| FDC |
|
4/3/231828Z
|
!FDC 3/5301 ADG PART 1 OF 2 ODP LENAWEE COUNTY, ADRIAN, MI.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
TAKEOFF OBSTACLE NOTES: RWY 5: SIGN 65 FT FROM DER, 430 FT LEFT OF
CENTERLINE, 3 FT AGL/800 FT MSL.
TREE 814 FT FROM DER, 696 FT RIGHT OF CENTERLINE, 845 FT MSL.
BUILDING, TREES BEGINNING 888 FT FROM DER, 121 FT LEFT OF
CENTERLINE, UP TO 58 FT AGL/857 FT MSL.
TREES BEGINNING 951 FT FROM DER, 23 FT RIGHT OF CENTERLINE, UP TO
862 FT MSL.
TREES BEGINNING 1853 FT FROM DER, 133 FT LEFT OF CENTERLINE, UP TO
867 FT MSL.
TREES BEGINNING 1879 FT FROM DER, 2 FT LEFT OF CENTERLINE, UP TO
872 FT MSL.
TREES BEGINNING 2192 FT FROM DER, 292 FT LEFT OF CENTERLINE, UP TO
875 FT MSL.
TREE 2237 FT FROM DER, 384 FT RIGHT OF CENTERLINE, 872 FT MSL.
TREES BEGINNING 2253 FT FROM DER, 259 FT LEFT OF CENTERLINE, UP TO
878 FT MSL.
TREES BEGINNING 2342 FT FROM DER, 131 FT RIGHT OF CENTERLINE, UP TO
877 FT MSL.
TREE 3200 FT FROM DER, 676 FT RIGHT OF CENTERLINE, 884 FT MSL. RWY
2304031828-2504031828EST
END PART 1 OF 2
!FDC 3/5301 ADG PART 2 OF 2 ODP LENAWEE COUNTY, ADRIAN, MI.
23: LIGHT POLE 40 FT FROM DER, 88 FT RIGHT OF CENTERLINE, 4 FT
AGL/796 FT MSL.
LIGHT POLE 40 FT FROM DER, 89 FT LEFT OF CENTERLINE, 4 FT AGL/796
FT MSL.
TREE 1231 FT FROM DER, 632 FT LEFT OF CENTERLINE, 849 FT MSL.
TREES BEGINNING 2238 FT FROM DER, 167 FT RIGHT OF CENTERLINE, UP TO
872 FT MSL.
TREE 2672 FT FROM DER, 271 FT LEFT OF CENTERLINE, 861 FT MSL.
2304031828-2504031828EST
END PART 2 OF 2
|
