8/11/231945Z
|
!FDC 3/2967 EOP PART 1 OF 3 ODP PIKE COUNTY, WAVERLY, OH.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1...
TAKEOFF OBSTACLE NOTES: RWY 7: FENCE, LIGHT POLE BEGINNING 1 FT
FROM DER, 75 FT RIGHT OF CENTERLINE, UP TO 668 FT MSL.
LIGHT POLE 39 FT FROM DER, 78 FT LEFT OF CENTERLINE, 663 FT MSL.
FENCE 88 FT FROM DER, 462 FT LEFT OF CENTERLINE, 670 FT MSL.
TREE 95 FT FROM DER, 487 FT RIGHT OF CENTERLINE, 24 FT AGL/679 FT
MSL.
FENCE 198 FT FROM DER, 462 FT LEFT OF CENTERLINE, 671 FT MSL.
TREE 237 FT FROM DER, 516 FT LEFT OF CENTERLINE, 701 FT MSL.
TREE 368 FT FROM DER, 506 FT LEFT OF CENTERLINE, 715 FT MSL.
TREES, BUILDINGS BEGINNING 435 FT FROM DER, 286 FT RIGHT OF
CENTERLINE, UP TO 732 FT MSL.
TREES BEGINNING 566 FT FROM DER, 332 FT LEFT OF CENTERLINE, UP TO
721 FT MSL.
TREES BEGINNING 641 FT FROM DER, 568 FT LEFT OF CENTERLINE, UP TO
741 FT MSL.
TREES BEGINNING 965 FT FROM DER, 323 FT LEFT OF CENTERLINE, UP TO
751 FT MSL.
TREES BEGINNING 2400 FT FROM DER, 1048 FT RIGHT OF CENTERLINE, UP
TO 734 FT MSL.
115 FT AGL/769 FT MSL. 2308111945-2508101945EST
END PART 1 OF 3
!FDC 3/2967 EOP PART 2 OF 3 ODP PIKE COUNTY, WAVERLY, OH.
TREE 2650 FT FROM DER, 1202 FT RIGHT OF CENTERLINE, 736 FT MSL.
TREE 2923 FT FROM DER, 494 FT LEFT OF CENTERLINE, 752 FT MSL. RWY
25: LIGHT POLE 39 FT FROM DER, 79 FT LEFT OF CENTERLINE, 662 FT
MSL.
LIGHT POLE 40 FT FROM DER, 78 FT RIGHT OF CENTERLINE, 662 FT MSL.
ANTENNA 56 FT FROM DER, 474 FT LEFT OF CENTERLINE, 699 FT MSL.
TREES, TRAVERSE WAY BEGINNING 80 FT FROM DER, 372 FT RIGHT OF
CENTERLINE, UP TO 67 FT AGL/722 FT MSL.
TREE 150 FT FROM DER, 265 FT RIGHT OF CENTERLINE, 80 FT AGL/737 FT
MSL.
LIGHT POLE, ANTENNA, FENCE, POLES, TRAVERSE WAYS, TREES BEGINNING
154 FT FROM DER, 97 FT LEFT OF CENTERLINE, UP TO 46 FT AGL/705 FT
MSL.
TREES, TRAVERSE WAYS, POLE BEGINNING 191 FT FROM DER, 1 FT RIGHT OF
CENTERLINE, UP TO 86 FT AGL/739 FT MSL.
TREE 930 FT FROM DER, 590 FT LEFT OF CENTERLINE, 710 FT MSL.
TREES BEGINNING 989 FT FROM DER, 266 FT LEFT OF CENTERLINE, UP TO
711 FT MSL.
TREES BEGINNING 1133 FT FROM DER, 319 FT LEFT OF CENTERLINE, UP TO
714 FT MSL.
115 FT AGL/769 FT MSL. 2308111945-2508101945EST
END PART 2 OF 3
!FDC 3/2967 EOP PART 3 OF 3 ODP PIKE COUNTY, WAVERLY, OH.
TREES BEGINNING 1317 FT FROM DER, 216 FT LEFT OF CENTERLINE, UP TO
728 FT MSL.
TREES BEGINNING 1548 FT FROM DER, 59 FT LEFT OF CENTERLINE, UP TO
729 FT MSL.
TREES BEGINNING 1670 FT FROM DER, 75 FT LEFT OF CENTERLINE, UP TO
734 FT MSL.
TREES BEGINNING 1795 FT FROM DER, 233 FT LEFT OF CENTERLINE, UP TO
737 FT MSL.
TREE 2155 FT FROM DER, 332 FT LEFT OF CENTERLINE, 745 FT MSL.
TREES BEGINNING 2173 FT FROM DER, 134 FT LEFT OF CENTERLINE, UP TO
748 FT MSL.
TREES BEGINNING 2310 FT FROM DER, 210 FT LEFT OF CENTERLINE, UP TO
757 FT MSL.
TREES BEGINNING 2582 FT FROM DER, 343 FT LEFT OF CENTERLINE, UP TO
758 FT MSL.
TREES BEGINNING 2783 FT FROM DER, 498 FT LEFT OF CENTERLINE, UP TO
760 FT MSL.
TREES BEGINNING 2859 FT FROM DER, 384 FT LEFT OF CENTERLINE, UP TO
766 FT MSL.
TREES BEGINNING 2955 FT FROM DER, 475 FT LEFT OF CENTERLINE, UP TO
115 FT AGL/769 FT MSL. 2308111945-2508101945EST
END PART 3 OF 3
|
