!FDC 5/8030 ACZ PART 1 OF 4 ODP WALLACE-PENDER, WALLACE, NC.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
TAKEOFF MINIMUMS, RWY 9: 300 1 1/8 OR STANDARD WITH A MINIMUM
CLIMB OF 389 FT/NM TO 400.
TAKEOFF OBSTACLE NOTES: RWY 9: TREES BEGINNING 11 FT FROM DER, 442
FT LEFT OF CENTERLINE, UP TO 44 FT AGL/70 FT MSL.
TREE 287 FT FROM DER, 553 FT LEFT OF CENTERLINE, 110 FT MSL.
TREES BEGINNING 382 FT FROM DER, 461 FT RIGHT OF CENTERLINE, UP TO
82 FT MSL.
TREE 473 FT FROM DER, 511 FT LEFT OF CENTERLINE, 117 FT MSL.
TREES, TRANSMISSION LINE, ANTENNA BEGINNING 552 FT FROM DER, 30 FT
LEFT OF CENTERLINE, UP TO 121 FT MSL.
TREE 557 FT FROM DER, 538 FT RIGHT OF CENTERLINE, 101 FT MSL.
TREES BEGINNING 634 FT FROM DER, 269 FT RIGHT OF CENTERLINE, UP TO
109 FT MSL.
TREES BEGINNING 1068 FT FROM DER, 223 FT RIGHT OF CENTERLINE, UP TO
112 FT MSL.
TREES BEGINNING 1112 FT FROM DER, 46 FT RIGHT OF CENTERLINE, UP TO
119 FT MSL.
TREES BEGINNING 2241 FT FROM DER, 29 FT LEFT OF CENTERLINE, UP TO
95 FT AGL/122 FT MSL.
2502281955-2510101955EST
END PART 1 OF 4
!FDC 5/8030 ACZ PART 2 OF 4 ODP WALLACE-PENDER, WALLACE, NC.
TREES BEGINNING 2683 FT FROM DER, 25 FT RIGHT OF CENTERLINE, UP TO
97 FT AGL/123 FT MSL.
TREES BEGINNING 3210 FT FROM DER, 795 FT LEFT OF CENTERLINE, UP TO
124 FT MSL.
TREES BEGINNING 3549 FT FROM DER, 51 FT LEFT OF CENTERLINE, UP TO
110 FT AGL/131 FT MSL.
TREE 3751 FT FROM DER, 1187 FT RIGHT OF CENTERLINE, 124 FT MSL.
ANTENNA 5208 FT FROM DER, 1046 FT LEFT OF CENTERLINE, 151 FT
AGL/184 FT MSL.
TOWER 5209 FT FROM DER, 1052 FT LEFT OF CENTERLINE, 150 FT AGL/182
FT MSL.
RWY 27: TRANSMISSION LINES, BUILDING, TRAVERSE WAY, TREE BEGINNING
39 FT FROM DER, 10 FT RIGHT OF CENTERLINE, UP TO 29 FT AGL/66 FT
MSL.
VEGETATION 114 FT FROM DER, 312 FT LEFT OF CENTERLINE, 43 FT MSL.
TREES, TRANSMISSION LINE BEGINNING 725 FT FROM DER, 39 FT LEFT OF
CENTERLINE, UP TO 72 FT MSL.
TREES BEGINNING 817 FT FROM DER, 128 FT LEFT OF CENTERLINE, UP TO
97 FT MSL.
TREES, POLES BEGINNING 942 FT FROM DER, 161 FT LEFT OF CENTERLINE,
2502281955-2510101955EST
END PART 2 OF 4
!FDC 5/8030 ACZ PART 3 OF 4 ODP WALLACE-PENDER, WALLACE, NC.
UP TO 100 FT MSL.
TREES, POLE BEGINNING 1217 FT FROM DER, 33 FT LEFT OF CENTERLINE,
UP TO 101 FT MSL.
POLE 1382 FT FROM DER, 203 FT RIGHT OF CENTERLINE, 36 FT AGL/74 FT
MSL.
TREES BEGINNING 1455 FT FROM DER, 481 FT LEFT OF CENTERLINE, UP TO
106 FT MSL.
TREES BEGINNING 1590 FT FROM DER, 606 FT LEFT OF CENTERLINE, UP TO
107 FT MSL.
TREES BEGINNING 1660 FT FROM DER, 452 FT RIGHT OF CENTERLINE, UP TO
101 FT MSL.
TREES BEGINNING 1684 FT FROM DER, 634 FT LEFT OF CENTERLINE, UP TO
110 FT MSL.
TREES BEGINNING 1728 FT FROM DER, 510 FT RIGHT OF CENTERLINE, UP TO
119 FT MSL.
TREES BEGINNING 1875 FT FROM DER, 497 FT LEFT OF CENTERLINE, UP TO
113 FT MSL.
TREES BEGINNING 1903 FT FROM DER, 400 FT RIGHT OF CENTERLINE, UP TO
132 FT MSL.
TREES BEGINNING 2467 FT FROM DER, 101 FT LEFT OF CENTERLINE, UP TO
2502281955-2510101955EST
END PART 3 OF 4
!FDC 5/8030 ACZ PART 4 OF 4 ODP WALLACE-PENDER, WALLACE, NC.
114 FT MSL.
TREES BEGINNING 2799 FT FROM DER, 149 FT LEFT OF CENTERLINE, UP TO
90 FT AGL/130 FT MSL.
TREE 3559 FT FROM DER, 309 FT LEFT OF CENTERLINE, 97 FT AGL/139 FT
MSL.
TREE 4128 FT FROM DER, 1567 FT LEFT OF CENTERLINE, 143 FT MSL.
2502281955-2510101955EST
END PART 4 OF 4
|
