!FDC 3/2398 3JC PART 1 OF 6 ODP FREEMAN FLD, JUNCTION CITY, KS.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 2A...
TAKEOFF OBSTACLE NOTES:
NOTE: RWY 18: TREES BEGINNING 76 FT FROM DER, 461 FT RIGHT OF
CENTERLINE, UP TO 51 FT AGL/1153 FT MSL.
TREE 194 FT FROM DER, 494 FT LEFT OF CENTERLINE, 40 FT AGL/1139 FT
MSL.
TREES BEGINNING 197 FT FROM DER, 518 FT LEFT OF CENTERLINE, UP TO
38 FT AGL/1140 FT MSL.
TREE 251 FT FROM DER, 558 FT RIGHT OF CENTERLINE, 67 FT AGL/1171 FT
MSL.
TREE 274 FT FROM DER, 515 FT LEFT OF CENTERLINE, 46 FT AGL/1146 FT
MSL.
TREES, POLES, BUILDINGS BEGINNING 399 FT FROM DER, 5 FT RIGHT OF
CENTERLINE, UP TO 68 FT AGL/1173 FT MSL.
TREES BEGINNING 459 FT FROM DER, 432 FT LEFT OF CENTERLINE, UP TO
55 FT AGL/1156 FT MSL.
TREES, BUILDINGS, POLES BEGINNING 611 FT FROM DER, 372 FT LEFT OF
CENTERLINE, UP TO 56 FT AGL/1158 FT MSL.
TREE, POLE BEGINNING 903 FT FROM DER, 278 FT LEFT OF CENTERLINE, UP
TO 63 FT AGL/1164 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2305261520-2505261518EST
END PART 1 OF 6
!FDC 3/2398 3JC PART 2 OF 6 ODP FREEMAN FLD, JUNCTION CITY, KS.
POLES, TREES, BUILDINGS BEGINNING 908 FT FROM DER, 12 FT LEFT OF
CENTERLINE, UP TO 75 FT AGL/1175 FT MSL.
TREES, POLES BEGINNING 1304 FT FROM DER, 43 FT RIGHT OF CENTERLINE,
UP TO 65 FT AGL/1175 FT MSL.
TREES, POLES BEGINNING 1462 FT FROM DER, 33 FT RIGHT OF CENTERLINE,
UP TO 69 FT AGL/1179 FT MSL.
TREES, POLES BEGINNING 1983 FT FROM DER, 61 FT LEFT OF CENTERLINE,
UP TO 68 FT AGL/1176 FT MSL.
TREES, POLES BEGINNING 1988 FT FROM DER, 6 FT RIGHT OF CENTERLINE,
UP TO 72 FT AGL/1184 FT MSL.
TREES, POLE BEGINNING 2369 FT FROM DER, ON CENTERLINE, UP TO 82 FT
AGL/1199 FT MSL.
TREE 2398 FT FROM DER, 626 FT LEFT OF CENTERLINE, 66 FT AGL/1179 FT
MSL.
TREES BEGINNING 2438 FT FROM DER, 129 FT LEFT OF CENTERLINE, UP TO
67 FT AGL/1182 FT MSL.
TREES BEGINNING 2674 FT FROM DER, 266 FT LEFT OF CENTERLINE, UP TO
68 FT AGL/1183 FT MSL.
TREES BEGINNING 2769 FT FROM DER, 324 FT LEFT OF CENTERLINE, UP TO
71 FT AGL/1185 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2305261520-2505261518EST
END PART 2 OF 6
!FDC 3/2398 3JC PART 3 OF 6 ODP FREEMAN FLD, JUNCTION CITY, KS.
POLES, TREES BEGINNING 2807 FT FROM DER, 25 FT RIGHT OF CENTERLINE,
UP TO 82 FT AGL/1204 FT MSL.
TREE 3063 FT FROM DER, 1201 FT LEFT OF CENTERLINE, 67 FT AGL/1186
FT MSL.
TREES BEGINNING 3076 FT FROM DER, 42 FT LEFT OF CENTERLINE, UP TO
71 FT AGL/1192 FT MSL.
TREES BEGINNING 3356 FT FROM DER, 138 FT LEFT OF CENTERLINE, UP TO
72 FT AGL/1194 FT MSL.
TREES BEGINNING 3505 FT FROM DER, 843 FT RIGHT OF CENTERLINE, UP TO
65 FT AGL/1214 FT MSL.
TREE 3593 FT FROM DER, 267 FT LEFT OF CENTERLINE, 73 FT AGL/1200 FT
MSL.
TREES, POLE BEGINNING 3633 FT FROM DER, 1157 FT RIGHT OF
CENTERLINE, UP TO 62 FT AGL/1218 FT MSL.
TREES, POLES, BUILDING, BUILDING SPIRE, TERRAIN, TRAVERSE WAY
BEGINNING 3707 FT FROM DER, 168 FT RIGHT OF CENTERLINE, UP TO 73 FT
AGL/1237 FT MSL.
POLE 4105 FT FROM DER, 1375 FT RIGHT OF CENTERLINE, 26 FT AGL/1238
FT MSL.
