BUTTS AAF (FORT CARSON) - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

KFCS
BUTTS AAF (FORT CARSON)
PrivatePVT

3 miles S of FORT CARSON, CO
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
38° 40' 42"N 104° 45' 23"W
5874' MSL
6874' MSL
08E
None Listed
DENVER (DEN)
DENVER
DENVER (ZDV)
12/26/24-1/23/25
KFCS VFR
8:55 AM MST
Clear
10sm
26°F
1°F
30.15"Hg
070° 3kts
AO2 SLP253 T10361172 $
KFCS 221555Z AUTO 07003KT 10SM CLR M04/M17 A3015 RMK AO2 SLP253 T10361172 $

KFCS FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
-- --

ATIS

ATIS
Hours: 0700-2300
108.8

AWOS-3

AWOS-3
719-637-9696
125.0

Emergency

EMERG
121.5

Ground

GND/P
118.55

Tower

LCL/P
41.5
LCL/P
125.5

Other

FLT FLW
AVBL 24 HRS EXC THANKSGIVING AND XMAS
38.35
FLT FLW
AVBL 24 HRS EXC THANKSGIVING AND XMA
138.15
OPS
138.75
PMSV METRO
50.75

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

  • No Documents

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

KFCS
Wed, 1/22 5:00 AM MST
Wed, 1/22 5:00 AM MST - Thu, 1/23 11:00 AM MST
VFR
5:00 AM MST - 8:00 AM MST
Sky Clear
6sm
30.03"Hg
340° 12kts
Gusts 18kts
Severe, Clear Air, Occasional: 4,000 - 13,000'
VFR
Becoming 8:00 AM MST - 12:00 PM MST
Scattered 10,000'
6sm
30.09"Hg
340° 12kts
Gusts 18kts
VFR
Becoming 12:00 PM MST - 7:00 PM MST
Broken 5,000'
6sm
30.15"Hg
350° 15kts
Gusts 25kts
Light, In Cloud (Rime): 5,000-14,000'
Moderate, Clear Air, Occasional: 4,000 - 9,000'
VFR
Becoming 7:00 PM MST - 8:00 AM MST
Broken 5,000'
6sm
30.21"Hg
300° 9kts
Light, In Cloud (Rime): 5,000-14,000'
VFR
Becoming 8:00 AM MST - 11:00 AM MST
Few 10,000'
6sm
30.35"Hg
200° 10kts
TAF KFCS 221200Z 2212/2318 34012G18KT 9999 SKC 560409 QNH3003INS
   BECMG 2215/2216 34012G18KT 9999 SCT100 QNH3010INS
   BECMG 2219/2220 35015G25KT 9999 BKN050 620509 520009 QNH3015INS
   BECMG 2302/2303 30009KT 9999 BKN050 620509 QNH3020INS
   BECMG 2315/2316 20010KT 9999 FEW100 QNH3035INS TX01/2219Z TNM11/2213Z
KFCS
Domestic
1/3/251600Z !FCS 01/001 FCS AIRSPACE UAS WI AN AREA DEFINED AS 2.6NM RADIUS OF
384926.80N1044917.10W (5.8NM W COS) SFC-400FT AGL FRI TUE WED THU
1600-0200 2501031600-2502010200
Military
1/24/251600Z KFCS: 2-4 CONDUCTING FATCOW/FUELING OPS ON E RAMP FROM 1900-2300(1200-1600L). USE CAUTION FOR PERSONNEL AND EQUIPMENT IN THE VICINITY. POC: WO1 KARBO, 719-505-4818
1/23/250030Z R2601: 10TH SFG WILL CONDUCT STATIC LINE AND MFF OPERATIONS INTO DZ SULLIVAN WITH 1 C130 AIRCRAFT. STATIC LINE WILL BE FROM 2000 AGL AND MFF FROM 7999 AGL. NON-PARTICIPATING AIRCRAFT AVOID SULLIVAN DZ BY 1 MILE. POC SSG STEVENS 719-524-1161
1/22/251645Z M0044/25 NOTAMC M0785/24
1/22/251645Z KFCS: ALPHA TAXIWAY HELIPAD MARKINGS REMOVED AND REPLACED WITH HOVERPOINT MARKINGS. NO SHOULDERS ON ALPHA TAXIWAY.
1/22/251643Z M0042/25 NOTAMC M0791/24
1/22/250110Z RWY 13/31 PATCHY ICE BA FAIR.
1/22/250105Z CAUTION: RAMPS AND TAXIWAYS COVERED WITH SNOW AND ICE.
1/21/252219Z M0039/25 NOTAMC M0034/25
1/21/251700Z AIRBURST MOA AND RANGE 123 ACTIVE. PILOTS CONTACT AIRBURST TOWER FREQUENCIES 251.25 OR 126.2 WHEN FLYING IN THE VICINTY OF AIRBURST MOA, RANGE 123, OR RED DEVIL. ACTIVE/INACTIVE STATUS MAY CHANGE FREQUENTLY.
1/21/250700Z R2601: 6-17 ACS WILL CONDUCT ROTARY WING AND SUAS OPERATIONS IN OP6, OP BONKO, TA10, TA17, AND TA19 (IVO 13SEC 1546 7255). ALTITUDE FOR SUAS SFC-500 FT AGL. EXPECT HEAVY ROTARY WING TRAFFIC AIR 1,2, AND 3 SFC-1000 FT AGL. POC CW2 MCCAULEY 315-396-5559.
