9/7/231429Z
|
!FDC 3/6923 9A5 PART 1 OF 4 ODP BARWICK LAFAYETTE, LAFAYETTE, GA. TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1A... CHANGE TAKEOFF MINIMUMS TO READ RWY 02: 300-2 OR STANDARD WITH MINIMUM CLIMB OF 285 FEET PER NM TO 1100.. CHANGE TAKEOFF OBSTACLE NOTES TO READ: RWY 2: TREE, VEGETATION, BUILDING, POLE BEGINNING 3 FT FROM DER, 107 FT LEFT OF CENTERLINE, UP TO 873 FT MSL. TERRAIN 11 FT FROM DER, 116 FT RIGHT OF CENTERLINE, 776 FT MSL. TREE 37 FT FROM DER, 261 FT RIGHT OF CENTERLINE, 797 FT MSL. TREE 39 FT FROM DER, 432 FT RIGHT OF CENTERLINE, 816 FT MSL. TREE, VEGETATION, POLE, BUILDING BEGINNING 85 FT FROM DER, 233 FT RIGHT OF CENTERLINE, UP TO 856 FT MSL. TREE, BUILDING, POLE BEGINNING 576 FT FROM DER, 161 FT LEFT OF CENTERLINE, UP TO 875 FT MSL. TREE, POLE, BUILDING BEGINNING 775 FT FROM DER, 41 FT RIGHT OF CENTERLINE, UP TO 866 FT MSL. TREE, POLE, BUILDING BEGINNING 914 FT FROM DER, 3 FT LEFT OF CENTERLINE, UP TO 884 FT MSL. TREE, BUILDING, POLE BEGINNING 1274 FT FROM DER, 5 FT LEFT OF CENTERLINE, UP TO 888 FT MSL. TREE, POLE, BUILDING BEGINNING 1322 FT FROM DER, 131 FT RIGHT OF CENTERLINE, UP TO 868 FT MSL. TREE 1572 FT FROM DER, 460 FT RIGHT OF CENTERLINE, 880 FT MSL. TREE, POLE, BUILDING BEGINNING 1592 FT FROM DER, 16 FT RIGHT OF CENTERLINE, UP TO 886 FT MSL. TREE, POLE BEGINNING 1728 FT FROM ALL OTHER DATA REMAINS AS PUBLISHED. 2309071429-2510011429EST END PART 1 OF 4 !FDC 3/6923 9A5 PART 2 OF 4 ODP BARWICK LAFAYETTE, LAFAYETTE, GA. DER, 7 FT LEFT OF CENTERLINE, UP TO 892 FT MSL. TREE, BUILDING, POLE BEGINNING 1889 FT FROM DER, 34 FT RIGHT OF CENTERLINE, UP TO 897 FT MSL. TREE, POLE, ANTENNA BEGINNING 2517 FT FROM DER, 1 FT RIGHT OF CENTERLINE, UP TO 900 FT MSL. TREES BEGINNING 2640 FT FROM DER, ON CENTERLINE, UP TO 903 FT MSL. TREES BEGINNING 2825 FT FROM DER, 76 FT RIGHT OF CENTERLINE, UP TO 908 FT MSL. TREES BEGINNING 2868 FT FROM DER, 53 FT RIGHT OF CENTERLINE, UP TO 920 FT MSL. TREE, BUILDING BEGINNING 2930 FT FROM DER, 2 FT RIGHT OF CENTERLINE, UP TO 925 FT MSL. TREES BEGINNING 4129 FT FROM DER, 338 FT LEFT OF CENTERLINE, UP TO 905 FT MSL. TREE, BUILDING, WINDMILL FARM BEGINNING 4321 FT FROM DER, 8 FT RIGHT OF CENTERLINE, UP TO 926 FT MSL. TREE, WINDMILL FARM BEGINNING 4339 FT FROM DER, 75 FT LEFT OF CENTERLINE, UP TO 910 FT MSL. TREES BEGINNING 4828 FT FROM DER, 175 FT LEFT OF CENTERLINE, UP TO 911 FT MSL. TREE 5186 FT FROM DER, 1355 FT LEFT OF CENTERLINE, 912 FT MSL. TREES BEGINNING 5342 FT FROM DER, 927 FT LEFT OF CENTERLINE, UP TO 923 FT MSL. TREES BEGINNING 5623 FT FROM DER, 485 FT LEFT OF CENTERLINE, UP TO 925 FT MSL. NOTE: RWY 20: SIGN 16 FT FROM DER, 68 FT LEFT OF CENTERLINE, 2 FT AGL/770 FT MSL. TREE, POLE, TRAVERSE WAY, BUILDING, TRANSMISSION LINE BEGINNING 32 FT FROM DER, 10 FT RIGHT OF CENTERLINE, UP TO 892 ALL OTHER DATA REMAINS AS PUBLISHED. 2309071429-2510011429EST END PART 2 OF 4 !FDC 3/6923 9A5 PART 3 OF 4 ODP BARWICK LAFAYETTE, LAFAYETTE, GA. FT MSL. TREE 78 FT FROM DER, 345 FT LEFT OF CENTERLINE, 819 FT MSL. TREES BEGINNING 128 FT FROM DER, 308 FT LEFT OF CENTERLINE, UP TO 848 FT MSL. TREES BEGINNING 173 FT FROM DER, 265 FT LEFT OF CENTERLINE, UP TO 850 FT MSL. TREES BEGINNING 234 FT FROM DER, 234 FT LEFT OF CENTERLINE, UP TO 852 FT MSL. TREE, TRAVERSE WAY, POLE BEGINNING 287 FT FROM DER, 84 FT LEFT OF CENTERLINE, UP TO 854 FT MSL. TREES BEGINNING 1107 FT FROM DER, 1 FT LEFT OF CENTERLINE, UP TO 863 FT MSL. TREES BEGINNING 1143 FT FROM DER, 316 FT LEFT OF CENTERLINE, UP TO 865 FT MSL. TREE, TRANSMISSION LINE BEGINNING 1197 FT FROM DER, 80 FT LEFT OF CENTERLINE, UP TO 875 FT MSL. TREES BEGINNING 2188 FT FROM DER, 73 FT LEFT OF CENTERLINE, UP TO 876 FT MSL. TREE, ELECTRICAL SYSTEM, TRANSMISSION LINE BEGINNING 2434 FT FROM DER, 93 FT LEFT OF CENTERLINE, UP TO 902 FT MSL. TREES BEGINNING 2645 FT FROM DER, 755 FT LEFT OF CENTERLINE, UP TO 911 FT MSL. TREES BEGINNING 3284 FT FROM DER, 178 FT RIGHT OF CENTERLINE, UP TO 896 FT MSL. TREES BEGINNING 3508 FT FROM DER, 550 FT RIGHT OF CENTERLINE, UP TO 898 FT MSL. TREES BEGINNING 3563 FT FROM DER, 430 FT RIGHT OF CENTERLINE, UP TO 899 FT MSL. TREES BEGINNING 3590 FT FROM DER, 754 FT LEFT OF CENTERLINE, UP TO 919 FT MSL. TREES BEGINNING 3721 FT FROM DER, 825 FT RIGHT OF CENTERLINE, UP TO 901 ALL OTHER DATA REMAINS AS PUBLISHED. 2309071429-2510011429EST END PART 3 OF 4 !FDC 3/6923 9A5 PART 4 OF 4 ODP BARWICK LAFAYETTE, LAFAYETTE, GA. FT MSL.. ALL OTHER DATA REMAINS AS PUBLISHED. 2309071429-2510011429EST END PART 4 OF 4
|