TREE 4116 FT FROM DER, 1135 FT RIGHT OF CENTERLINE, 68 FT AGL/1258
ALL OTHER DATA REMAINS AS PUBLISHED. 2305261520-2505261518EST
END PART 3 OF 6
!FDC 3/2398 3JC PART 4 OF 6 ODP FREEMAN FLD, JUNCTION CITY, KS.
FT MSL.
TREES, TRAVERSE WAYS, POLES, TERRAIN BEGINNING 4123 FT FROM DER,
457 FT RIGHT OF CENTERLINE, UP TO 49 FT AGL/1259 FT MSL.
TREES, TERRAIN, POLES, TRAVERSE WAY BEGINNING 4349 FT FROM DER, 352
FT RIGHT OF CENTERLINE, UP TO 68 FT AGL/1292 FT MSL.
TREES, TERRAIN, POLES, BUILDINGS, TRAVERSE WAYS BEGINNING 4516 FT
FROM DER, 344 FT RIGHT OF CENTERLINE, UP TO 63 FT AGL/1298 FT MSL.
TREE, BUILDING, TERRAIN, POLE, TRAVERSE WAY BEGINNING 4634 FT FROM
DER, 527 FT RIGHT OF CENTERLINE, UP TO 61 FT AGL/1301 FT MSL.
TREES, POLES, TERRAIN, BUILDINGS, TRAVERSE WAYS BEGINNING 4682 FT
FROM DER, 97 FT RIGHT OF CENTERLINE, UP TO 68 FT AGL/1303 FT MSL.
TREE 5160 FT FROM DER, 3 FT LEFT OF CENTERLINE, 47 FT AGL/1232 FT
MSL.
TREE 5585 FT FROM DER, 1318 FT LEFT OF CENTERLINE, 72 FT AGL/1248
FT MSL.
TREE 5631 FT FROM DER, 1756 FT LEFT OF CENTERLINE, 73 FT AGL/1250
FT MSL.
TREES BEGINNING 5662 FT FROM DER, 1232 FT LEFT OF CENTERLINE, UP TO
77 FT AGL/1256 FT MSL.
TREE, BUILDING BEGINNING 5821 FT FROM DER, 887 FT LEFT OF
ALL OTHER DATA REMAINS AS PUBLISHED. 2305261520-2505261518EST
END PART 4 OF 6
!FDC 3/2398 3JC PART 5 OF 6 ODP FREEMAN FLD, JUNCTION CITY, KS.
CENTERLINE, UP TO 58 FT AGL/1263 FT MSL.
TREES BEGINNING 5904 FT FROM DER, 787 FT LEFT OF CENTERLINE, UP TO
73 FT AGL/1273 FT MSL.
TREES, POLE BEGINNING 5967 FT FROM DER, 947 FT LEFT OF CENTERLINE,
UP TO 52 FT AGL/1275 FT MSL.
TREES, POLE BEGINNING 6030 FT FROM DER, 877 FT LEFT OF CENTERLINE,
UP TO 60 FT AGL/1276 FT MSL.
TREES, POLES, BUILDINGS TANKS, TOWERS, TRANSMISSION LINE BEGINNING
1 NM FROM DER, 724 FT LEFT AND RIGHT OF CENTERLINE, UP TO 75 FT
AGL/1428 FT MSL.
NOTE: RWY 36: TRAVERSE WAYS BEGINNING 1 FT FROM DER, 312 FT RIGHT
OF CENTERLINE, UP TO 1097 FT MSL.
TREES, FENCES, SIGN, TRAVERSE WAYS, POLES BEGINNING 5 FT FROM DER,
96 FT RIGHT OF CENTERLINE, UP TO 33 FT AGL/1113 FT MSL.
FENCE 35 FT FROM DER, 253 FT LEFT OF CENTERLINE, 6 FT AGL/1089 FT
MSL.
POLES, FENCE, TRAVERSE WAYS, BUILDINGS, TREES, SIGN BEGINNING 42 FT
FROM DER, 36 FT LEFT OF CENTERLINE, UP TO 30 FT AGL/1113 FT MSL.
TREE 2025 FT FROM DER, 565 FT LEFT OF CENTERLINE, 80 FT AGL/1146 FT
MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2305261520-2505261518EST
END PART 5 OF 6
!FDC 3/2398 3JC PART 6 OF 6 ODP FREEMAN FLD, JUNCTION CITY, KS.
TREE 2233 FT FROM DER, 444 FT LEFT OF CENTERLINE, 82 FT AGL/1147 FT
MSL.
TREE 2766 FT FROM DER, 198 FT LEFT OF CENTERLINE, 106 FT AGL/1171
FT MSL.
TREES BEGINNING 3022 FT FROM DER, 53 FT RIGHT OF CENTERLINE, UP TO
115 FT AGL/1183 FT MSL.
TERRAIN BEGINNING 2.1 NM FROM DER, 4029 FT RIGHT OF CENTERLINE, UP
TO 1500 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2305261520-2505261518EST
END PART 6 OF 6
|
