2/12/241230Z
|
!FDC 4/3676 ASG PART 1 OF 4 ODP SPRINGDALE MUNI, SPRINGDALE, AR.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 5...
TAKEOFF OBSTACLE NOTES: RWY 18, TREES BEGINNING 42 FT FROM DER, 303
FT RIGHT OF CENTERLINE, UP TO 1408 FT MSL.
TRAVERSE WAYS BEGINNING 46 FT FROM DER, 299 FT LEFT OF CENTERLINE,
UP TO 1358 FT MSL.
POLE 166 FT FROM DER, 272 FT LEFT OF CENTERLINE, 26 FT AGL/1365 FT
MSL.
POLES, TREE BEGINNING 170 FT FROM DER, 243 FT LEFT OF CENTERLINE,
UP TO 30 FT AGL/1368 FT MSL.
TREES BEGINNING 485 FT FROM DER, 508 FT LEFT OF CENTERLINE, UP TO
1374 FT MSL.
POLES BEGINNING 674 FT FROM DER, 246 FT LEFT OF CENTERLINE, UP TO
40 FT AGL/1376 FT MSL.
POLE, TREE BEGINNING 808 FT FROM DER, 216 FT LEFT OF CENTERLINE, UP
TO 38 FT AGL/1378 FT MSL.
TREE 1435 FT FROM DER, 429 FT LEFT OF CENTERLINE, 1391 FT MSL.
RWY 36, FENCE 51 FT FROM DER, 510 FT RIGHT OF CENTERLINE, 6 FT
AGL/1342 FT MSL.
TRAVERSE WAY 216 FT FROM DER, 555 FT RIGHT OF CENTERLINE, 1357 FT
MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2402121230-2602121230EST
END PART 1 OF 4
!FDC 4/3676 ASG PART 2 OF 4 ODP SPRINGDALE MUNI, SPRINGDALE, AR.
TRAVERSE WAYS BEGINNING 290 FT FROM DER, 86 FT LEFT OF CENTERLINE,
UP TO 1352 FT MSL.
ELECTRICAL SYSTEMS, TRAVERSE WAYS, POLES, SIGN, BUILDINGS, TREES
BEGINNING 350 FT FROM DER, 26 FT RIGHT OF CENTERLINE, UP TO 30 FT
AGL/1368 FT MSL.
POLE, TRAVERSE WAYS, FENCE BEGINNING 358 FT FROM DER, 205 FT LEFT
OF CENTERLINE, UP TO 23 FT AGL/1363 FT MSL.
POLES, TRAVERSE WAYS, TREE, ELECTRICAL SYSTEM BEGINNING 528 FT FROM
DER, 27 FT LEFT OF CENTERLINE, UP TO 22 FT AGL/1364 FT MSL.
TREE, BUILDINGS BEGINNING 694 FT FROM DER, 565 FT LEFT OF
CENTERLINE, UP TO 1381 FT MSL.
TREES, POLES, BUILDINGS, TOWER BEGINNING 714 FT FROM DER, 556 FT
LEFT OF CENTERLINE, UP TO 1382 FT MSL.
POLES, TREE BEGINNING 849 FT FROM DER, 185 FT RIGHT OF CENTERLINE,
UP TO 34 FT AGL/1377 FT MSL.
POLES, TREE BEGINNING 1073 FT FROM DER, 434 FT RIGHT OF CENTERLINE,
UP TO 38 FT AGL/1382 FT MSL.
POLES BEGINNING 1294 FT FROM DER, 359 FT RIGHT OF CENTERLINE, UP TO
38 FT AGL/1386 FT MSL.
POLES, ELECTRICAL SYSTEMS BEGINNING 1426 FT FROM DER, 274 FT RIGHT
ALL OTHER DATA REMAINS AS PUBLISHED. 2402121230-2602121230EST
END PART 2 OF 4
!FDC 4/3676 ASG PART 3 OF 4 ODP SPRINGDALE MUNI, SPRINGDALE, AR.
OF CENTERLINE, UP TO 40 FT AGL/1388 FT MSL.
TREE 1481 FT FROM DER, 859 FT LEFT OF CENTERLINE, 1383 FT MSL.
TREE 1492 FT FROM DER, 617 FT LEFT OF CENTERLINE, 1391 FT MSL.
TREES BEGINNING 1504 FT FROM DER, 94 FT LEFT OF CENTERLINE, UP TO
1395 FT MSL.
POLES, ELECTRICAL SYSTEMS BEGINNING 1659 FT FROM DER, 288 FT RIGHT
OF CENTERLINE, UP TO 40 FT AGL/1389 FT MSL.
POLE 1898 FT FROM DER, 293 FT RIGHT OF CENTERLINE, 40 FT AGL/1390
FT MSL.
POLE 1932 FT FROM DER, 386 FT RIGHT OF CENTERLINE, 43 FT AGL/1393
FT MSL.
TREE 2073 FT FROM DER, 498 FT LEFT OF CENTERLINE, 1397 FT MSL.
TREES BEGINNING 2139 FT FROM DER, 66 FT RIGHT OF CENTERLINE, UP TO
1405 FT MSL.
TREES BEGINNING 2263 FT FROM DER, 196 FT LEFT OF CENTERLINE, UP TO
1401 FT MSL.
TREES BEGINNING 2303 FT FROM DER, 54 FT LEFT OF CENTERLINE, UP TO
1406 FT MSL.
TREE 2733 FT FROM DER, 324 FT RIGHT OF CENTERLINE, 1409 FT MSL.
TREE 3074 FT FROM DER, 328 FT RIGHT OF CENTERLINE, 1418 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2402121230-2602121230EST
END PART 3 OF 4
!FDC 4/3676 ASG PART 4 OF 4 ODP SPRINGDALE MUNI, SPRINGDALE, AR.
TREES BEGINNING 1.3 NM FROM DER, 2104 FT RIGHT OF CENTERLINE, UP TO
1565 FT MSL.
TRANSMISSION LINES, POLES, TERRAIN, TREES, BUILDINGS, TOWER,
TRAVERSE WAYS BEGINNING 1.4 NM FROM DER, 1691 FT RIGHT OF
CENTERLINE, UP TO 60 FT AGL/1703 FT MSL.
TREES, TERRAIN, BUILDING BEGINNING 1.6 NM FROM DER, 1419 FT RIGHT
OF CENTERLINE, UP TO 1721 FT MSL.
TREES BEGINNING 2.1 NM FROM DER, 1543 FT RIGHT OF CENTERLINE, UP TO
1665 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2402121230-2602121230EST
END PART 4 OF 4
|
