3/13/242006Z
|
!FDC 4/6935 E06 PART 1 OF 3 ODP LEA COUNTY/ZIP FRANKLIN MEML,
LOVINGTON, NM.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1...
TAKEOFF OBSTACLE NOTES: RWY 3, VEGETATION 14 FT FROM DER, 163 FT
LEFT OF CENTERLINE, 3973 FT MSL.
VEGETATIONS BEGINNING 67 FT FROM DER, 224 FT LEFT OF CENTERLINE, UP
TO 3981 FT MSL.
VEGETATION 474 FT FROM DER, 161 FT RIGHT OF CENTERLINE, 3979 FT
MSL.
RWY 12, TRAVERSE WAY, VEGETATION BEGINNING 43 FT FROM DER, 180 FT
RIGHT OF CENTERLINE, UP TO 3986 FT MSL.
POLE, TRANSMISSION LINE, VEGETATIONS, TRAVERSE WAY BEGINNING 108 FT
FROM DER, 131 FT RIGHT OF CENTERLINE, UP TO 4001 FT MSL.
VEGETATION 122 FT FROM DER, 123 FT LEFT OF CENTERLINE, 3975 FT MSL.
RWY 21, FENCE, TERRAIN BEGINNING 5 FT FROM DER, 97 FT RIGHT OF
CENTERLINE, UP TO 2 FT AGL/3980 FT MSL.
VEGETATION 71 FT FROM DER, 466 FT RIGHT OF CENTERLINE, 3982 FT MSL.
VEGETATION 102 FT FROM DER, 331 FT RIGHT OF CENTERLINE, 3984 FT
MSL.
TRAVERSE WAYS BEGINNING 158 FT FROM DER, 323 FT LEFT OF CENTERLINE,
UP TO 3991 FT MSL.
TRAVERSE WAY 223 FT FROM DER, 156 FT RIGHT OF CENTERLINE, 3992 FT
ALL OTHER DATA REMAINS AS PUBLISHED. 2403132006-2603132006EST
END PART 1 OF 3
!FDC 4/6935 E06 PART 2 OF 3 ODP LEA COUNTY/ZIP FRANKLIN MEML,
LOVINGTON, NM.
MSL.
TRAVERSE WAY 450 FT FROM DER, 81 FT LEFT OF CENTERLINE, 3992 FT
MSL.
TRANSMISSION LINE, POLE BEGINNING 949 FT FROM DER, 275 FT LEFT OF
CENTERLINE, UP TO 38 FT AGL/4014 FT MSL.
POLE 1221 FT FROM DER, 281 FT LEFT OF CENTERLINE, 39 FT AGL/4015 FT
MSL.
RWY 30, SIGN 14 FT FROM DER, 123 FT LEFT OF CENTERLINE, 3 FT
AGL/3982 FT MSL.
VEGETATION 24 FT FROM DER, 142 FT RIGHT OF CENTERLINE, 3984 FT MSL.
VEGETATIONS BEGINNING 39 FT FROM DER, 119 FT RIGHT OF CENTERLINE,
UP TO 3987 FT MSL.
VEGETATION 58 FT FROM DER, 473 FT LEFT OF CENTERLINE, 3986 FT MSL.
VEGETATION 121 FT FROM DER, 168 FT RIGHT OF CENTERLINE, 3989 FT
MSL.
TRAVERSE WAYS BEGINNING 143 FT FROM DER, 120 FT LEFT OF CENTERLINE,
UP TO 3996 FT MSL.
TRAVERSE WAYS BEGINNING 166 FT FROM DER, 131 FT RIGHT OF
CENTERLINE, UP TO 3995 FT MSL.
TRAVERSE WAY 275 FT FROM DER, 13 FT RIGHT OF CENTERLINE, 3996 FT
ALL OTHER DATA REMAINS AS PUBLISHED. 2403132006-2603132006EST
END PART 2 OF 3
!FDC 4/6935 E06 PART 3 OF 3 ODP LEA COUNTY/ZIP FRANKLIN MEML,
LOVINGTON, NM.
MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2403132006-2603132006EST
END PART 3 OF 3
|
