12/20/241239Z
|
!FDC 4/9269 CRT PART 1 OF 3 ODP Z M JACK STELL FLD, CROSSETT, AR.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG-A...
CHANGE TAKEOFF OBSTACLE NOTES TO READ:
NOTE: RWY 5: TRAVERSE WAY 44 FT FROM DER, 503 FT RIGHT OF
CENTERLINE, 194 FT MSL.
POLE 78 FT FROM DER, 367 FT LEFT OF CENTERLINE, 27 FT AGL/209 FT
MSL.
POLES, TRAVERSE WAY BEGINNING 401 FT FROM DER, 92 FT LEFT OF
CENTERLINE, UP TO 31 FT AGL/213 FT MSL.
TRAVERSE WAY 432 FT FROM DER, 3 FT RIGHT OF CENTERLINE, 195 FT MSL.
POLES BEGINNING 722 FT FROM DER, 402 FT LEFT OF CENTERLINE, UP TO
36 FT AGL/219 FT MSL.
TREES BEGINNING 1987 FT FROM DER, 397 FT LEFT OF CENTERLINE, UP TO
76 FT AGL/256 FT MSL.
TREE 2113 FT FROM DER, 847 FT RIGHT OF CENTERLINE, 100 FT AGL/278
FT MSL.
TREES BEGINNING 2445 FT FROM DER, 291 FT RIGHT OF CENTERLINE, UP TO
102 FT AGL/279 FT MSL.
TREES BEGINNING 2623 FT FROM DER, 168 FT LEFT OF CENTERLINE, UP TO
81 FT AGL/264 FT MSL.
TREE 3350 FT FROM DER, 1380 FT LEFT OF CENTERLINE, 99 FT AGL/281 FT
ALL OTHER DATA REMAINS AS PUBLISHED. 2412201239-2612201238EST
END PART 1 OF 3
!FDC 4/9269 CRT PART 2 OF 3 ODP Z M JACK STELL FLD, CROSSETT, AR.
MSL.
TREE 3358 FT FROM DER, 959 FT RIGHT OF CENTERLINE, 107 FT AGL/281
FT MSL.
TREES BEGINNING 3565 FT FROM DER, 365 FT RIGHT OF CENTERLINE, UP TO
115 FT AGL/293 FT MSL.
TREE 3806 FT FROM DER, 1177 FT LEFT OF CENTERLINE, 106 FT AGL/289
FT MSL.
TERRAIN BEGINNING 5209 FT FROM DER, 1836 FT RIGHT OF CENTERLINE, UP
TO 381 FT MSL.
TERRAIN BEGINNING 5484 FT FROM DER, 1807 FT LEFT OF CENTERLINE, UP
TO 200 FT AGL/381 FT MSL.
NOTE: RWY 23: TREES BEGINNING 38 FT FROM DER, 335 FT RIGHT OF
CENTERLINE, UP TO 45 FT AGL/222 FT MSL.
TANK, BUILDING BEGINNING 152 FT FROM DER, 473 FT LEFT OF
CENTERLINE, UP TO 7 FT AGL/187 FT MSL.
BUILDING 216 FT FROM DER, 473 FT LEFT OF CENTERLINE, 8 FT AGL/188
FT MSL.
POLE 453 FT FROM DER, 573 FT LEFT OF CENTERLINE, 27 FT AGL/206 FT
MSL.
TREE, POLE BEGINNING 550 FT FROM DER, 408 FT LEFT OF CENTERLINE, UP
ALL OTHER DATA REMAINS AS PUBLISHED. 2412201239-2612201238EST
END PART 2 OF 3
!FDC 4/9269 CRT PART 3 OF 3 ODP Z M JACK STELL FLD, CROSSETT, AR.
TO 44 FT AGL/223 FT MSL.
TREE 660 FT FROM DER, 498 FT LEFT OF CENTERLINE, 50 FT AGL/227 FT
MSL.
TREES BEGINNING 787 FT FROM DER, 13 FT LEFT OF CENTERLINE, UP TO 56
FT AGL/232 FT MSL.
TREE 1079 FT FROM DER, 333 FT RIGHT OF CENTERLINE, 54 FT AGL/223 FT
MSL.
TREES BEGINNING 1269 FT FROM DER, 268 FT RIGHT OF CENTERLINE, UP TO
60 FT AGL/228 FT MSL.
TREE 1622 FT FROM DER, 178 FT RIGHT OF CENTERLINE, 68 FT AGL/236 FT
MSL.
TREE 2263 FT FROM DER, 278 FT RIGHT OF CENTERLINE, 84 FT AGL/251 FT
MSL.
TREE 3336 FT FROM DER, 273 FT RIGHT OF CENTERLINE, 101 FT AGL/264
FT MSL.
TERRAIN BEGINNING 4536 FT FROM DER, 1689 FT RIGHT OF CENTERLINE, UP
TO 374 FT MSL.
TERRAIN BEGINNING 4624 FT FROM DER, 1716 FT LEFT OF CENTERLINE, UP
TO 378 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2412201239-2612201238EST
END PART 3 OF 3
|
