| Domestic |
|
12/23/241138Z
|
!BFF 12/009 BFF NAV ILS RWY 30 GP U/S 2412231138-2501102000EST
|
|
12/6/240202Z
|
!BFF 12/005 BFF OBST TOWER LGT (ASR 1249399) 415427.40N1032836.20W (5.7NM ENE BFF) 4651.9FT (499.0FT AGL) U/S 2412060202-2501200201
|
|
11/30/241919Z
|
!BFF 11/007 BFF AD AP BIRD ACT 2411301919-2503010600
|
| FDC |
|
12/19/241620Z
|
!FDC 4/8905 BFF IAP SCOTTSBLUFF/WESTERN NEBRASKA RGNL/WM B HEILIG FLD, SCOTTSBLUFF, NE.
VOR OR TACAN RWY 23, AMDT 12A...
ADD PLANVIEW NOTE AT ROTOR: 1 MINUTE HOLDING LEG LENGTHS.
2412191620-2612191620EST
|
|
3/27/241738Z
|
!FDC 4/2864 BFF PART 1 OF 2 ODP WESTERN NEBRASKA RGNL/WILLIAM B
HEILIG FLD, SCOTTSBLUFF, NE.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 4...
TAKEOFF OBSTACLE NOTES: RWY 5, ELECTRICAL SYSTEM 9 FT FROM DER, 55
FT RIGHT OF CENTERLINE, 2 FT AGL/3969 FT MSL.
ELECTRICAL SYSTEM 10 FT FROM DER, 54 FT LEFT OF CENTERLINE, 2 FT
AGL/3969 FT MSL.
TERRAIN 81 FT FROM DER, 478 FT LEFT OF CENTERLINE, 3971 FT MSL.
DAM 1386 FT FROM DER, 440 FT LEFT OF CENTERLINE, 24 FT AGL/4012 FT
MSL.
POLE 1427 FT FROM DER, 648 FT RIGHT OF CENTERLINE, 38 FT AGL/4010
FT MSL.
POLES BEGINNING 1564 FT FROM DER, 95 FT RIGHT OF CENTERLINE, UP TO
31 FT AGL/4013 FT MSL.
POLE 1667 FT FROM DER, 139 FT LEFT OF CENTERLINE, 30 FT AGL/4014 FT
MSL.
POLE 1729 FT FROM DER, 74 FT LEFT OF CENTERLINE, 33 FT AGL/4018 FT
MSL.
POLES BEGINNING 1752 FT FROM DER, 126 FT LEFT OF CENTERLINE, UP TO
34 FT AGL/4019 FT MSL.
POLE 2077 FT FROM DER, 47 FT RIGHT OF CENTERLINE, 43 FT AGL/4030 FT
MSL.
2403271738-2603271738EST
END PART 1 OF 2
!FDC 4/2864 BFF PART 2 OF 2 ODP WESTERN NEBRASKA RGNL/WILLIAM B
HEILIG FLD, SCOTTSBLUFF, NE.
RWY 12, ELECTRICAL_SYSTEM 10 FT FROM DER, 55 FT RIGHT OF
CENTERLINE, 2 FT AGL/3945 FT MSL.
ELECTRICAL_SYSTEM 10 FT FROM DER, 55 FT LEFT OF CENTERLINE, 2 FT
AGL/3945 FT MSL.
SIGN 42 FT FROM DER, 453 FT RIGHT OF CENTERLINE, 5 FT AGL/3947 FT
MSL.
TREE 103 FT FROM DER, 509 FT LEFT OF CENTERLINE, 7 FT AGL/3948 FT
MSL.
RWY 23, ELECTRICAL SYSTEM 9 FT FROM DER, 54 FT LEFT OF CENTERLINE,
2 FT AGL/3951 FT MSL.
ELECTRICAL SYSTEM 10 FT FROM DER, 55 FT RIGHT OF CENTERLINE, 2 FT
AGL/3951 FT MSL.
POLE 291 FT FROM DER, 406 FT RIGHT OF CENTERLINE, 35 FT AGL/3984 FT
MSL.
RWY 30, ELECTRICAL SYSTEM 9 FT FROM DER, 54 FT RIGHT OF CENTERLINE,
2 FT AGL/3964 FT MSL.
ELECTRICAL SYSTEM 9 FT FROM DER, 55 FT LEFT OF CENTERLINE, 2 FT
AGL/3963 FT MSL. ALL OTHER DATA REMAINS AS PUBLISHED.
2403271738-2603271738EST
END PART 2 OF 2
|
