| Domestic |
|
10/28/241455Z
|
!DYL 10/013 DYL OBST TOWER LGT (ASR 1039590) 401936.00N0750938.00W (1.8NM WSW DYL) 506.6FT (206.7FT AGL) U/S 2410281455-2412312359
|
| FDC |
|
5/8/241228Z
|
!FDC 4/0565 DYL IAP DOYLESTOWN, DOYLESTOWN, PA.
VOR-A, ORIG...
PROCEDURE NA.
2405081228-2605081228EST
|
|
8/23/231813Z
|
!FDC 3/0037 DYL PART 1 OF 2 ODP DOYLESTOWN, DOYLESTOWN, PA.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 2...
NOTE: RWY 5: TERRAIN 65 FT FROM DER, 401 FT RIGHT OF CENTERLINE,
397 FT MSL.
BUILDING 74 FT FROM DER, 320 FT LEFT OF CENTERLINE, 401 FT MSL.
POLE 100 FT FROM DER, 424 FT LEFT OF CENTERLINE, 408 FT MSL.
TREES, TRAVERSE WAYS, POLE BEGINNING 150 FT FROM DER, 150 FT RIGHT
OF CENTERLINE, UP TO 57 FT AGL/456 FT MSL.
POLE 221 FT FROM DER, 446 FT LEFT OF CENTERLINE, 45 FT AGL/418 FT
MSL.
TREES BEGINNING 260 FT FROM DER, 298 FT LEFT OF CENTERLINE, UP TO
435 FT MSL.
TREES BEGINNING 473 FT FROM DER, 426 FT LEFT OF CENTERLINE, UP TO
442 FT MSL.
TREE, BUILDING BEGINNING 635 FT FROM DER, 232 FT LEFT OF
CENTERLINE, UP TO 459 FT MSL.
TREES BEGINNING 762 FT FROM DER, 330 FT LEFT OF CENTERLINE, UP TO
471 FT MSL.
TREES BEGINNING 963 FT FROM DER, 43 FT LEFT OF CENTERLINE, UP TO
484 FT MSL.
TREES BEGINNING 1210 FT FROM DER, 288 FT RIGHT OF CENTERLINE, UP TO
ALL OTHER DATA REMAINS AS PUBLISHED. 2308231813-2508231812EST
END PART 1 OF 2
!FDC 3/0037 DYL PART 2 OF 2 ODP DOYLESTOWN, DOYLESTOWN, PA.
485 FT MSL.
TREES BEGINNING 1643 FT FROM DER, 19 FT RIGHT OF CENTERLINE, UP TO
106 FT AGL/494 FT MSL.
TERRAIN BEGINNING 2.2 NM FROM DER, 4155 FT LEFT OF CENTERLINE, UP
TO 771 FT MSL.
NOTE: RWY 23: TREES, POLES BEGINNING 13 FT FROM DER, 11 FT RIGHT OF
CENTERLINE, UP TO 76 FT AGL/455 FT MSL.
BUILDING 33 FT FROM DER, 405 FT LEFT OF CENTERLINE, 401 FT MSL.
BUILDING 482 FT FROM DER, 261 FT LEFT OF CENTERLINE, 407 FT MSL.
TREE 729 FT FROM DER, 270 FT LEFT OF CENTERLINE, 417 FT MSL.
TREE 810 FT FROM DER, 537 FT LEFT OF CENTERLINE, 427 FT MSL.
TREES, POLE BEGINNING 832 FT FROM DER, 190 FT LEFT OF CENTERLINE,
UP TO 435 FT MSL.
TREES BEGINNING 1006 FT FROM DER, 201 FT LEFT OF CENTERLINE, UP TO
438 FT MSL.
TREE 1227 FT FROM DER, 523 FT LEFT OF CENTERLINE, 439 FT MSL.
TREES BEGINNING 1327 FT FROM DER, 83 FT LEFT OF CENTERLINE, UP TO
469 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2308231813-2508231812EST
END PART 2 OF 2
|
