| FDC |
|
10/7/241922Z
|
!FDC 4/6044 ETB IAP WEST BEND MUNI, WEST BEND, WI.
RNAV (GPS) RWY 31, ORIG-B...
CHANGE CHART NOTE TO READ: FOR UNCOMPENSATED BARO-VNAV SYSTEMS,
LNAV/VNAV NA BELOW -16C OR ABOVE 47C.
DELETE PROFILE NOTE: VGSI AND RNAV GLIDEPATH NOT COINCIDENT (VGSI
ANGLE 3.00/TCH 28).
CHANGE CHART NOTE TO READ: CIRCLING RWY 6 NA AT NIGHT..
THIS IS RNAV (GPS) RWY 31, ORIG-C. 2410071922-PERM
|
|
6/27/232154Z
|
!FDC 3/7402 ETB ODP WEST BEND MUNI, WEST BEND, WI.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
TAKEOFF OBSTACLE NOTES: NOTE: RWY 6: TREE 2495 FT FROM DER, 1041 FT LEFT OF CENTERLINE, 979 FT MSL. TREE 2610 FT FROM DER, 1009 FT LEFT OF CENTERLINE, 986 FT MSL. NOTE: RWY 13: TREE 170 FT FROM DER, 545 FT LEFT OF CENTERLINE, 907 FT MSL. TREES BEGINNING 222 FT FROM DER, 413 FT RIGHT OF CENTERLINE, UP TO 917 FT MSL. TREE 227 FT FROM DER, 551 FT LEFT OF CENTERLINE, 911 FT MSL. TREES BEGINNING 412 FT FROM DER, 554 FT LEFT OF CENTERLINE, UP TO 917 FT MSL. NOTE: RWY 24: TREE 87 FT FROM DER, 118 FT RIGHT OF CENTERLINE, 900 FT MSL. TREES BEGINNING 108 FT FROM DER, 75 FT LEFT OF CENTERLINE, UP TO 895 FT MSL. NOTE: RWY 31: TRAVERSE WAY 70 FT FROM DER, 476 FT RIGHT OF CENTERLINE, 896 FT MSL. TRAVERSE WAY BEGINNING 87 FT FROM DER, 449 FT LEFT OF CENTERLINE, UP TO 889 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2306272154-2506272154EST
|
