!FDC 4/5583 C75 PART 1 OF 4 ODP MARSHALL COUNTY, LACON, IL.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 2...
TAKEOFF OBSTACLE NOTES: RWY 13, UTILITY BUILDING 18 FT FROM DER,
125 FT LEFT OF CENTERLINE, 586 FT MSL.
TREE, TERRAINS BEGINNING 162 FT FROM DER, 41 FT RIGHT OF
CENTERLINE, UP TO 66 FT AGL/637 FT MSL.
VEGETATION 165 FT FROM DER, 404 FT LEFT OF CENTERLINE, 4 FT AGL/604
FT MSL.
TERRAIN 201 FT FROM DER, 421 FT LEFT OF CENTERLINE, 605 FT MSL.
TERRAIN 296 FT FROM DER, 479 FT LEFT OF CENTERLINE, 618 FT MSL.
TERRAINS BEGINNING 405 FT FROM DER, 103 FT LEFT OF CENTERLINE, UP
TO 619 FT MSL.
TERRAINS BEGINNING 598 FT FROM DER, 35 FT LEFT OF CENTERLINE, UP TO
620 FT MSL.
TERRAINS BEGINNING 666 FT FROM DER, 68 FT LEFT OF CENTERLINE, UP TO
635 FT MSL.
TERRAINS, VEGETATIONS BEGINNING 864 FT FROM DER, 114 FT LEFT OF
CENTERLINE, UP TO 641 FT MSL.
TERRAINS BEGINNING 916 FT FROM DER, 286 FT RIGHT OF CENTERLINE, UP
TO 644 FT MSL.
TREES, TERRAINS, TRAVERSE WAYS, VEGETATION BEGINNING 1006 FT FROM
2401191552-2601191552EST
END PART 1 OF 4
!FDC 4/5583 C75 PART 2 OF 4 ODP MARSHALL COUNTY, LACON, IL.
DER, 36 FT RIGHT OF CENTERLINE, UP TO 718 FT MSL.
TREE, TERRAIN BEGINNING 1265 FT FROM DER, 478 FT LEFT OF
CENTERLINE, UP TO 693 FT MSL.
TREES, TERRAINS BEGINNING 1286 FT FROM DER, 3 FT LEFT OF
CENTERLINE, UP TO 711 FT MSL.
TREES, TERRAINS BEGINNING 1593 FT FROM DER, 123 FT LEFT OF
CENTERLINE, UP TO 716 FT MSL.
TREES, TERRAINS BEGINNING 1676 FT FROM DER, 71 FT RIGHT OF
CENTERLINE, UP TO 722 FT MSL.
TREES, VEGETATION, TERRAINS BEGINNING 1755 FT FROM DER, 303 FT LEFT
OF CENTERLINE, UP TO 729 FT MSL.
TREES, TERRAINS, VEGETATIONS, TRAVERSE WAYS BEGINNING 1854 FT FROM
DER, 71 FT LEFT OF CENTERLINE, UP TO 733 FT MSL.
TREES, VEGETATION, TERRAIN, FENCE BEGINNING 1857 FT FROM DER, 130
FT RIGHT OF CENTERLINE, UP TO 726 FT MSL.
TREES, TERRAINS, FENCES, TRAVERSE WAYS, VEGETATIONS BEGINNING 1978
FT FROM DER, 15 FT RIGHT OF CENTERLINE, UP TO 729 FT MSL.
TREES, TERRAINS BEGINNING 2468 FT FROM DER, 13 FT LEFT OF
CENTERLINE, UP TO 743 FT MSL.
TREES BEGINNING 3720 FT FROM DER, 136 FT RIGHT OF CENTERLINE, UP TO
2401191552-2601191552EST
END PART 2 OF 4
!FDC 4/5583 C75 PART 3 OF 4 ODP MARSHALL COUNTY, LACON, IL.
730 FT MSL.
TREES BEGINNING 4945 FT FROM DER, 104 FT RIGHT OF CENTERLINE, UP TO
86 FT AGL/740 FT MSL.
TREES BEGINNING 5635 FT FROM DER, 20 FT LEFT OF CENTERLINE, UP TO
751 FT MSL.
TREES BEGINNING 1 NM FROM DER, 495 FT LEFT OF CENTERLINE, UP TO 91
FT AGL/754 FT MSL.
RWY 18, TREE 2 FT FROM DER, 382 FT RIGHT OF CENTERLINE, 568 FT MSL.
TREE 46 FT FROM DER, 484 FT RIGHT OF CENTERLINE, 574 FT MSL.
TREES, POLES BEGINNING 98 FT FROM DER, 150 FT RIGHT OF CENTERLINE,
UP TO 585 FT MSL.
TREE 266 FT FROM DER, 121 FT LEFT OF CENTERLINE, 571 FT MSL.
TREE 702 FT FROM DER, 110 FT LEFT OF CENTERLINE, 577 FT MSL.
TREE 734 FT FROM DER, 255 FT LEFT OF CENTERLINE, 580 FT MSL.
TREES BEGINNING 745 FT FROM DER, 289 FT LEFT OF CENTERLINE, UP TO
72 FT AGL/595 FT MSL.
TREE 872 FT FROM DER, 303 FT RIGHT OF CENTERLINE, 605 FT MSL.
TREE 1101 FT FROM DER, 609 FT LEFT OF CENTERLINE, 601 FT MSL.
TREE 2045 FT FROM DER, 749 FT LEFT OF CENTERLINE, 678 FT MSL.
TREE 2703 FT FROM DER, 742 FT LEFT OF CENTERLINE, 685 FT MSL.
2401191552-2601191552EST
END PART 3 OF 4
!FDC 4/5583 C75 PART 4 OF 4 ODP MARSHALL COUNTY, LACON, IL.
TREE 3628 FT FROM DER, 910 FT LEFT OF CENTERLINE, 691 FT MSL.
RWY 31, POLE, TRAVERSE WAY BEGINNING 55 FT FROM DER, 475 FT RIGHT
OF CENTERLINE, UP TO 31 FT AGL/568 FT MSL.
TREES BEGINNING 828 FT FROM DER, 646 FT LEFT OF CENTERLINE, UP TO
586 FT MSL.
TREES BEGINNING 1097 FT FROM DER, 392 FT LEFT OF CENTERLINE, UP TO
587 FT MSL.
TREES, POLE BEGINNING 1175 FT FROM DER, 292 FT LEFT OF CENTERLINE,
UP TO 596 FT MSL.
TREES BEGINNING 1258 FT FROM DER, 621 FT LEFT OF CENTERLINE, UP TO
605 FT MSL.
TREES BEGINNING 1390 FT FROM DER, 133 FT LEFT OF CENTERLINE, UP TO
612 FT MSL.
WATER TOWER, TREES BEGINNING 2355 FT FROM DER, 259 FT LEFT OF
CENTERLINE, UP TO 85 FT AGL/631 FT MSL.
TREES BEGINNING 2604 FT FROM DER, 194 FT LEFT OF CENTERLINE, UP TO
96 FT AGL/639 FT MSL.
RWY 36, POLE 3095 FT FROM DER, 241 FT LEFT OF CENTERLINE, 70 FT
AGL/634 FT MSL. ALL OTHER DATA REMAINS AS PUBLISHED.
