6/1/231736Z
|
!FDC 3/4402 8D4 PART 1 OF 3 ODP PAUL C MILLER/SPARTA, SPARTA, MI.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 2...
TAKE-OFF MINIMUMS RWY 25, 300-1 1/4 OR STANDARD WITH MINIMUM CLIMB
OF 215 FEET PER NM TO 1000.
IN ADDITION TO TAKEOFF OBSTACLE NOTES: ADD: RWY 7: TRAVERSE WAY 16
FT FROM DER, 495 FT LEFT OF CENTERLINE, 755 FT MSL. TREE, TRAVERSE
WAY, BUILDING BEGINNING 129 FT FROM DER, 393 FT LEFT OF CENTERLINE,
UP TO 25 FT AGL/762 FT MSL. TRANSMISSION LINE, POLE, TREE BEGINNING
302 FT FROM DER, 295 FT LEFT OF CENTERLINE, UP TO 24 FT AGL/764 FT
MSL. TREE 331 FT FROM DER, 519 FT RIGHT OF CENTERLINE, 759 FT MSL.
BUILDING 471 FT FROM DER, 436 FT RIGHT OF CENTERLINE, 773 FT MSL.
TREE, BUILDING BEGINNING 541 FT FROM DER, 222 FT RIGHT OF
CENTERLINE, UP TO 58 FT AGL/798 FT MSL. POLE, TREE BEGINNING 729 FT
FROM DER, 339 FT LEFT OF CENTERLINE, UP TO 37 FT AGL/768 FT MSL.
TREES BEGINNING 1900 FT FROM DER, 4 FT LEFT OF CENTERLINE, UP TO
829 FT MSL. TREES BEGINNING 2367 FT FROM DER, 105 FT LEFT OF
CENTERLINE, UP TO 108 FT AGL/832 FT MSL. TREES BEGINNING 2414 FT
FROM DER, 5 FT LEFT OF CENTERLINE, UP TO 107 FT AGL/835 FT MSL.
TREES BEGINNING 2467 FT FROM DER, 1 FT RIGHT OF CENTERLINE, UP TO
108 FT AGL/836 FT MSL. TREE, TRANSMISSION LINE, POLE BEGINNING 2852
FT FROM DER, 33 FT LEFT OF CENTERLINE, UP TO 130 FT AGL/853 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2306011736-2506011736EST
END PART 1 OF 3
!FDC 3/4402 8D4 PART 2 OF 3 ODP PAUL C MILLER/SPARTA, SPARTA, MI.
TREES BEGINNING 3657 FT FROM DER, 1015 FT RIGHT OF CENTERLINE, UP
TO 116 FT AGL/844 FT MSL. ADD: RWY 25: UTILITY BUILDING 39 FT FROM
DER, 112 FT RIGHT OF CENTERLINE, 8 FT AGL/775 FT MSL. UTILITY
BUILDING 39 FT FROM DER, 112 FT LEFT OF CENTERLINE, 6 FT AGL/775 FT
MSL. TERRAIN 74 FT FROM DER, 463 FT LEFT OF CENTERLINE, 787 FT MSL.
TREES BEGINNING 671 FT FROM DER, 351 FT RIGHT OF CENTERLINE, UP TO
62 FT AGL/832 FT MSL. TREE, POLE BEGINNING 866 FT FROM DER, 249 FT
RIGHT OF CENTERLINE, UP TO 836 FT MSL. TREES BEGINNING 1014 FT FROM
DER, 88 FT LEFT OF CENTERLINE, UP TO 838 FT MSL. TREES BEGINNING
1289 FT FROM DER, 50 FT RIGHT OF CENTERLINE, UP TO 81 FT AGL/851 FT
MSL. TREES BEGINNING 1515 FT FROM DER, 212 FT LEFT OF CENTERLINE,
UP TO 840 FT MSL. TREES BEGINNING 1529 FT FROM DER, 28 FT LEFT OF
CENTERLINE, UP TO 858 FT MSL. TREES BEGINNING 1563 FT FROM DER, 426
FT RIGHT OF CENTERLINE, UP TO 866 FT MSL. TREES BEGINNING 1646 FT
FROM DER, 173 FT RIGHT OF CENTERLINE, UP TO 96 FT AGL/868 FT MSL.
TREE 1729 FT FROM DER, 819 FT RIGHT OF CENTERLINE, 103 FT AGL/875
FT MSL. TREES BEGINNING 1869 FT FROM DER, 42 FT RIGHT OF
CENTERLINE, UP TO 105 FT AGL/881 FT MSL. TREES BEGINNING 2644 FT
FROM DER, 87 FT LEFT OF CENTERLINE, UP TO 860 FT MSL. TREES
BEGINNING 2932 FT FROM DER, 61 FT LEFT OF CENTERLINE, UP TO 105 FT
ALL OTHER DATA REMAINS AS PUBLISHED. 2306011736-2506011736EST
END PART 2 OF 3
!FDC 3/4402 8D4 PART 3 OF 3 ODP PAUL C MILLER/SPARTA, SPARTA, MI.
AGL/869 FT MSL. TREE 3621 FT FROM DER, 120 FT LEFT OF CENTERLINE,
100 FT AGL/871 FT MSL. TREE 1.3 NM FROM DER, 1694 FT RIGHT OF
CENTERLINE, 73 FT AGL/979 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2306011736-2506011736EST
END PART 3 OF 3
|
