10/2/231757Z
|
!FDC 3/8555 CAR PART 1 OF 3 ODP CARIBOU MUNI, CARIBOU, ME.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1...
TAKEOFF OBSTACLE NOTES: RWY 1, TREE 53 FT FROM DER, 365 FT RIGHT
OF CENTERLINE, 634 FT MSL.
TERRAIN 162 FT FROM DER, 339 FT LEFT OF CENTERLINE, 628 FT MSL.
TREE 178 FT FROM DER, 298 FT RIGHT OF CENTERLINE, 641 FT MSL.
TREE 320 FT FROM DER, 429 FT RIGHT OF CENTERLINE, 648 FT MSL.
TREE 334 FT FROM DER, 576 FT RIGHT OF CENTERLINE, 653 FT MSL.
TERRAIN 369 FT FROM DER, 407 FT LEFT OF CENTERLINE, 633 FT MSL.
TREE 401 FT FROM DER, 521 FT RIGHT OF CENTERLINE, 655 FT MSL.
TREES, TRAVERSE WAYS BEGINNING 441 FT FROM DER, 31 FT RIGHT OF
CENTERLINE, UP TO 656 FT MSL.
TERRAIN 568 FT FROM DER, 485 FT LEFT OF CENTERLINE, 640 FT MSL.
TERRAIN 749 FT FROM DER, 648 FT LEFT OF CENTERLINE, 652 FT MSL.
TERRAINS BEGINNING 908 FT FROM DER, 391 FT LEFT OF CENTERLINE, UP
TO 654 FT MSL.
TERRAINS BEGINNING 1118 FT FROM DER, 366 FT LEFT OF CENTERLINE, UP
TO 659 FT MSL.
TERRAINS BEGINNING 1282 FT FROM DER, 560 FT LEFT OF CENTERLINE, UP
TO 664 FT MSL.
TERRAINS BEGINNING 1495 FT FROM DER, 564 FT LEFT OF CENTERLINE, UP
2310021757-2510021757EST
END PART 1 OF 3
!FDC 3/8555 CAR PART 2 OF 3 ODP CARIBOU MUNI, CARIBOU, ME.
TO 668 FT MSL.
RWY 11, TERRAIN 57 FT FROM DER, 164 FT LEFT OF CENTERLINE, 625 FT
MSL.
BUILDING 86 FT FROM DER, 275 FT LEFT OF CENTERLINE, 9 FT AGL/639 FT
MSL.
TERRAIN 105 FT FROM DER, 181 FT RIGHT OF CENTERLINE, 623 FT MSL.
BUILDING, TERRAINS, TRANSMISSION LINE, POLE BEGINNING 115 FT FROM
DER, 245 FT LEFT OF CENTERLINE, UP TO 23 FT AGL/655 FT MSL.
BUILDINGS, POLES, TREES, TRANSMISSION LINES, TRAVERSE WAYS
BEGINNING 132 FT FROM DER, 7 FT RIGHT OF CENTERLINE, UP TO 37 FT
AGL/661 FT MSL.
TRANSMISSION LINE, POLE, BUILDING, TERRAIN BEGINNING 331 FT FROM
DER, 158 FT LEFT OF CENTERLINE, UP TO 29 FT AGL/661 FT MSL.
TREES, TRANSMISSION LINES, POLES, TRAVERSE WAY, SIGN, BUILDINGS
BEGINNING 360 FT FROM DER, 10 FT LEFT OF CENTERLINE, UP TO 678 FT
MSL.
TREES, BUILDING, POLE, TRANSMISSION LINE BEGINNING 624 FT FROM DER,
45 FT RIGHT OF CENTERLINE, UP TO 664 FT MSL.
RWY 19, POLE 10 FT FROM DER, 439 FT LEFT OF CENTERLINE, 13 FT
AGL/638 FT MSL.
2310021757-2510021757EST
END PART 2 OF 3
!FDC 3/8555 CAR PART 3 OF 3 ODP CARIBOU MUNI, CARIBOU, ME.
POLES, TERRAIN BEGINNING 18 FT FROM DER, 183 FT LEFT OF CENTERLINE,
UP TO 15 FT AGL/639 FT MSL.
TREES, POLES, TRANSMISSION LINES BEGINNING 71 FT FROM DER, 9 FT
RIGHT OF CENTERLINE, UP TO 659 FT MSL.
BUILDINGS, POLES, TERRAINS, TREES BEGINNING 89 FT FROM DER, 192 FT
LEFT OF CENTERLINE, UP TO 37 FT AGL/661 FT MSL.
TREES, TRANSMISSION LINES, POLES, BUILDING, TANK BEGINNING 528 FT
FROM DER, 76 FT LEFT OF CENTERLINE, UP TO 675 FT MSL.
2310021757-2510021757EST
END PART 3 OF 3
|
