7/18/241613Z
|
!FDC 4/4384 BAX PART 1 OF 7 ODP HURON COUNTY MEML, BAD AXE, MI.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 4...
TAKEOFF OBSTACLE NOTES: RWY 4, BUILDING, TRAVERSE WAYS, ELECTRICAL
SYSTEM BEGINNING 59 FT FROM DER, 171 FT LEFT OF CENTERLINE, UP TO 3
FT AGL/785 FT MSL.
FENCE 179 FT FROM DER, 490 FT RIGHT OF CENTERLINE, 10 FT AGL/770 FT
MSL.
TREE, TRAVERSE WAY BEGINNING 275 FT FROM DER, 463 FT RIGHT OF
CENTERLINE, UP TO 5 FT AGL/812 FT MSL.
TREE, TRAVERSE WAY BEGINNING 434 FT FROM DER, 366 FT RIGHT OF
CENTERLINE, UP TO 5 FT AGL/814 FT MSL.
TREE, TRAVERSE WAYS, POLE BEGINNING 459 FT FROM DER, 1 FT LEFT OF
CENTERLINE, UP TO 5 FT AGL/808 FT MSL.
TREES, TRAVERSE WAYS BEGINNING 538 FT FROM DER, 39 FT RIGHT OF
CENTERLINE, UP TO 7 FT AGL/829 FT MSL.
TREES BEGINNING 836 FT FROM DER, 455 FT LEFT OF CENTERLINE, UP TO 8
FT AGL/836 FT MSL.
TREES BEGINNING 1047 FT FROM DER, 46 FT LEFT OF CENTERLINE, UP TO 9
FT AGL/847 FT MSL.
TREES BEGINNING 1048 FT FROM DER, 16 FT RIGHT OF CENTERLINE, UP TO
8 FT AGL/837 FT MSL.
2407181613-2607181613EST
END PART 1 OF 7
!FDC 4/4384 BAX PART 2 OF 7 ODP HURON COUNTY MEML, BAD AXE, MI.
TREES BEGINNING 1613 FT FROM DER, 11 FT LEFT OF CENTERLINE, UP TO
10 FT AGL/854 FT MSL.
TREES BEGINNING 1639 FT FROM DER, 12 FT RIGHT OF CENTERLINE, UP TO
9 FT AGL/843 FT MSL.
TREES BEGINNING 1910 FT FROM DER, 52 FT RIGHT OF CENTERLINE, UP TO
9 FT AGL/845 FT MSL.
TREE 1988 FT FROM DER, 345 FT RIGHT OF CENTERLINE, 9 FT AGL/846 FT
MSL.
TREES BEGINNING 1989 FT FROM DER, 11 FT RIGHT OF CENTERLINE, UP TO
9 FT AGL/849 FT MSL.
TREES BEGINNING 2104 FT FROM DER, 36 FT RIGHT OF CENTERLINE, UP TO
9 FT AGL/851 FT MSL.
TREES BEGINNING 2489 FT FROM DER, 3 FT LEFT OF CENTERLINE, UP TO 10
FT AGL/855 FT MSL.
TREES BEGINNING 2608 FT FROM DER, 18 FT RIGHT OF CENTERLINE, UP TO
1 FT AGL/856 FT MSL.
TREES BEGINNING 2747 FT FROM DER, 30 FT LEFT OF CENTERLINE, UP TO 9
FT AGL/859 FT MSL.
TREES BEGINNING 3010 FT FROM DER, 113 FT RIGHT OF CENTERLINE, UP TO
1 FT AGL/858 FT MSL.
2407181613-2607181613EST
END PART 2 OF 7
!FDC 4/4384 BAX PART 3 OF 7 ODP HURON COUNTY MEML, BAD AXE, MI.
TREES BEGINNING 3778 FT FROM DER, 183 FT RIGHT OF CENTERLINE, UP TO
1 FT AGL/867 FT MSL.
RWY 17, POLE 20 FT FROM DER, 281 FT RIGHT OF CENTERLINE, 8 FT
AGL/756 FT MSL.
