9/24/241558Z
|
!FDC 4/9612 61C PART 1 OF 3 ODP FORT ATKINSON MUNI,
FORT ATKINSON, WI.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1...
TAKEOFF OBSTACLE NOTES: RWY 3: TERRAIN 20 FT FROM DER, 17 FT LEFT
OF CENTERLINE, 796 FT MSL.
NAVAID 217 FT FROM DER, 291 FT RIGHT OF CENTERLINE, 18 FT AGL/810
FT MSL.
BUILDING 544 FT FROM DER, 479 FT LEFT OF CENTERLINE, 29 FT AGL/835
FT MSL.
TREES BEGINNING 630 FT FROM DER, 541 FT LEFT OF CENTERLINE, UP TO
866 FT MSL.
BUILDING 786 FT FROM DER, 693 FT RIGHT OF CENTERLINE, 22 FT AGL/817
FT MSL.
TREE 930 FT FROM DER, 631 FT RIGHT OF CENTERLINE, 847 FT MSL.
TREE 988 FT FROM DER, 728 FT RIGHT OF CENTERLINE, 851 FT MSL.
TREE 1408 FT FROM DER, 774 FT LEFT OF CENTERLINE, 869 FT MSL.
TREES BEGINNING 1430 FT FROM DER, 35 FT RIGHT OF CENTERLINE, UP TO
859 FT MSL.
TREE 1495 FT FROM DER, 592 FT LEFT OF CENTERLINE, 870 FT MSL.
TREES BEGINNING 1585 FT FROM DER, 118 FT RIGHT OF CENTERLINE, UP TO
860 FT MSL.
TREES BEGINNING 1899 FT FROM DER, 652 FT RIGHT OF CENTERLINE, UP TO
ALL OTHER DATA REMAINS AS PUBLISHED. 2409241558-2609241558EST
END PART 1 OF 3
!FDC 4/9612 61C PART 2 OF 3 ODP FORT ATKINSON MUNI,
FORT ATKINSON, WI.
865 FT MSL.
TREES BEGINNING 2009 FT FROM DER, 236 FT LEFT OF CENTERLINE, UP TO
882 FT MSL.
TREES BEGINNING 2048 FT FROM DER, 386 FT RIGHT OF CENTERLINE, UP TO
882 FT MSL.
TANK 1 NM FROM DER, 2212 FT LEFT OF CENTERLINE, 144 FT AGL/994 FT
MSL. RWY 21: TRAVERSE WAY BEGINNING 34 FT FROM DER, 89 FT LEFT OF
CENTERLINE, UP TO 808 FT MSL.
TREE 182 FT FROM DER, 532 FT RIGHT OF CENTERLINE, 809 FT MSL.
TREE 300 FT FROM DER, 472 FT RIGHT OF CENTERLINE, 819 FT MSL.
TREE 756 FT FROM DER, 517 FT RIGHT OF CENTERLINE, 824 FT MSL.
SIGN, TREE BEGINNING 782 FT FROM DER, 380 FT RIGHT OF CENTERLINE,
UP TO 36 FT AGL/835 FT MSL.
TREES BEGINNING 1146 FT FROM DER, 590 FT RIGHT OF CENTERLINE, UP TO
848 FT MSL.
TREES BEGINNING 1792 FT FROM DER, 570 FT RIGHT OF CENTERLINE, UP TO
862 FT MSL.
TREES BEGINNING 1816 FT FROM DER, 403 FT LEFT OF CENTERLINE, UP TO
849 FT MSL.
TREES BEGINNING 2110 FT FROM DER, 781 FT RIGHT OF CENTERLINE, UP TO
ALL OTHER DATA REMAINS AS PUBLISHED. 2409241558-2609241558EST
END PART 2 OF 3
!FDC 4/9612 61C PART 3 OF 3 ODP FORT ATKINSON MUNI,
FORT ATKINSON, WI.
872 FT MSL.
TREE 2532 FT FROM DER, 819 FT RIGHT OF CENTERLINE, 876 FT MSL.
TREES BEGINNING 2608 FT FROM DER, 698 FT LEFT OF CENTERLINE, UP TO
872 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2409241558-2609241558EST
END PART 3 OF 3
|
