 29 FT AGL/1680 FT MSL. POLE, TREES, TRAVERSE WAY, VEGETATION BEGINNING 477 FT FROM DER, 46 FT LEFT OF CENTERLINE, UP TO 1673 FT MSL. POLE, BUILDING, VEGETATION, TRAVERSE WAY BEGINNING 645 FT FROM DER, 3 FT LEFT OF CENTERLINE, UP TO 1679 FT MSL. UP TO 1798 FT MSL. 2308092055-2508092054EST END PART 1 OF 3 !FDC 3/1389 2K4 PART 2 OF 3 ODP SCOTT FLD, MANGUM, OK. POLES, VEGETATION, TRAVERSE WAYS BEGINNING 889 FT FROM DER, 45 FT LEFT OF CENTERLINE, UP TO 1681 FT MSL. TRAVERSE WAY 1036 FT FROM DER, 374 FT RIGHT OF CENTERLINE, 1681 FT MSL. POLE, TRAVERSE WAYS, TREE BEGINNING 1103 FT FROM DER, 112 FT RIGHT OF CENTERLINE, UP TO 1688 FT MSL. TRAVERSE WAY 1202 FT FROM DER, 224 FT LEFT OF CENTERLINE, 1683 FT MSL. TRAVERSE WAY 1216 FT FROM DER, 11 FT LEFT OF CENTERLINE, 1684 FT MSL. TRAVERSE WAY 1217 FT FROM DER, 123 FT LEFT OF CENTERLINE, 1685 FT MSL. POLE 1336 FT FROM DER, 409 FT LEFT OF CENTERLINE, 1689 FT MSL. POLE 1343 FT FROM DER, 190 FT LEFT OF CENTERLINE, 30 FT AGL/1693 FT MSL. POLE 1350 FT FROM DER, 39 FT RIGHT OF CENTERLINE, 1690 FT MSL. POLE 1359 FT FROM DER, 260 FT RIGHT OF CENTERLINE, 1697 FT MSL. POLE 1361 FT FROM DER, 485 FT RIGHT OF CENTERLINE, 28 FT AGL/1698 FT MSL. TERRAIN BEGINNING 4921 FT FROM DER, 1775 FT RIGHT OF CENTERLINE, UP UP TO 1798 FT MSL. 2308092055-2508092054EST END PART 2 OF 3 !FDC 3/1389 2K4 PART 3 OF 3 ODP SCOTT FLD, MANGUM, OK. TO 1772 FT MSL. NOTE: RWY 35: TERRAIN BEGINNING 15 FT FROM DER, 142 FT LEFT OF CENTERLINE, UP TO 1802 FT MSL. FENCE 46 FT FROM DER, 297 FT LEFT OF CENTERLINE, 4 FT AGL/1625 FT MSL. TERRAIN BEGINNING 4535 FT FROM DER, 1701 FT RIGHT OF CENTERLINE, UP TO 1798 FT MSL. 2308092055-2508092054EST END PART 3 OF 3
|