VEGETATION 81 FT FROM DER, 498 FT RIGHT OF CENTERLINE, 757 FT MSL.
TREE 91 FT FROM DER, 399 FT RIGHT OF CENTERLINE, 5 FT AGL/758 FT
MSL.
POLE, TRAVERSE WAY, TREE BEGINNING 315 FT FROM DER, 511 FT LEFT OF
CENTERLINE, UP TO 4 FT AGL/788 FT MSL.
TREES, TRAVERSE WAY BEGINNING 855 FT FROM DER, 643 FT RIGHT OF
CENTERLINE, UP TO 799 FT MSL.
TRANSMISSION LINE, ELECTRICAL SYSTEM BEGINNING 1135 FT FROM DER,
710 FT LEFT OF CENTERLINE, UP TO 45 FT AGL/798 FT MSL.
POLE 1467 FT FROM DER, 667 FT LEFT OF CENTERLINE, 5 FT AGL/800 FT
MSL.
TREE 1692 FT FROM DER, 371 FT LEFT OF CENTERLINE, 809 FT MSL.
TREE, POLE BEGINNING 1753 FT FROM DER, 451 FT LEFT OF CENTERLINE,
UP TO 814 FT MSL.
TREE 1818 FT FROM DER, 392 FT RIGHT OF CENTERLINE, 821 FT MSL.
TREE, POLE BEGINNING 1830 FT FROM DER, 510 FT LEFT OF CENTERLINE,
2407181613-2607181613EST
END PART 3 OF 7
!FDC 4/4384 BAX PART 4 OF 7 ODP HURON COUNTY MEML, BAD AXE, MI.
UP TO 829 FT MSL.
TREE 3499 FT FROM DER, 246 FT RIGHT OF CENTERLINE, 8 FT AGL/849 FT
MSL.
TREE 3501 FT FROM DER, 273 FT RIGHT OF CENTERLINE, 8 FT AGL/850 FT
MSL.
ELEVATOR, SILO, TREE BEGINNING 3617 FT FROM DER, 614 FT RIGHT OF
CENTERLINE, UP TO 93 FT AGL/866 FT MSL.
TREES BEGINNING 4071 FT FROM DER, 1391 FT RIGHT OF CENTERLINE, UP
TO 1 FT AGL/871 FT MSL.
RWY 22, LIGHT POLES 10 FT FROM DER, 17 FT LEFT OF CENTERLINE, 1 FT
AGL/756 FT MSL.
TREES BEGINNING 45 FT FROM DER, 249 FT LEFT OF CENTERLINE, UP TO 3
FT AGL/779 FT MSL.
TREES, TRAVERSE WAYS BEGINNING 74 FT FROM DER, 19 FT RIGHT OF
CENTERLINE, UP TO 3 FT AGL/783 FT MSL.
TREES BEGINNING 349 FT FROM DER, 349 FT LEFT OF CENTERLINE, UP TO 5
FT AGL/795 FT MSL.
TREES, TRAVERSE WAYS BEGINNING 508 FT FROM DER, 9 FT LEFT OF
CENTERLINE, UP TO 5 FT AGL/801 FT MSL.
TREES BEGINNING 1151 FT FROM DER, 545 FT LEFT OF CENTERLINE, UP TO
2407181613-2607181613EST
END PART 4 OF 7
!FDC 4/4384 BAX PART 5 OF 7 ODP HURON COUNTY MEML, BAD AXE, MI.
5 FT AGL/803 FT MSL.
TREE 1703 FT FROM DER, 822 FT LEFT OF CENTERLINE, 7 FT AGL/819 FT
MSL.
TREES BEGINNING 1803 FT FROM DER, 620 FT LEFT OF CENTERLINE, UP TO
7 FT AGL/820 FT MSL.
TREE 2474 FT FROM DER, 447 FT LEFT OF CENTERLINE, 8 FT AGL/837 FT
MSL.
