6/27/241854Z
|
!FDC 4/4838 2M2 PART 1 OF 4 ODP LAWRENCEBURG-LAWRENCE COUNTY,
LAWRENCEBURG, TN.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
TAKEOFF OBSTACLES NOTES: RWY 17: TREES BEGINNING 17 FT FROM DER,
483 FT RIGHT OF CENTERLINE, UP TO 1003 FT MSL.
TREE, BUILDING, TRAVERSE WAY, POLE BEGINNING 140 FT FROM DER, 60 FT
RIGHT OF CENTERLINE, UP TO 1014 FT MSL.
FENCE 150 FT FROM DER, 525 FT LEFT OF CENTERLINE, 7 FT AGL/932 FT
MSL.
TREE, TRAVERSE WAY BEGINNING 349 FT FROM DER, 471 FT LEFT OF
CENTERLINE, UP TO 943 FT MSL.
TREE 400 FT FROM DER, 589 FT LEFT OF CENTERLINE, 954 FT MSL.
TREES BEGINNING 439 FT FROM DER, 503 FT LEFT OF CENTERLINE, UP TO
965 FT MSL.
TREE 929 FT FROM DER, 586 FT LEFT OF CENTERLINE, 966 FT MSL.
TREE 1041 FT FROM DER, 656 FT LEFT OF CENTERLINE, 974 FT MSL.
TREE 1066 FT FROM DER, 580 FT LEFT OF CENTERLINE, 981 FT MSL.
TREES BEGINNING 1070 FT FROM DER, 210 FT LEFT OF CENTERLINE, UP TO
984 FT MSL.
TREE, TANK BEGINNING 1180 FT FROM DER, 82 FT LEFT OF CENTERLINE, UP
TO 1024 FT MSL.
TREES BEGINNING 2180 FT FROM DER, 244 FT RIGHT OF CENTERLINE, UP TO
ALL OTHER DATA REMAINS AS PUBLISHED. 2406271854-2606261854EST
END PART 1 OF 4
!FDC 4/4838 2M2 PART 2 OF 4 ODP LAWRENCEBURG-LAWRENCE COUNTY,
LAWRENCEBURG, TN.
1016 FT MSL.
TREES BEGINNING 2380 FT FROM DER, 230 FT RIGHT OF CENTERLINE, UP TO
1017 FT MSL.
TREE 2448 FT FROM DER, 1042 FT LEFT OF CENTERLINE, 1026 FT MSL.
TREES BEGINNING 2486 FT FROM DER, 111 FT RIGHT OF CENTERLINE, UP TO
1022 FT MSL.
TREES BEGINNING 2505 FT FROM DER, 659 FT LEFT OF CENTERLINE, UP TO
1029 FT MSL.
TREES BEGINNING 2533 FT FROM DER, 1 FT RIGHT OF CENTERLINE, UP TO
1023 FT MSL.
TREE 2581 FT FROM DER, 825 FT RIGHT OF CENTERLINE, 1029 FT MSL.
TREES BEGINNING 2613 FT FROM DER, 212 FT RIGHT OF CENTERLINE, UP TO
1032 FT MSL.
TREES BEGINNING 2678 FT FROM DER, 568 FT LEFT OF CENTERLINE, UP TO
1034 FT MSL.
TREE 2794 FT FROM DER, 1007 FT LEFT OF CENTERLINE, 1040 FT MSL.
TREES BEGINNING 2805 FT FROM DER, 8 FT LEFT OF CENTERLINE, UP TO
1043 FT MSL.
TREES BEGINNING 2817 FT FROM DER, 413 FT RIGHT OF CENTERLINE, UP TO
1035 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2406271854-2606261854EST
END PART 2 OF 4
!FDC 4/4838 2M2 PART 3 OF 4 ODP LAWRENCEBURG-LAWRENCE COUNTY,
LAWRENCEBURG, TN.
TREES BEGINNING 2829 FT FROM DER, 27 FT RIGHT OF CENTERLINE, UP TO
1039 FT MSL.
TREES BEGINNING 3082 FT FROM DER, 156 FT RIGHT OF CENTERLINE, UP TO
1041 FT MSL.
TREES BEGINNING 3455 FT FROM DER, 114 FT RIGHT OF CENTERLINE, UP TO
1047 FT MSL.
TREES BEGINNING 3968 FT FROM DER, 122 FT RIGHT OF CENTERLINE, UP TO
1051 FT MSL.
BUILDING 4887 FT FROM DER, 1283 FT LEFT OF CENTERLINE, 1051 FT MSL.
TREE 5132 FT FROM DER, 1530 FT RIGHT OF CENTERLINE, 1062 FT MSL.
TREES BEGINNING 5182 FT FROM DER, 1425 FT RIGHT OF CENTERLINE, UP
TO 1067 FT MSL.
TREE 5272 FT FROM DER, 1479 FT RIGHT OF CENTERLINE, 1072 FT MSL.
TREES BEGINNING 5371 FT FROM DER, 1334 FT RIGHT OF CENTERLINE, UP
TO 1077 FT MSL RWY 35: TREE, BUILDING, POLE, TRANSMISSION LINE
BEGINNING 10 FT FROM DER, 61 FT LEFT OF CENTERLINE, UP TO 1031 FT
MSL. TREE 13 FT FROM DER, 293 FT RIGHT OF CENTERLINE, 940 FT MSL.
TREES BEGINNING 984 FT FROM DER, 673 FT RIGHT OF CENTERLINE, UP TO
1010 FT MSL.
TREE, POLE, TRANSMISSION LINE BEGINNING 1261 FT FROM DER, 4 FT
ALL OTHER DATA REMAINS AS PUBLISHED. 2406271854-2606261854EST
END PART 3 OF 4
!FDC 4/4838 2M2 PART 4 OF 4 ODP LAWRENCEBURG-LAWRENCE COUNTY,
LAWRENCEBURG, TN.
RIGHT OF CENTERLINE, UP TO 1028 FT MSL.
TREES BEGINNING 3193 FT FROM DER, 468 FT RIGHT OF CENTERLINE, UP TO
1046 FT MSL.
TREES BEGINNING 3257 FT FROM DER, 426 FT RIGHT OF CENTERLINE, UP TO
1048 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2406271854-2606261854EST
END PART 4 OF 4
|