1/14/251700Z R2601: (DAILY 1700-2000 & 0100-0400). AFSOC GSU WILL CONDUCT SUAS OPERATIONS ON/FROM RED DEVIL AND/TO AIRBURST RANGE WITH 1 SUAS AIRCRAFT AT 4,000 FT AGL AND BELOW. UNIT WILL MAINTAIN CONTACT WITH RANGE CONTROL AND BUTTS ATC AT ALL TIMES. UNIT WILL NOT FLY WHEN ATC IS CLOSED. NONPARTICIPATING AIRCRAFT MUST CONTACT CARSON RADIO FOR STATUS OF THE ROZ AND UAS OPERATIONS. POC: MR ALLEN, EXT. 910-927-7118 OR 910-703-3111.
1/14/251700Z R2601: 140TH OSS RNG 123 WILL CONDUCT MULTIPLE SORTIE FMP OPERATIONS WITH MULTIPLE F-16,A-10, AC-130, U-28, H60, H47, AND H64 AIRCRAFT IN AIR 1-6 AND AIRBURST PORTION RNG 123 UP TO 22,500 FT MSL REQUESTING THE SHELF (10,000 FT MSL- 22,500 FT MSL) FROM GRID 63-71 NORTH (GRID 15 IS EAST BORDER). REQUESTING SHELF FOR SIMULATED ATTACKS ON RED DEVIL AND MANEUVER AIRSPACE. DATES/TIMES: (14 JAN 1700-2000 & 0100-0400) (15 JAN 1700-2000 & 0100-0400) (16 JAN 1700-2000 & 0100-0400) (17JAN 1700-2000) (21JAN 1700-2000& 0100-0400) (22JAN 1700-2000 & 0100-0400) (23JAN 1700-2000 & 0100-0400) (24JAN 1700-2000). POC: TSGT GIDDENS, EXT. 719-526-3225.
1/13/251400Z R2601: 10TH SFG WILL CONDUCT SUAS OPERATIONS ON AIR 1 AND 2 AND TA17 WITH 3 SUAS AIRCRAFT AT 2,000 FT AGL AND BELOW. UNIT WILL MAINTAIN CONTACT WITH RANGE CONTROL AND BUTTS ATC AT ALL TIMES. UNIT WILL NOT FLY WHEN ATC IS CLOSED. IN CASE OF LOST LINK, AIRCRAFT WILL RETURN TO AGONY NORTH. NONPARTICIPATING AIRCRAFT MUST CONTACT CARSON RADIO FOR STATUS OF THE ROZ AND UAS OPERATIONS. POC: CW3 COLOMB, EXT. 850-499-3873.
1/2/251526Z R2601: EAGLE NEST VICINITY OF TA33. NO OVERFLIGHT BELOW 1000 FT WITHIN A 1/2 MILE RADIUS OF 13SEC13406590.
1/1/250700Z GRAY EAGLE OPERATIONS DAILY FCS TO R2601 (AIR 1-7) VIA GE ROUTE AT 12,000 FT-15,000 FT MSL AND AT OR BELOW 8000 FT MSL IN BAHP CLASS D AIRSPACE. POC SFC BUTLER 719-503-6844.
12/31/241638Z !KFCS V0513/24 FCS AERODROME INSTRUMENT APPROACH PROCEDURE AMENDMENT RNAV (GPS) RWY 31 CHANGE MINIMUMS TO CIRCLING CAT A 6280-1 439 (500-1), CAT B 6400-1 559 (600-1), CAT C 6580-2 739 (800-2), CAT D 6840-3 999 (1000-3), COS ALTIMETER SETTING MINIMUMS: LPV DA 6094-7/8 268 (300-7/8); LNAV/VNAV DA 6198-1 372 (400-1): LNAV MDA CAT AB 6360-1 534 (600-1), CAT CD 6360-1 1/2 534 (600-1 1/2); CIRCLING CAT A 6360-1 519 (600-1), CAT B 6480-1 639 (700-1), CAT C 6660-2½ 819 (900-2½), CAT D 6920-3 1079 (1100-3) 2412311638-2512310001
12/17/240121Z BASE OPERATIONS HOURS 1300-0600 (0700-0000L) MON-FRI. CLOSED ALL FEDERAL HOLIDAYS.
12/17/240111Z KFCS: SOUTH WINDSOCK IN FOXTROT SOD, OBSTRUCTION LIGHT AND FLOODLIGHT UNLIT.
12/17/240109Z IHS NDB OUT OF SERVICE
12/17/240105Z KFCS: CAUTION: PERSONNEL, VEHICLES AND EQUIPMENT IN FOXTROT SOD.
12/17/240036Z KFCS: FOXTROT SOD, NORTH WINDSOCK OBSTRUCTION LIGHT OUT.
12/17/240015Z RNAV 31 APPROACH UNUSABLE DUE TO DISPLACED THRESHOLD.
12/17/240002Z RWY 31 NONSTANDARD DISLACED THRESHOLD MARKINGS. RWY DISTANCE REMAINING 3510 FT.
11/6/241200Z R2601: 10TH SFG(A) SORD WILL FLY 5 SUAS IN AGONY NORTH AND TA 17 AT OR BELOW 1000FT AGL. NO UAS OPS WHEN TOWER IS CLOSED. (POC COLOMB 850-499-3873).
11/4/241300Z ATC HOURS: 1300-0700Z (0600-0000L) MON-FRI. CLOSED WEEKENDS AND FEDERAL HOLIDAYS.
Yes
ALL
FLT FLW- BUTTS RDO OPR 1200-1200++ MONDAY-THURSDAY, 1200-0400++FRIDAY- SUNDAY EXC NEW YEARS, THANKSGIVING AND CHRISTMAS DAY.
US ARMY AERONAUTICAL SVCS AGENCY

