8/9/231259Z
|
!FDC 3/0848 COM PART 1 OF 2 ODP COLEMAN MUNI, COLEMAN, TX.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
CHANGE TAKEOFF OBSTACLE NOTES TO READ:
NOTE: RWY 15: FENCE 28 FT FROM DER, 315 FT LEFT OF CENTERLINE, 1681
FT MSL.
FENCES BEGINNING 36 FT FROM DER, 393 FT RIGHT OF CENTERLINE, UP TO
7 FT AGL/1685 FT MSL.
TRAVERSE WAYS BEGINNING 440 FT FROM DER, 340 FT RIGHT OF
CENTERLINE, UP TO 1694 FT MSL.
TREES BEGINNING 730 FT FROM DER, 28 FT RIGHT OF CENTERLINE, UP TO
1700 FT MSL.
TERRAIN BEGINNING 4302 FT FROM DER, 1622 FT LEFT OF CENTERLINE, UP
TO 1903 FT MSL.
TERRAIN BEGINNING 4756 FT FROM DER, 1725 FT RIGHT OF CENTERLINE, UP
TO 1874 FT MSL.
NOTE: RWY 33: POLE 2 FT FROM DER, 17 FT RIGHT OF CENTERLINE, 1698
FT MSL.
TRAVERSE WAY 6 FT FROM DER, 499 FT LEFT OF CENTERLINE, 15 FT
AGL/1714 FT MSL.
POLE, TRAVERSE WAYS, TREE BEGINNING 88 FT FROM DER, 30 FT LEFT OF
CENTERLINE, UP TO 1724 FT MSL.
TO 1916 FT MSL. 2308091259-2508091258EST
END PART 1 OF 2
!FDC 3/0848 COM PART 2 OF 2 ODP COLEMAN MUNI, COLEMAN, TX.
TREE, TRAVERSE WAY BEGINNING 485 FT FROM DER, 382 FT RIGHT OF
CENTERLINE, UP TO 1724 FT MSL.
TREES, POLES BEGINNING 561 FT FROM DER, 339 FT RIGHT OF CENTERLINE,
UP TO 1736 FT MSL.
TREES BEGINNING 680 FT FROM DER, 531 FT LEFT OF CENTERLINE, UP TO
1730 FT MSL.
TREES, POLE BEGINNING 808 FT FROM DER, 501 FT LEFT OF CENTERLINE,
UP TO 1740 FT MSL.
POLES, BUILDING BEGINNING 1045 FT FROM DER, 253 FT LEFT OF
CENTERLINE, UP TO 1743 FT MSL.
CRANE, POLES BEGINNING 1918 FT FROM DER, 120 FT LEFT OF CENTERLINE,
UP TO 42 FT AGL/1755 FT MSL.
POLE 2279 FT FROM DER, 9 FT RIGHT OF CENTERLINE, 45 FT AGL/1757 FT
MSL.
POLE 2340 FT FROM DER, 464 FT LEFT OF CENTERLINE, 42 FT AGL/1756 FT
MSL.
TERRAIN BEGINNING 4408 FT FROM DER, 1667 FT LEFT OF CENTERLINE, UP
TO 1992 FT MSL.
TERRAIN BEGINNING 5138 FT FROM DER, 1807 FT RIGHT OF CENTERLINE, UP
TO 1916 FT MSL. 2308091259-2508091258EST
END PART 2 OF 2
|
