!FDC 4/1715 GGE PART 1 OF 4 ODP GEORGETOWN COUNTY, GEORGETOWN, SC.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1...
TAKEOFF OBSTACLE NOTES: RWY 5: LIGHT POLES BEGINNING 9 FT FROM DER,
29 FT LEFT OF CENTERLINE, UP TO 2 FT AGL/35 FT MSL.
TREE 122 FT FROM DER, 493 FT RIGHT OF CENTERLINE, 47 FT MSL.
TREE 265 FT FROM DER, 548 FT RIGHT OF CENTERLINE, 80 FT MSL.
TREES BEGINNING 382 FT FROM DER, 562 FT RIGHT OF CENTERLINE, UP TO
94 FT MSL.
TREES BEGINNING 534 FT FROM DER, 580 FT LEFT OF CENTERLINE, UP TO
86 FT MSL.
TREES BEGINNING 775 FT FROM DER, 617 FT RIGHT OF CENTERLINE, UP TO
95 FT MSL.
TREES BEGINNING 994 FT FROM DER, 4 FT LEFT OF CENTERLINE, UP TO 110
FT MSL.
TREES BEGINNING 1156 FT FROM DER, 676 FT RIGHT OF CENTERLINE, UP TO
100 FT MSL.
TREES BEGINNING 1605 FT FROM DER, 638 FT RIGHT OF CENTERLINE, UP TO
118 FT MSL.
TREES BEGINNING 1885 FT FROM DER, 1 FT RIGHT OF CENTERLINE, UP TO
119 FT MSL.
TREES BEGINNING 2657 FT FROM DER, 36 FT LEFT OF CENTERLINE, UP TO
ALL OTHER DATA REMAINS AS PUBLISHED. 2404162009-2604162009EST
END PART 1 OF 4
!FDC 4/1715 GGE PART 2 OF 4 ODP GEORGETOWN COUNTY, GEORGETOWN, SC.
86 FT AGL/118 FT MSL.
RWY 11: TREE 110 FT FROM DER, 259 FT RIGHT OF CENTERLINE, 82 FT
MSL.
TREES BEGINNING 127 FT FROM DER, 15 FT RIGHT OF CENTERLINE, UP TO
90 FT MSL.
TREES BEGINNING 565 FT FROM DER, 89 FT LEFT OF CENTERLINE, UP TO 63
FT MSL.
TREE 624 FT FROM DER, 245 FT LEFT OF CENTERLINE, 78 FT MSL.
TREES BEGINNING 713 FT FROM DER, 273 FT LEFT OF CENTERLINE, UP TO
88 FT MSL.
TREE 1042 FT FROM DER, 431 FT LEFT OF CENTERLINE, 97 FT MSL.
TREE 1092 FT FROM DER, 574 FT LEFT OF CENTERLINE, 101 FT MSL.
TREES BEGINNING 1193 FT FROM DER, 406 FT LEFT OF CENTERLINE, UP TO
109 FT MSL.
TREE 1682 FT FROM DER, 573 FT RIGHT OF CENTERLINE, 107 FT MSL.
TREE 1784 FT FROM DER, 438 FT RIGHT OF CENTERLINE, 114 FT MSL.
TREE 2013 FT FROM DER, 571 FT LEFT OF CENTERLINE, 113 FT MSL.
TREE 2120 FT FROM DER, 296 FT RIGHT OF CENTERLINE, 122 FT MSL.
TREE 2172 FT FROM DER, 617 FT LEFT OF CENTERLINE, 114 FT MSL.
RWY 23: LIGHT POLES 19 FT FROM DER, 89 FT RIGHT OF CENTERLINE, 5 FT
ALL OTHER DATA REMAINS AS PUBLISHED. 2404162009-2604162009EST
END PART 2 OF 4
!FDC 4/1715 GGE PART 3 OF 4 ODP GEORGETOWN COUNTY, GEORGETOWN, SC.
AGL/42 FT MSL.
LIGHT POLES 19 FT FROM DER, 90 FT LEFT OF CENTERLINE, 5 FT AGL/43
FT MSL.
TREE 177 FT FROM DER, 441 FT RIGHT OF CENTERLINE, 13 FT AGL/50 FT
MSL.
TREE 258 FT FROM DER, 511 FT RIGHT OF CENTERLINE, 60 FT MSL.
TREE 631 FT FROM DER, 609 FT RIGHT OF CENTERLINE, 69 FT MSL.
TREE 704 FT FROM DER, 628 FT RIGHT OF CENTERLINE, 101 FT MSL.
TREE 764 FT FROM DER, 638 FT RIGHT OF CENTERLINE, 104 FT MSL.
TREES BEGINNING 811 FT FROM DER, 574 FT RIGHT OF CENTERLINE, UP TO
121 FT MSL.
TREES BEGINNING 865 FT FROM DER, 599 FT LEFT OF CENTERLINE, UP TO
106 FT MSL.
RWY 29: SIGN 28 FT FROM DER, 129 FT RIGHT OF CENTERLINE, 3 FT
AGL/41 FT MSL.
TREE 880 FT FROM DER, 523 FT RIGHT OF CENTERLINE, 73 FT MSL.
TREE 882 FT FROM DER, 639 FT RIGHT OF CENTERLINE, 78 FT MSL.
TREES BEGINNING 928 FT FROM DER, 274 FT RIGHT OF CENTERLINE, UP TO
93 FT MSL.
TREES BEGINNING 1114 FT FROM DER, 270 FT RIGHT OF CENTERLINE, UP TO
ALL OTHER DATA REMAINS AS PUBLISHED. 2404162009-2604162009EST
END PART 3 OF 4
!FDC 4/1715 GGE PART 4 OF 4 ODP GEORGETOWN COUNTY, GEORGETOWN, SC.
102 FT MSL.
TREES BEGINNING 1186 FT FROM DER, 21 FT RIGHT OF CENTERLINE, UP TO
142 FT MSL.
TREE 1218 FT FROM DER, 96 FT LEFT OF CENTERLINE, 85 FT MSL.
TREES BEGINNING 1309 FT FROM DER, 247 FT LEFT OF CENTERLINE, UP TO
94 FT MSL.
TREES BEGINNING 1319 FT FROM DER, 48 FT RIGHT OF CENTERLINE, UP TO
143 FT MSL.
TREES BEGINNING 1392 FT FROM DER, 30 FT LEFT OF CENTERLINE, UP TO
98 FT MSL.
TREES BEGINNING 1463 FT FROM DER, 172 FT LEFT OF CENTERLINE, UP TO
99 FT MSL.
TREES BEGINNING 1505 FT FROM DER, 70 FT LEFT OF CENTERLINE, UP TO
104 FT MSL.
TREES BEGINNING 1616 FT FROM DER, 211 FT LEFT OF CENTERLINE, UP TO
83 FT AGL/126 FT MSL.
TREES BEGINNING 1743 FT FROM DER, 432 FT LEFT OF CENTERLINE, UP TO
128 FT MSL.
TREES BEGINNING 1821 FT FROM DER, 32 FT LEFT OF CENTERLINE, UP TO
95 FT AGL/137 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2404162009-2604162009EST
