4/4/231647Z
|
!FDC 3/5992 GMJ PART 1 OF 2 ODP GROVE RGNL, GROVE, OK.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
TAKEOFF OBSTACLE NOTES: RWY 18: POLE 67 FT FROM DER, 404 FT LEFT
OF CENTERLINE, 25 FT AGL/856 FT MSL.
POLE 117 FT FROM DER, 325 FT RIGHT OF CENTERLINE, 25 FT AGL/851 FT
MSL.
ELECTRICAL SYSTEM 164 FT FROM DER, 419 FT LEFT OF CENTERLINE, 32 FT
AGL/863 FT MSL.
POLES, BUILDINGS BEGINNING 251 FT FROM DER, 339 FT RIGHT OF
CENTERLINE, UP TO 33 FT AGL/857 FT MSL.
POLES, TREES, BUILDING BEGINNING 255 FT FROM DER, 296 FT LEFT OF
CENTERLINE, UP TO 34 FT AGL/865 FT MSL.
POLES BEGINNING 549 FT FROM DER, 408 FT RIGHT OF CENTERLINE, UP TO
37 FT AGL/858 FT MSL.
TREES, POLE BEGINNING 721 FT FROM DER, 13 FT RIGHT OF CENTERLINE,
UP TO 869 FT MSL.
TREES BEGINNING 957 FT FROM DER, 11 FT LEFT OF CENTERLINE, UP TO
866 FT MSL.
TREES BEGINNING 1136 FT FROM DER, 93 FT LEFT OF CENTERLINE, UP TO
873 FT MSL.
TREE 2465 FT FROM DER, 396 FT LEFT OF CENTERLINE, 890 FT MSL. RWY
903 FT MSL. 2304041647-2504041647EST
END PART 1 OF 2
!FDC 3/5992 GMJ PART 2 OF 2 ODP GROVE RGNL, GROVE, OK.
36: TERRAIN 29 FT FROM DER, 277 FT LEFT OF CENTERLINE, 825 FT MSL.
TREE 107 FT FROM DER, 451 FT RIGHT OF CENTERLINE, 878 FT MSL.
TREE, TERRAIN BEGINNING 151 FT FROM DER, 337 FT LEFT OF CENTERLINE,
UP TO 837 FT MSL.
TREES BEGINNING 201 FT FROM DER, 48 FT RIGHT OF CENTERLINE, UP TO
884 FT MSL.
POLE, TERRAIN, TREE BEGINNING 316 FT FROM DER, 376 FT LEFT OF
CENTERLINE, UP TO 27 FT AGL/859 FT MSL.
TREE 1452 FT FROM DER, 257 FT LEFT OF CENTERLINE, 863 FT MSL.
TREES BEGINNING 2131 FT FROM DER, 157 FT LEFT OF CENTERLINE, UP TO
880 FT MSL.
TREES BEGINNING 2210 FT FROM DER, 53 FT LEFT OF CENTERLINE, UP TO
887 FT MSL.
TREES BEGINNING 2349 FT FROM DER, 161 FT LEFT OF CENTERLINE, UP TO
899 FT MSL.
TREES BEGINNING 2629 FT FROM DER, 197 FT LEFT OF CENTERLINE, UP TO
903 FT MSL. 2304041647-2504041647EST
END PART 2 OF 2
|
