| Domestic |
|
12/23/240546Z
|
!MCN 12/605 DBN OBST TOWER LGT (ASR 1254074) 323713.70N0825926.70W (3.3NM N DBN) 618.1FT (310.0FT AGL) U/S 2412230546-2501062359
|
|
12/22/242348Z
|
!MCN 12/601 DBN OBST TOWER LGT (ASR 1224835) 323116.40N0830505.80W (5.8NM WSW DBN) 595.8FT (259.8FT AGL) U/S 2412222348-2501051300
|
|
12/14/241221Z
|
!MCN 12/383 DBN OBST TOWER LGT (ASR 1254372) 322510.30N0825620.60W (9.0NM SSE DBN) 588.6FT (326.8FT AGL) U/S 2412141221-2504122359
|
|
12/12/242057Z
|
!MCN 12/353 DBN NAV ILS RWY 02 LOC/GP/DME U/S 2412122057-2412271100
|
|
11/13/242107Z
|
!MCN 11/404 DBN OBST TOWER LGT (ASR 1020278) 324928.70N0831034.20W (18.1NM NNW DBN) 860.6FT (411.1FT AGL) U/S 2411132107-2412282107
|
|
11/8/240027Z
|
!MCN 11/236 DBN OBST TOWER LGT (ASR 1273671) 322931.40N0825531.80W (5.2NM SE DBN) 574.8FT (299.9FT AGL) U/S 2411080027-2503072359
|
|
10/29/242223Z
|
!MCN 10/956 DBN OBST TOWER LGT (ASR 1020278) 324928.70N0831034.20W (18.1NM NNW DBN) 860.6FT (411.1FT AGL) U/S 2410292223-2501312359
|
|
9/27/241158Z
|
!MCN 09/253 DBN OBST TOWER LGT (ASR 1224511) 322750.90N0824731.80W (11.4NM ESE DBN) 443.9FT (259.8FT AGL) U/S 2409271158-2412262359
|
| FDC |
|
12/4/241751Z
|
!FDC 4/1647 DBN IAP W H 'BUD'
BARRON, DUBLIN, GA.
ILS OR LOC RWY 2, AMDT 3...
ALTERNATE MINIMUMS NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV
SYSTEM WITH GPS,
VNA VOR UNMONITORED. 2412041751-2501041751EST
|
|
11/25/241448Z
|
!FDC 4/8407 DBN IAP W H 'BUD' BARRON, DUBLIN, GA.
ILS OR LOC RWY 2, AMDT 3...
PROCEDURE NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM
WITH GPS,
DBN VOR OUT OF SERVICE. 2411251448-2507071448EST
|
|
9/12/231738Z
|
!FDC 3/9165 DBN IAP W H 'BUD' BARRON, DUBLIN, GA.
ILS OR LOC RWY 2, AMDT 3...
RNAV (GPS) RWY 2, AMDT 1...
CIRCLING CAT B MDA 900/HAA 589.
2309121738-2509121738EST
|
|
9/12/231738Z
|
!FDC 3/9164 DBN IAP W H 'BUD' BARRON, DUBLIN, GA.
RNAV (GPS) RWY 20, AMDT 1...
LNAV/VNAV DA 915/HAT 606 ALL CATS, VIS ALL CATS 1 3/4. LNAV MDA
860/HAT 551 ALL CATS, VIS CAT C/D 1 5/8. CIRCLING CAT A MDA
860/HAA 549, CAT B MDA 900/HAA 589. DISREGARD TUFTY FIX AND TUFTY
FIX ALTITUDE. VDP 1.6 NM TO RW20. CHANGE NOTE TO READ: WHEN LOCAL
ALTIMETER SETTING NOT RECEIVED, USE VIDALIA ALTIMETER SETTING;
INCREASE LPV DA TO 681 FEET AND LNAV/VNAV DA TO 1009 FEET AND ALL
MDA 100 FEET; INCREASE LPV ALL CATS VISIBILITY 1/4 MILE AND
LNAV/VNAV ALL CATS VISIBLITY 1/4 MILE AND LNAV CAT C/D AND CIRCLING
CAT C/D VISIBILITY 1/4 MILE.
2309121738-2509121738EST
|
|
9/12/231418Z
|
!FDC 3/8938 DBN PART 1 OF 4 ODP W H 'BUD' BARRON, DUBLIN, GA.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1...
TAKEOFF MINIMUMS:
RWY 2: 300-1 7/8 OR STANDARD WITH MINIMUM CLIMB OF 251 FT PER NM TO
700.
RWY 14, 20, 32: STANDARD.
CHANGE TAKEOFF OBSTACLE NOTES TO READ:
NOTE: RWY 2: VEHICLES ON ROAD, TREES BEGINNING 211 FT FROM DER, 1
FT LEFT OF CENTERLINE, UP TO 320 FT MSL.
