!FDC 3/5813 AVC PART 1 OF 4 ODP MECKLENBURG-BRUNSWICK RGNL,
SOUTH HILL, VA.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 2...
TAKEOFF OBSTACLE NOTES: RWY 1: LIGHT POLE 40 FT FROM DER, 81 FT
RIGHT OF CENTERLINE, 4 FT AGL/445 FT MSL.
LIGHT POLE 40 FT FROM DER, 77 FT LEFT OF CENTERLINE, 5 FT AGL/444
FT MSL.
TREE 131 FT FROM DER, 446 FT LEFT OF CENTERLINE, 29 FT AGL/460 FT
MSL.
TREES BEGINNING 181 FT FROM DER, 311 FT LEFT OF CENTERLINE, UP TO
500 FT MSL.
POLE 325 FT FROM DER, 545 FT RIGHT OF CENTERLINE, 450 FT MSL.
TREE 1161 FT FROM DER, 637 FT RIGHT OF CENTERLINE, 472 FT MSL.
TREE 1292 FT FROM DER, 638 FT RIGHT OF CENTERLINE, 484 FT MSL.
TREE 1862 FT FROM DER, 628 FT RIGHT OF CENTERLINE, 498 FT MSL.
TREE 1949 FT FROM DER, 859 FT RIGHT OF CENTERLINE, 499 FT MSL.
TREE 1975 FT FROM DER, 755 FT RIGHT OF CENTERLINE, 503 FT MSL.
TREES BEGINNING 2127 FT FROM DER, 864 FT RIGHT OF CENTERLINE, UP TO
509 FT MSL. RWY 19: TREE 20 FT FROM DER, 491 FT RIGHT OF
CENTERLINE, 384 FT MSL.
TREES, FENCE BEGINNING 105 FT FROM DER, 450 FT RIGHT OF CENTERLINE,
UP TO 389 FT MSL.
MSL. 2304212026-2504212026EST
END PART 1 OF 4
!FDC 3/5813 AVC PART 2 OF 4 ODP MECKLENBURG-BRUNSWICK RGNL,
SOUTH HILL, VA.
TREES BEGINNING 182 FT FROM DER, 451 FT LEFT OF CENTERLINE, UP TO
23 FT AGL/398 FT MSL.
TREES BEGINNING 237 FT FROM DER, 487 FT LEFT OF CENTERLINE, UP TO
404 FT MSL.
TREE 342 FT FROM DER, 524 FT RIGHT OF CENTERLINE, 391 FT MSL.
TREE 466 FT FROM DER, 539 FT RIGHT OF CENTERLINE, 392 FT MSL.
TREES BEGINNING 952 FT FROM DER, 246 FT LEFT OF CENTERLINE, UP TO
416 FT MSL.
TREES BEGINNING 1137 FT FROM DER, 524 FT RIGHT OF CENTERLINE, UP TO
431 FT MSL.
TREES BEGINNING 1176 FT FROM DER, 577 FT RIGHT OF CENTERLINE, UP TO
432 FT MSL.
TREES BEGINNING 1353 FT FROM DER, 31 FT RIGHT OF CENTERLINE, UP TO
437 FT MSL.
TREES BEGINNING 1461 FT FROM DER, 62 FT LEFT OF CENTERLINE, UP TO
432 FT MSL.
TREE 1534 FT FROM DER, 784 FT LEFT OF CENTERLINE, 433 FT MSL.
TREES BEGINNING 1540 FT FROM DER, 310 FT LEFT OF CENTERLINE, UP TO
439 FT MSL.
TREES BEGINNING 1804 FT FROM DER, 48 FT LEFT OF CENTERLINE, UP TO
MSL. 2304212026-2504212026EST
END PART 2 OF 4
!FDC 3/5813 AVC PART 3 OF 4 ODP MECKLENBURG-BRUNSWICK RGNL,
SOUTH HILL, VA.
115 FT AGL/440 FT MSL.
TREES BEGINNING 1843 FT FROM DER, 32 FT LEFT OF CENTERLINE, UP TO
453 FT MSL.
TREES BEGINNING 2046 FT FROM DER, 77 FT RIGHT OF CENTERLINE, UP TO
440 FT MSL.
TREES BEGINNING 2186 FT FROM DER, 9 FT RIGHT OF CENTERLINE, UP TO
73 FT AGL/449 FT MSL.
TREES BEGINNING 2507 FT FROM DER, 58 FT RIGHT OF CENTERLINE, UP TO
466 FT MSL.
TREE 2659 FT FROM DER, 564 FT LEFT OF CENTERLINE, 457 FT MSL.
TREES BEGINNING 3068 FT FROM DER, 561 FT LEFT OF CENTERLINE, UP TO
459 FT MSL.
TREE 3304 FT FROM DER, 605 FT LEFT OF CENTERLINE, 462 FT MSL.
TREES BEGINNING 3494 FT FROM DER, 176 FT RIGHT OF CENTERLINE, UP TO
468 FT MSL.
TREES BEGINNING 3538 FT FROM DER, 67 FT RIGHT OF CENTERLINE, UP TO
60 FT AGL/470 FT MSL.
TREE 3664 FT FROM DER, 118 FT LEFT OF CENTERLINE, 63 FT AGL/471 FT
MSL.
TREES BEGINNING 3704 FT FROM DER, 77 FT LEFT OF CENTERLINE, UP TO
MSL. 2304212026-2504212026EST
END PART 3 OF 4
!FDC 3/5813 AVC PART 4 OF 4 ODP MECKLENBURG-BRUNSWICK RGNL,
SOUTH HILL, VA.
69 FT AGL/477 FT MSL.
TREE 3884 FT FROM DER, 148 FT RIGHT OF CENTERLINE, 65 FT AGL/482 FT
MSL.
TREE 4140 FT FROM DER, 86 FT LEFT OF CENTERLINE, 73 FT AGL/483 FT
MSL. 2304212026-2504212026EST
END PART 4 OF 4
|
