| Domestic |
|
2/23/251550Z
|
!GFK 02/200 4V4 OBST TOWER LGT (ASR 1046474) 474030.00N0971911.00W (11.3NM ESE 4V4) 1220.1FT (220.1FT AGL) U/S 2502231550-2506232359
|
| FDC |
|
11/21/231605Z
|
!FDC 3/4477 4V4 PART 1 OF 2 ODP NORTHWOOD MUNI/VINCE FLD,
NORTHWOOD, ND.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
RWY 8, LIGHT POLES 10 FT FROM DER, 10 FT LEFT OF CENTERLINE, 2 FT
AGL/1119 FT MSL.
LIGHT POLES 10 FT FROM DER, 10 FT RIGHT OF CENTERLINE, 2 FT
AGL/1119 FT MSL.
TRAVERSE WAY 148 FT FROM DER, 493 FT RIGHT OF CENTERLINE, 8 FT
AGL/1124 FT MSL.
RWY 26, LIGHT POLES 12 FT FROM DER, 9 FT RIGHT OF CENTERLINE, 2 FT
AGL/1119 FT MSL.
LIGHT POLES 13 FT FROM DER, 10 FT LEFT OF CENTERLINE, 2 FT AGL/1119
FT MSL.
TREE 1338 FT FROM DER, 14 FT LEFT OF CENTERLINE, 1156 FT MSL.
TREE 1359 FT FROM DER, 157 FT LEFT OF CENTERLINE, 1160 FT MSL.
TREES BEGINNING 1425 FT FROM DER, 119 FT RIGHT OF CENTERLINE, UP TO
1168 FT MSL.
TREES BEGINNING 1571 FT FROM DER, 107 FT RIGHT OF CENTERLINE, UP TO
1173 FT MSL.
TREES BEGINNING 1651 FT FROM DER, 86 FT RIGHT OF CENTERLINE, UP TO
1177 FT MSL.
TREE 1657 FT FROM DER, 106 FT LEFT OF CENTERLINE, 1163 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2311211605-2511211605EST
END PART 1 OF 2
!FDC 3/4477 4V4 PART 2 OF 2 ODP NORTHWOOD MUNI/VINCE FLD,
NORTHWOOD, ND.
TREE 1727 FT FROM DER, 6 FT LEFT OF CENTERLINE, 1171 FT MSL.
TREES BEGINNING 1828 FT FROM DER, 2 FT RIGHT OF CENTERLINE, UP TO
1180 FT MSL.
TREE 2231 FT FROM DER, 312 FT RIGHT OF CENTERLINE, 1185 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2311211605-2511211605EST
END PART 2 OF 2
|