TREE 2478 FT FROM DER, 353 FT LEFT OF CENTERLINE, 8 FT AGL/845 FT
MSL.
TREES BEGINNING 2485 FT FROM DER, 213 FT LEFT OF CENTERLINE, UP TO
9 FT AGL/849 FT MSL.
TREES BEGINNING 2567 FT FROM DER, 86 FT LEFT OF CENTERLINE, UP TO 9
FT AGL/850 FT MSL.
TREES BEGINNING 2823 FT FROM DER, 580 FT LEFT OF CENTERLINE, UP TO
9 FT AGL/852 FT MSL.
TREES BEGINNING 2898 FT FROM DER, 39 FT LEFT OF CENTERLINE, UP TO
10 FT AGL/856 FT MSL.
TREES BEGINNING 3110 FT FROM DER, 204 FT LEFT OF CENTERLINE, UP TO
9 FT AGL/857 FT MSL.
TREE 3452 FT FROM DER, 472 FT RIGHT OF CENTERLINE, 9 FT AGL/845 FT
2407181613-2607181613EST
END PART 5 OF 7
!FDC 4/4384 BAX PART 6 OF 7 ODP HURON COUNTY MEML, BAD AXE, MI.
MSL.
RWY 35, LIGHT POLES 33 FT FROM DER, 76 FT LEFT OF CENTERLINE, 3 FT
AGL/765 FT MSL.
LIGHT POLES 36 FT FROM DER, 78 FT RIGHT OF CENTERLINE, 3 FT AGL/765
FT MSL.
TOWER 365 FT FROM DER, 478 FT RIGHT OF CENTERLINE, 33 FT AGL/793 FT
MSL.
ANTENNA, ELECTRICAL SYSTEM, POLE, TRAVERSE WAY BEGINNING 370 FT
FROM DER, 412 FT RIGHT OF CENTERLINE, UP TO 3 FT AGL/794 FT MSL.
LIGHT POLES, TOWER BEGINNING 754 FT FROM DER, 419 FT RIGHT OF
CENTERLINE, UP TO 6 FT AGL/819 FT MSL.
TREES BEGINNING 1084 FT FROM DER, 589 FT RIGHT OF CENTERLINE, UP TO
7 FT AGL/823 FT MSL.
ANTENNA 1094 FT FROM DER, 696 FT LEFT OF CENTERLINE, 6 FT AGL/821
FT MSL.
TOWER, TREE BEGINNING 1095 FT FROM DER, 698 FT LEFT OF CENTERLINE,
UP TO 64 FT AGL/822 FT MSL.
TREES BEGINNING 1283 FT FROM DER, 58 FT RIGHT OF CENTERLINE, UP TO
8 FT AGL/835 FT MSL.
TREES BEGINNING 1689 FT FROM DER, 27 FT LEFT OF CENTERLINE, UP TO
2407181613-2607181613EST
END PART 6 OF 7
!FDC 4/4384 BAX PART 7 OF 7 ODP HURON COUNTY MEML, BAD AXE, MI.
829 FT MSL.
TREES BEGINNING 1793 FT FROM DER, 45 FT LEFT OF CENTERLINE, UP TO
10 FT AGL/858 FT MSL.
TREE 1834 FT FROM DER, 768 FT RIGHT OF CENTERLINE, 8 FT AGL/838 FT
MSL.
TREES BEGINNING 1870 FT FROM DER, 343 FT RIGHT OF CENTERLINE, UP TO
8 FT AGL/843 FT MSL.
TREES BEGINNING 2297 FT FROM DER, 281 FT LEFT OF CENTERLINE, UP TO
1 FT AGL/867 FT MSL.
TREES BEGINNING 2841 FT FROM DER, 24 FT RIGHT OF CENTERLINE, UP TO
10 FT AGL/849 FT MSL. ALL OTHER DATA REMAINS AS PUBLISHED.
2407181613-2607181613EST
END PART 7 OF 7
|
