!FDC 3/6732 EZS PART 1 OF 6 ODP SHAWANO MUNI, SHAWANO, WI.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 2A...
TAKEOFF OBSTACLE NOTES: RWY 12: LIGHT POLE 13 FT FROM DER, 78 FT
LEFT OF CENTERLINE, 3 FT AGL/813 FT MSL.
TREE, FENCE BEGINNING 47 FT FROM DER, 309 FT RIGHT OF CENTERLINE,
UP TO 29 FT AGL/837 FT MSL.
FENCE 60 FT FROM DER, 310 FT LEFT OF CENTERLINE, 9 FT AGL/815 FT
MSL.
TREES BEGINNING 157 FT FROM DER, 466 FT RIGHT OF CENTERLINE, UP TO
878 FT MSL.
TREE, FENCE BEGINNING 167 FT FROM DER, 309 FT LEFT OF CENTERLINE,
UP TO 821 FT MSL.
TREES BEGINNING 745 FT FROM DER, 29 FT LEFT OF CENTERLINE, UP TO
894 FT MSL.
TREES BEGINNING 848 FT FROM DER, 261 FT RIGHT OF CENTERLINE, UP TO
74 FT AGL/884 FT MSL.
TREES BEGINNING 1315 FT FROM DER, 165 FT RIGHT OF CENTERLINE, UP TO
890 FT MSL.
TREES BEGINNING 1984 FT FROM DER, 57 FT RIGHT OF CENTERLINE, UP TO
86 FT AGL/896 FT MSL.
TREES BEGINNING 2505 FT FROM DER, 13 FT LEFT OF CENTERLINE, UP TO
MSL. 2307141757-2507141757EST
END PART 1 OF 6
!FDC 3/6732 EZS PART 2 OF 6 ODP SHAWANO MUNI, SHAWANO, WI.
903 FT MSL.
TREES BEGINNING 2759 FT FROM DER, ON AND RIGHT OF CENTERLINE, UP TO
83 FT AGL/897 FT MSL.
TREES BEGINNING 2836 FT FROM DER, 4 FT LEFT OF CENTERLINE, UP TO 99
FT AGL/907 FT MSL.
TREES BEGINNING 2884 FT FROM DER, 54 FT RIGHT OF CENTERLINE, UP TO
907 FT MSL.
TREE 3528 FT FROM DER, 621 FT LEFT OF CENTERLINE, 908 FT MSL.
RWY 17: TREE 339 FT FROM DER, 582 FT LEFT OF CENTERLINE, 825 FT
MSL.
TREE 369 FT FROM DER, 517 FT RIGHT OF CENTERLINE, 72 FT AGL/882 FT
MSL.
TREES BEGINNING 374 FT FROM DER, 9 FT RIGHT OF CENTERLINE, UP TO 73
FT AGL/884 FT MSL.
TREE 453 FT FROM DER, 560 FT LEFT OF CENTERLINE, 827 FT MSL.
TREE 456 FT FROM DER, 393 FT LEFT OF CENTERLINE, 20 FT AGL/829 FT
MSL.
TREES BEGINNING 503 FT FROM DER, 406 FT LEFT OF CENTERLINE, UP TO
46 FT AGL/854 FT MSL.
TREES BEGINNING 626 FT FROM DER, 1 FT LEFT OF CENTERLINE, UP TO 48
MSL. 2307141757-2507141757EST
END PART 2 OF 6
!FDC 3/6732 EZS PART 3 OF 6 ODP SHAWANO MUNI, SHAWANO, WI.
FT AGL/857 FT MSL.
TREES BEGINNING 688 FT FROM DER, 101 FT LEFT OF CENTERLINE, UP TO
70 FT AGL/881 FT MSL.
TREE 1163 FT FROM DER, 458 FT LEFT OF CENTERLINE, 80 FT AGL/891 FT
MSL.
TREES BEGINNING 1168 FT FROM DER, 40 FT LEFT OF CENTERLINE, UP TO
87 FT AGL/896 FT MSL.
TREE 1196 FT FROM DER, 372 FT LEFT OF CENTERLINE, 88 FT AGL/898 FT
MSL.
TREES BEGINNING 1233 FT FROM DER, 3 FT LEFT OF CENTERLINE, UP TO 97
FT AGL/908 FT MSL.
TREES BEGINNING 1317 FT FROM DER, 25 FT LEFT OF CENTERLINE, UP TO
100 FT AGL/911 FT MSL.
TREES BEGINNING 1332 FT FROM DER, 8 FT RIGHT OF CENTERLINE, UP TO
82 FT AGL/894 FT MSL.
TREE 2009 FT FROM DER, 65 FT RIGHT OF CENTERLINE, 85 FT AGL/896 FT
MSL.
