8/9/231443Z
|
!FDC 3/0908 7W5 PART 1 OF 2 ODP HENRY COUNTY, NAPOLEON, OH.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
TAKEOFF OBSTACLE NOTES: RWY 10: VEGETATION 115 FT FROM DER, 137 FT
LEFT OF CENTERLINE, 17 FT AGL/696 FT MSL.
POLES, TRAVERSE WAY BEGINNING 442 FT FROM DER, 574 FT LEFT OF
CENTERLINE, UP TO 715 FT MSL.
TREE 822 FT FROM DER, 612 FT LEFT OF CENTERLINE, 758 FT MSL.
TREES BEGINNING 861 FT FROM DER, 597 FT LEFT OF CENTERLINE, UP TO
102 FT AGL/785 FT MSL.
POLE 1063 FT FROM DER, 701 FT RIGHT OF CENTERLINE, 719 FT MSL.
TREES BEGINNING 1782 FT FROM DER, 436 FT RIGHT OF CENTERLINE, UP TO
755 FT MSL.
TREE 3696 FT FROM DER, 352 FT RIGHT OF CENTERLINE, 778 FT MSL.
RWY 28: TERRAIN 79 FT FROM DER, 488 FT RIGHT OF CENTERLINE, 683 FT
MSL.
TREE 114 FT FROM DER, 128 FT LEFT OF CENTERLINE, 684 FT MSL.
VEGETATION 117 FT FROM DER, 110 FT RIGHT OF CENTERLINE, 13 FT
AGL/687 FT MSL.
TRAVERSE WAYS BEGINNING 424 FT FROM DER, 230 FT LEFT OF CENTERLINE,
UP TO 694 FT MSL.
TREE, BUILDING BEGINNING 721 FT FROM DER, 442 FT RIGHT OF
FT MSL. 2308091443-2508091443EST
END PART 1 OF 2
!FDC 3/0908 7W5 PART 2 OF 2 ODP HENRY COUNTY, NAPOLEON, OH.
CENTERLINE, UP TO 708 FT MSL.
TREE, BUILDING BEGINNING 795 FT FROM DER, 366 FT RIGHT OF
CENTERLINE, UP TO 717 FT MSL.
TREES BEGINNING 879 FT FROM DER, 308 FT RIGHT OF CENTERLINE, UP TO
727 FT MSL.
TREES BEGINNING 964 FT FROM DER, 411 FT RIGHT OF CENTERLINE, UP TO
743 FT MSL.
TREES BEGINNING 1036 FT FROM DER, 432 FT RIGHT OF CENTERLINE, UP TO
755 FT MSL.
TREES BEGINNING 2114 FT FROM DER, 180 FT LEFT OF CENTERLINE, UP TO
770 FT MSL.
TREE 3455 FT FROM DER, 476 FT RIGHT OF CENTERLINE, 782 FT MSL.
TREES BEGINNING 3469 FT FROM DER, 377 FT RIGHT OF CENTERLINE, UP TO
786 FT MSL.
TREES BEGINNING 3724 FT FROM DER, 282 FT RIGHT OF CENTERLINE, UP TO
790 FT MSL.
TREE 4085 FT FROM DER, 1512 FT LEFT OF CENTERLINE, 108 FT AGL/786
FT MSL.
TREE 4435 FT FROM DER, 562 FT RIGHT OF CENTERLINE, 115 FT AGL/792
FT MSL. 2308091443-2508091443EST
END PART 2 OF 2
|
