10/26/231937Z
|
!FDC 3/2441 K61 PART 1 OF 3 ODP MORITZ MEML, BELOIT, KS.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1A...
TAKEOFF OBSTACLE NOTES: RWY 17: ANTENNA 11 FT FROM DER, 17 FT LEFT
OF CENTERLINE, 1 FT AGL/1417 FT MSL. TREES BEGINNING 173 FT FROM
DER, 311 FT LEFT OF CENTERLINE, UP TO 50 FT AGL/1460 FT MSL.
BUILDING 201 FT FROM DER, 380 FT RIGHT OF CENTERLINE, 13 FT
AGL/1425 FT MSL. BUILDING 208 FT FROM DER, 443 FT RIGHT OF
CENTERLINE, 19 FT AGL/1430 FT MSL. POLE, BUILDING BEGINNING 215 FT
FROM DER, 379 FT RIGHT OF CENTERLINE, UP TO 30 FT AGL/1440 FT MSL.
TREE, POLE, BUILDING, TANK, TRANSMISSION LINE, ELECTRICAL SYSTEM,
TRAVERSE WAY BEGINNING 237 FT FROM DER, 15 FT LEFT OF CENTERLINE,
UP TO 50 FT AGL/1461 FT MSL. ELECTRICAL SYSTEM, BUILDING, POLE,
TREE BEGINNING 243 FT FROM DER, 381 FT RIGHT OF CENTERLINE, UP TO
32 FT AGL/1443 FT MSL. ELECTRICAL SYSTEM, POLE, TRAVERSE WAY
BEGINNING 471 FT FROM DER, 37 FT RIGHT OF CENTERLINE, UP TO 33 FT
AGL/1444 FT MSL. POLE, TREE BEGINNING 524 FT FROM DER, 275 FT RIGHT
OF CENTERLINE, UP TO 32 FT AGL/1445 FT MSL. TREE, BUILDING
BEGINNING 565 FT FROM DER, 276 FT RIGHT OF CENTERLINE, UP TO 29 FT
AGL/1446 FT MSL. TREE, POLE, BUILDING BEGINNING 617 FT FROM DER,
307 FT RIGHT OF CENTERLINE, UP TO 46 FT AGL/1461 FT MSL. TREE, POLE
BEGINNING 726 FT FROM DER, 342 FT RIGHT OF CENTERLINE, UP TO 47 FT
ALL OTHER DATA REMAINS AS PUBLISHED. 2310261937-2510261937EST
END PART 1 OF 3
!FDC 3/2441 K61 PART 2 OF 3 ODP MORITZ MEML, BELOIT, KS.
AGL/1462 FT MSL. TREE, POLE BEGINNING 803 FT FROM DER, 231 FT LEFT
OF CENTERLINE, UP TO 65 FT AGL/1472 FT MSL. POLE 2183 FT FROM DER,
549 FT LEFT OF CENTERLINE, 65 FT AGL/1480 FT MSL. RWY 35: ANTENNA 9
FT FROM DER, 17 FT LEFT OF CENTERLINE, 1 FT AGL/1419 FT MSL.
TERRAIN 63 FT FROM DER, 437 FT LEFT OF CENTERLINE, 1426 FT MSL.
TERRAIN BEGINNING 68 FT FROM DER, 309 FT LEFT OF CENTERLINE, UP TO
1427 FT MSL. TERRAIN BEGINNING 218 FT FROM DER, 365 FT LEFT OF
CENTERLINE, UP TO 1428 FT MSL. TERRAIN BEGINNING 246 FT FROM DER,
336 FT LEFT OF CENTERLINE, UP TO 1429 FT MSL. TERRAIN BEGINNING 355
FT FROM DER, 299 FT LEFT OF CENTERLINE, UP TO 1430 FT MSL. TREE,
SIGN BEGINNING 419 FT FROM DER, 314 FT RIGHT OF CENTERLINE, UP TO
1442 FT MSL. TERRAIN BEGINNING 537 FT FROM DER, 379 FT LEFT OF
CENTERLINE, UP TO 1432 FT MSL. POLE, TREE BEGINNING 543 FT FROM
DER, 417 FT RIGHT OF CENTERLINE, UP TO 25 FT AGL/1450 FT MSL. POLE,
TRAVERSE WAY, FENCE BEGINNING 545 FT FROM DER, 48 FT RIGHT OF
CENTERLINE, UP TO 25 FT AGL/1452 FT MSL. POLE, TERRAIN, TRAVERSE
WAY, FENCE BEGINNING 550 FT FROM DER, 23 FT LEFT OF CENTERLINE, UP
TO 32 FT AGL/1465 FT MSL. TREE, POLE BEGINNING 723 FT FROM DER, 471
FT LEFT OF CENTERLINE, UP TO 36 FT AGL/1466 FT MSL. TREE 780 FT
FROM DER, 484 FT LEFT OF CENTERLINE, 1472 FT MSL. TREE, TRAVERSE
ALL OTHER DATA REMAINS AS PUBLISHED. 2310261937-2510261937EST
END PART 2 OF 3
!FDC 3/2441 K61 PART 3 OF 3 ODP MORITZ MEML, BELOIT, KS.
WAY, BUILDING, FENCE, POLE BEGINNING 800 FT FROM DER, 133 FT LEFT
OF CENTERLINE, UP TO 43 FT AGL/1476 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2310261937-2510261937EST
END PART 3 OF 3
|
