3/11/241609Z
|
!FDC 4/5707 45R PART 1 OF 4 ODP HAWTHORNE FLD,
KOUNTZE/SILSBEE, TX.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
TAKEOFF OBSTACLE NOTES: RWY 13, TREE 26 FT FROM DER, 442 FT LEFT
OF CENTERLINE, 110 FT MSL.
TREES BEGINNING 43 FT FROM DER, 360 FT LEFT OF CENTERLINE, UP TO
127 FT MSL.
TREES BEGINNING 43 FT FROM DER, 167 FT RIGHT OF CENTERLINE, UP TO
133 FT MSL.
TREES BEGINNING 1041 FT FROM DER, 85 FT LEFT OF CENTERLINE, UP TO
131 FT MSL.
TREE 1608 FT FROM DER, 12 FT LEFT OF CENTERLINE, 134 FT MSL.
TREE 1641 FT FROM DER, 193 FT LEFT OF CENTERLINE, 136 FT MSL.
TREES BEGINNING 1674 FT FROM DER, 191 FT LEFT OF CENTERLINE, UP TO
138 FT MSL.
TREES BEGINNING 1683 FT FROM DER, ON CENTERLINE, UP TO 136 FT MSL.
TREES BEGINNING 1711 FT FROM DER, 39 FT LEFT OF CENTERLINE, UP TO
139 FT MSL.
TREES BEGINNING 1787 FT FROM DER, 37 FT RIGHT OF CENTERLINE, UP TO
147 FT MSL.
TREES BEGINNING 2083 FT FROM DER, 90 FT RIGHT OF CENTERLINE, UP TO
149 FT MSL.
2403111609-2603111609EST
END PART 1 OF 4
!FDC 4/5707 45R PART 2 OF 4 ODP HAWTHORNE FLD,
KOUNTZE/SILSBEE, TX.
TREES BEGINNING 2258 FT FROM DER, 555 FT LEFT OF CENTERLINE, UP TO
178 FT MSL.
TREES BEGINNING 2387 FT FROM DER, 397 FT LEFT OF CENTERLINE, UP TO
182 FT MSL.
TREES BEGINNING 2549 FT FROM DER, 64 FT LEFT OF CENTERLINE, UP TO
183 FT MSL.
TREES BEGINNING 2582 FT FROM DER, 46 FT RIGHT OF CENTERLINE, UP TO
151 FT MSL.
RWY 31, TREES BEGINNING 183 FT FROM DER, 334 FT RIGHT OF
CENTERLINE, UP TO 126 FT MSL.
TREES BEGINNING 379 FT FROM DER, 295 FT RIGHT OF CENTERLINE, UP TO
130 FT MSL.
TREES BEGINNING 403 FT FROM DER, 19 FT LEFT OF CENTERLINE, UP TO 97
FT MSL.
TREES BEGINNING 421 FT FROM DER, 151 FT RIGHT OF CENTERLINE, UP TO
133 FT MSL.
TREE, POLE BEGINNING 514 FT FROM DER, 42 FT RIGHT OF CENTERLINE, UP
TO 136 FT MSL.
TREES BEGINNING 634 FT FROM DER, 58 FT LEFT OF CENTERLINE, UP TO
112 FT MSL.
2403111609-2603111609EST
END PART 2 OF 4
!FDC 4/5707 45R PART 3 OF 4 ODP HAWTHORNE FLD,
KOUNTZE/SILSBEE, TX.
TREES BEGINNING 736 FT FROM DER, 200 FT LEFT OF CENTERLINE, UP TO
114 FT MSL.
TREES BEGINNING 766 FT FROM DER, 17 FT LEFT OF CENTERLINE, UP TO
116 FT MSL.
TREES BEGINNING 886 FT FROM DER, 331 FT LEFT OF CENTERLINE, UP TO
123 FT MSL.
TREES BEGINNING 968 FT FROM DER, 453 FT LEFT OF CENTERLINE, UP TO
137 FT MSL.
TREE 1049 FT FROM DER, 454 FT LEFT OF CENTERLINE, 139 FT MSL.
TREES BEGINNING 1103 FT FROM DER, 283 FT LEFT OF CENTERLINE, UP TO
149 FT MSL.
TREES BEGINNING 1338 FT FROM DER, 21 FT RIGHT OF CENTERLINE, UP TO
146 FT MSL.
TREE 1432 FT FROM DER, 364 FT LEFT OF CENTERLINE, 151 FT MSL.
TREE 1435 FT FROM DER, 455 FT LEFT OF CENTERLINE, 159 FT MSL.
TREES BEGINNING 1486 FT FROM DER, 90 FT LEFT OF CENTERLINE, UP TO
162 FT MSL.
TREES BEGINNING 2047 FT FROM DER, 5 FT RIGHT OF CENTERLINE, UP TO
158 FT MSL.
TREES BEGINNING 3169 FT FROM DER, 926 FT LEFT OF CENTERLINE, UP TO
2403111609-2603111609EST
END PART 3 OF 4
!FDC 4/5707 45R PART 4 OF 4 ODP HAWTHORNE FLD,
KOUNTZE/SILSBEE, TX.
167 FT MSL.
TREES BEGINNING 3246 FT FROM DER, 1024 FT RIGHT OF CENTERLINE, UP
TO 181 FT MSL. ALL OTHER DATA REMAINS AS PUBLISHED.
2403111609-2603111609EST
END PART 4 OF 4
|