TREES BEGINNING 648 FT FROM DER, 526 FT RIGHT OF CENTERLINE, UP TO
347 FT MSL.
TREES BEGINNING 1158 FT FROM DER, 381 FT RIGHT OF CENTERLINE, UP TO
372 FT MSL.
TREES BEGINNING 1574 FT FROM DER, 696 FT LEFT OF CENTERLINE, UP TO
396 FT MSL.
TREES BEGINNING 1759 FT FROM DER, 12 FT LEFT OF CENTERLINE, UP TO
406 FT MSL.
TREES BEGINNING 1851 FT FROM DER, 82 FT RIGHT OF CENTERLINE, UP TO
389 FT MSL.
TOWER 1.5 NM FROM DER, 1333 FT RIGHT OF CENTERLINE, 265 FT AGL/599
FT MSL.
2309121418-2509121417EST
END PART 1 OF 4
!FDC 3/8938 DBN PART 2 OF 4 ODP W H 'BUD' BARRON, DUBLIN, GA.
NOTE: RWY 14: TREES BEGINNING 1536 FT FROM DER, 63 FT LEFT OF
CENTERLINE, UP TO 353 FT MSL.
TREES BEGINNING 1565 FT FROM DER, 130 FT RIGHT OF CENTERLINE, UP TO
364 FT MSL.
TREES BEGINNING 1597 FT FROM DER, 77 FT LEFT OF CENTERLINE, UP TO
385 FT MSL.
TREES BEGINNING 1664 FT FROM DER, 53 FT RIGHT OF CENTERLINE, UP TO
369 FT MSL.
TREES BEGINNING 1717 FT FROM DER, 27 FT LEFT OF CENTERLINE, UP TO
389 FT MSL.
TREES, ANTENNA BEGINNING 1788 FT FROM DER, 56 FT RIGHT OF
CENTERLINE, UP TO 383 FT MSL.
NOTE: RWY 20: SIGN, TREES BEGINNING 24 FT FROM DER, 249 FT LEFT OF
CENTERLINE, UP TO 293 FT MSL.
TREES BEGINNING 671 FT FROM DER, 616 FT RIGHT OF CENTERLINE, UP TO
333 FT MSL.
TREES BEGINNING 837 FT FROM DER, 577 FT RIGHT OF CENTERLINE, UP TO
343 FT MSL.
TREES BEGINNING 2111 FT FROM DER, 764 FT LEFT OF CENTERLINE, UP TO
354 FT MSL.
2309121418-2509121417EST
END PART 2 OF 4
!FDC 3/8938 DBN PART 3 OF 4 ODP W H 'BUD' BARRON, DUBLIN, GA.
TREES BEGINNING 2303 FT FROM DER, 785 FT RIGHT OF CENTERLINE, UP TO
370 FT MSL.
TREES BEGINNING 2401 FT FROM DER, 533 FT LEFT OF CENTERLINE, UP TO
357 FT MSL.
TREES BEGINNING 2463 FT FROM DER, 747 FT RIGHT OF CENTERLINE, UP TO
378 FT MSL.
NOTE: RWY 32: TREES BEGINNING 797 FT FROM DER, 58 FT RIGHT OF
CENTERLINE, UP TO 353 FT MSL.
TREES BEGINNING 898 FT FROM DER, 279 FT LEFT OF CENTERLINE, UP TO
339 FT MSL.
TREES BEGINNING 1411 FT FROM DER, 145 FT LEFT OF CENTERLINE, UP TO
344 FT MSL.
TREES BEGINNING 1506 FT FROM DER, 126 FT RIGHT OF CENTERLINE, UP TO
352 FT MSL.
TREES BEGINNING 1667 FT FROM DER, 8 FT RIGHT OF CENTERLINE, UP TO
397 FT MSL.
TREES BEGINNING 2066 FT FROM DER, 62 FT LEFT OF CENTERLINE, UP TO
363 FT MSL.
TREES BEGINNING 2734 FT FROM DER, 5 FT LEFT OF CENTERLINE, UP TO
386 FT MSL.
2309121418-2509121417EST
END PART 3 OF 4
!FDC 3/8938 DBN PART 4 OF 4 ODP W H 'BUD' BARRON, DUBLIN, GA.
TREES BEGINNING 3027 FT FROM DER, 73 FT RIGHT OF CENTERLINE, UP TO
409 FT MSL.
TREES BEGINNING 3452 FT FROM DER, 164 FT LEFT OF CENTERLINE, UP TO
394 FT MSL.
TREE 4396 FT FROM DER, 323 FT LEFT OF CENTERLINE, 421 FT MSL.
2309121418-2509121417EST
END PART 4 OF 4
|