TREE 2071 FT FROM DER, 18 FT RIGHT OF CENTERLINE, 94 FT AGL/905 FT
MSL.
RWY 30: BUILDING, TRAVERSE WAY BEGINNING 15 FT FROM DER, 444 FT
MSL. 2307141757-2507141757EST
END PART 3 OF 6
!FDC 3/6732 EZS PART 4 OF 6 ODP SHAWANO MUNI, SHAWANO, WI.
RIGHT OF CENTERLINE, UP TO 26 FT AGL/835 FT MSL.
BUILDING 195 FT FROM DER, 517 FT LEFT OF CENTERLINE, 15 FT AGL/826
FT MSL.
BUILDING, FENCE BEGINNING 196 FT FROM DER, 329 FT LEFT OF
CENTERLINE, UP TO 29 FT AGL/840 FT MSL.
TREE 251 FT FROM DER, 460 FT RIGHT OF CENTERLINE, 874 FT MSL.
TREES BEGINNING 371 FT FROM DER, 339 FT RIGHT OF CENTERLINE, UP TO
82 FT AGL/891 FT MSL.
TREES, TRAVERSE WAYS BEGINNING 399 FT FROM DER, 8 FT LEFT OF
CENTERLINE, UP TO 70 FT AGL/880 FT MSL.
TREE, TRAVERSE WAY BEGINNING 437 FT FROM DER, 201 FT RIGHT OF
CENTERLINE, UP TO 893 FT MSL.
TREES, TRAVERSE WAYS, POLES BEGINNING 443 FT FROM DER, ON AND RIGHT
OF CENTERLINE, UP TO 94 FT AGL/901 FT MSL.
TREES BEGINNING 581 FT FROM DER, 470 FT LEFT OF CENTERLINE, UP TO
84 FT AGL/894 FT MSL.
TREES BEGINNING 679 FT FROM DER, 2 FT LEFT OF CENTERLINE, UP TO 84
FT AGL/897 FT MSL.
TREES BEGINNING 1144 FT FROM DER, 132 FT LEFT OF CENTERLINE, UP TO
90 FT AGL/904 FT MSL.
MSL. 2307141757-2507141757EST
END PART 4 OF 6
!FDC 3/6732 EZS PART 5 OF 6 ODP SHAWANO MUNI, SHAWANO, WI.
TREES BEGINNING 1228 FT FROM DER, 737 FT LEFT OF CENTERLINE, UP TO
118 FT AGL/932 FT MSL.
TREE 1248 FT FROM DER, 755 FT LEFT OF CENTERLINE, 119 FT AGL/933 FT
MSL.
TREES BEGINNING 1255 FT FROM DER, 1 FT LEFT OF CENTERLINE, UP TO
120 FT AGL/934 FT MSL.
TREES BEGINNING 1350 FT FROM DER, 234 FT RIGHT OF CENTERLINE, UP TO
98 FT AGL/906 FT MSL.
TREES BEGINNING 1560 FT FROM DER, 79 FT RIGHT OF CENTERLINE, UP TO
113 FT AGL/923 FT MSL.
TREES BEGINNING 1715 FT FROM DER, ON AND RIGHT OF CENTERLINE, UP
TO 125 FT AGL/935 FT MSL.
TREES BEGINNING 4654 FT FROM DER, 583 FT LEFT OF CENTERLINE, UP TO
134 FT AGL/953 FT MSL.
RWY 35: TREES, BUILDING, POLE BEGINNING 106 FT FROM DER, 450 FT
RIGHT OF CENTERLINE, UP TO 80 FT AGL/887 FT MSL.
TREES BEGINNING 247 FT FROM DER, 183 FT RIGHT OF CENTERLINE, UP TO
86 FT AGL/892 FT MSL.
TRAVERSE WAYS BEGINNING 443 FT FROM DER, 268 FT LEFT OF CENTERLINE,
UP TO 822 FT MSL.
MSL. 2307141757-2507141757EST
END PART 5 OF 6
!FDC 3/6732 EZS PART 6 OF 6 ODP SHAWANO MUNI, SHAWANO, WI.
BUILDINGS, TREE BEGINNING 503 FT FROM DER, 504 FT LEFT OF
CENTERLINE, UP TO 29 FT AGL/835 FT MSL.
TREES BEGINNING 899 FT FROM DER, 565 FT LEFT OF CENTERLINE, UP TO
64 FT AGL/869 FT MSL.
TREES BEGINNING 1835 FT FROM DER, 797 FT LEFT OF CENTERLINE, UP TO
78 FT AGL/882 FT MSL.
TREE 2230 FT FROM DER, 974 FT LEFT OF CENTERLINE, 82 FT AGL/888 FT
MSL. 2307141757-2507141757EST
