| FDC |
|
12/6/240624Z
|
!FDC 4/2730 DEQ IAP J LYNN HELMS SEVIER COUNTY,
DE QUEEN, AR.
RNAV (GPS) RWY 8, ORIG-C...
CIRCLING CAT B MDA 920/HAA 565. CHART NOTE: CIRCLING RWY 26 NA AT
NIGHT. PBN REQUIREMENTS NOTE: RNP APCH - GPS. CHANGE BACKUP
ALTIMETER NOTE TO READ: WHEN LOCAL ALTIMETER SETTING NOT RECEIVED,
USE TXK ALTIMETER AND INCREASE ALL MDAS 100 FEET.
THIS IS RNAV (GPS) RWY 8, ORIG-D. 2412060624-PERM
|
|
8/1/232026Z
|
!FDC 3/6507 DEQ PART 1 OF 2 ODP J LYNN HELMS SEVIER COUNTY,
DE QUEEN, AR.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1A...
NOTE: RWY 8: TERRAIN, TOWER BEGINNING 54 FT FROM DER, 110 FT RIGHT
OF CENTERLINE, UP TO 200 FT AGL/647 FT MSL.
TERRAIN BEGINNING 123 FT FROM DER, 161 FT LEFT OF CENTERLINE, UP TO
657 FT MSL.
NOTE: RWY 26: TREE 125 FT FROM DER, 448 FT LEFT OF CENTERLINE, 410
FT MSL.
TREES, POLE BEGINNING 147 FT FROM DER, 399 FT LEFT OF CENTERLINE,
UP TO 414 FT MSL.
TREES BEGINNING 240 FT FROM DER, 343 FT RIGHT OF CENTERLINE, UP TO
434 FT MSL.
TREES, POLE BEGINNING 464 FT FROM DER, 296 FT LEFT OF CENTERLINE,
UP TO 415 FT MSL.
TREES, POLE BEGINNING 1160 FT FROM DER, 98 FT RIGHT OF CENTERLINE,
UP TO 436 FT MSL.
TREES BEGINNING 1407 FT FROM DER, 286 FT LEFT OF CENTERLINE, UP TO
427 FT MSL.
TERRAIN BEGINNING 4751 FT FROM DER, 1730 FT LEFT OF CENTERLINE, UP
TO 545 FT MSL.
TERRAIN BEGINNING 5841 FT FROM DER, 2058 FT RIGHT OF CENTERLINE, UP
ALL OTHER DATA REMAINS AS PUBLISHED. 2308012026-2508012025EST
END PART 1 OF 2
!FDC 3/6507 DEQ PART 2 OF 2 ODP J LYNN HELMS SEVIER COUNTY,
DE QUEEN, AR.
TO 538 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2308012026-2508012025EST
END PART 2 OF 2
|