FT BELVOIR, VA 22060
Phone: 520-228-6598/99
N/A
DENVER FSS (DEN)
Toll Free: 1-800-WX-BRIEF
FCS
Sunset to Sunrise
--
N/A
N/A
No
No
None
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
None
None
None
None
None

Runway 13/31

4500 ft. x 75 ft.
ASPH
Fair
NONE
MED
16 /F/A/W/T
--
--
--
--
  Runway 13 Runway 31
True Heading 137°317°
Traffic Pattern
Markings
Markings Condition FAIR FAIR
Latitude 38° 40' 58"N 38° 40' 26"N
Longitude 104° 45' 43"W 104° 45' 04"W
Elevation 5,841' 5,796'
Threshold Crossing Height 40 ft. AGL 40 ft. AGL
Visual Glide Path Angle
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1SVC: NO FUEL AVBL.
A110-10WX TECHNICIAN (DSN 691-3620/3651, C719-526-3620/3651), AVBL 24H MON-SUN INCL HOL. BUTTS METRO AVBL ON FREQ 50.75.
A110-11UNITS TMPRLY ASGND ARE RQRD TO COORD WX SUPPORT IAW AFMAN 15-129. AUGMENTED WX OBSN VIEW RSTD FROM 180-270 DEG AND 310-340 DEG BY FLT LINE FAC AND BLDGS.
A110-12RSTD: 24 HR PPR FOR ALL ACFT. CTC BASE OPS DSN 691-3935, C719-526-3935.
A110-13500 FT OVRN ON NW EOR, ACTF MAY TAX IN THIS AREA, UNUSE TO F/W ACFT FOR TKOF/LDG/ROLLOUT.
A110-16RWY 13/31 NSTD MARKINGS AND LIGHTING, TWY ALL NSTD MARKINGS AND LIGHTING, TWY B VFR OPS ONLY SR TO SS, NVD OPS ONLY SS TO SR.
A110-17WHEN BUTTS RDO IS CLSD CTC RANGE CTL 38.90 FOR OPS IN R2601. AVN TRNG AREA (ATA) AIR TO AIR FREQ ASSIGNMENT. ACFT OPERATING IN ATA 1-3 WILL MNT FM 37.200. ACFT OPERATING IN ATA 4-7 WILL MNT FM 68.750. ALL ACFT WILL MNT THE APPROPRIATE TRNG AREA FREQ WHEN OPERATING WITHIN R2601. WHEN OPERATING MULTI-SHIP ONLY ONE ACFT IS REQD TO MNT THE TRNG AREA FREQ. TRNG AREA FREQ ARE FOR TFC ADVSY AND DECONFLICTION AND WILL NOT BE USED FOR TACTICAL INTERNAL TFC.
A110-18ALL ACFT MUST REMAIN 100FT AGL OVER CONSTRUCTION AREAS.
A110-19ATC OPR MON-SAT 1300-0900Z++ CLSD WKND AND HOL. A - BASE OPS 1300-0500Z++ MON-FRI EXC HOL.
A110-20COMM: FLT FLW - CARSON RDO OPR MON-SAT 1200-0800Z++ CLSD WKNDS AND HOL.
A110-22D1 SOD PERMANENTLY CLSD.
A110-23MISC: NO TSNT ACFT SVC.
A110-3CAUTION: EXTV ARTILLERY AND SMALL ARMS FRNG. DUR PERIODS OF STRONG SW SFC WIND EXP STRUCTURE AND TRRN GENERATED TURB WITH WINDSHEAR NEAR THE APCH END RWY 13.
BUTTS AAF (FORT CARSON) (ICAO: KFCS, IATA: FCS) is a private airport located in FORT CARSON, CO.
