12/3/242121Z
|
!FDC 4/0982 HBI PART 1 OF 5 ODP ASHEBORO RGNL, ASHEBORO, NC.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 2...
TAKEOFF MINIMUMS: RWY 21, 400-2, OR STANDARD WITH A MINIMUM CLIMB
OF 498 FT PER NM TO 1200.
TAKEOFF OBSTACLE NOTES: RWY 21: FENCE 9 FT FROM DER, 299 FT RIGHT
OF CENTERLINE, 9 FT AGL/673 FT MSL.
TREE 16 FT FROM DER, 445 FT RIGHT OF CENTERLINE, 676 FT MSL.
TREE, VEHICLES ON ROAD, BUILDING BEGINNING 104 FT FROM DER, 287 FT
RIGHT OF CENTERLINE, UP TO 47 FT AGL/705 FT MSL.
TREES BEGINNING 935 FT FROM DER, 545 FT RIGHT OF CENTERLINE, UP TO
52 FT AGL/710 FT MSL.
TREE 1733 FT FROM DER, 544 FT RIGHT OF CENTERLINE, 719 FT MSL.
TREE 1819 FT FROM DER, 713 FT RIGHT OF CENTERLINE, 721 FT MSL.
TREE 1889 FT FROM DER, 965 FT LEFT OF CENTERLINE, 728 FT MSL.
TREE 2027 FT FROM DER, 980 FT LEFT OF CENTERLINE, 741 FT MSL.
TREE 2200 FT FROM DER, 907 FT LEFT OF CENTERLINE, 763 FT MSL.
TREES BEGINNING 2268 FT FROM DER, 810 FT LEFT OF CENTERLINE, UP TO
799 FT MSL.
TREES BEGINNING 2458 FT FROM DER, 769 FT LEFT OF CENTERLINE, UP TO
824 FT MSL.
TREES BEGINNING 3742 FT FROM DER, 1317 FT LEFT OF CENTERLINE, UP TO
ALL OTHER DATA REMAINS AS PUBLISHED. 2412032121-2612032120EST
END PART 1 OF 5
!FDC 4/0982 HBI PART 2 OF 5 ODP ASHEBORO RGNL, ASHEBORO, NC.
836 FT MSL.
TREES BEGINNING 3832 FT FROM DER, 899 FT LEFT OF CENTERLINE, UP TO
840 FT MSL.
TREES BEGINNING 3928 FT FROM DER, 1013 FT LEFT OF CENTERLINE, UP TO
850 FT MSL.
TREES BEGINNING 4002 FT FROM DER, 847 FT LEFT OF CENTERLINE, UP TO
852 FT MSL.
TREES BEGINNING 4187 FT FROM DER, 901 FT LEFT OF CENTERLINE, UP TO
858 FT MSL.
TREE 4238 FT FROM DER, 1515 FT LEFT OF CENTERLINE, 862 FT MSL.
TREE BEGINNING 4252 FT FROM DER, 1008 FT LEFT OF CENTERLINE, UP TO
100 FT AGL/865 FT MSL.
TREES BEGINNING 4347 FT FROM DER, 1216 FT LEFT OF CENTERLINE, UP TO
872 FT MSL.
TREES BEGINNING 4370 FT FROM DER, 1067 FT LEFT OF CENTERLINE, UP TO
873 FT MSL.
TREES BEGINNING 4593 FT FROM DER, 854 FT LEFT OF CENTERLINE, UP TO
882 FT MSL.
TREES BEGINNING 5264 FT FROM DER, 917 FT LEFT OF CENTERLINE, UP TO
887 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2412032121-2612032120EST
END PART 2 OF 5
!FDC 4/0982 HBI PART 3 OF 5 ODP ASHEBORO RGNL, ASHEBORO, NC.
TREE BEGINNING 5472 FT FROM DER, 1068 FT LEFT OF CENTERLINE, UP TO
100 FT AGL/891 FT MSL.
TREES BEGINNING 5694 FT FROM DER, 954 FT LEFT OF CENTERLINE, UP TO
895 FT MSL.
TREES BEGINNING 5893 FT FROM DER, 1146 FT LEFT OF CENTERLINE, UP TO
897 FT MSL.
TREES BEGINNING 6010 FT FROM DER, 906 FT LEFT OF CENTERLINE, UP TO
89 FT AGL/903 FT MSL.
TREES BEGINNING 1 NM FROM DER, 1263 FT LEFT OF CENTERLINE, UP TO
905 FT MSL.
TREES BEGINNING 1.1 NM FROM DER, 258 FT LEFT OF CENTERLINE, UP TO
924 FT MSL.
TREES BEGINNING 1.1 NM FROM DER, 331 FT LEFT OF CENTERLINE, UP TO
931 FT MSL.
TREES BEGINNING 1.3 NM FROM DER, 668 FT LEFT OF CENTERLINE, UP TO
934 FT MSL.
TREES BEGINNING 1.3 NM FROM DER, 472 FT LEFT OF CENTERLINE, UP TO
942 FT MSL.
TREES BEGINNING 1.3 NM FROM DER, 579 FT LEFT OF CENTERLINE, UP TO
947 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2412032121-2612032120EST
END PART 3 OF 5
!FDC 4/0982 HBI PART 4 OF 5 ODP ASHEBORO RGNL, ASHEBORO, NC.
TREES BEGINNING 1.3 NM FROM DER, 428 FT LEFT OF CENTERLINE, UP TO
954 FT MSL.
TREES BEGINNING 1.3 NM FROM DER, 516 FT LEFT OF CENTERLINE, UP TO
957 FT MSL.
TREES BEGINNING 1.3 NM FROM DER, 708 FT LEFT OF CENTERLINE, UP TO
968 FT MSL.
TREES BEGINNING 1.4 NM FROM DER, 409 FT LEFT OF CENTERLINE, UP TO
981 FT MSL.
TREES BEGINNING 1.4 NM FROM DER, 648 FT LEFT OF CENTERLINE, UP TO
983 FT MSL.
TREES BEGINNING 1.4 NM FROM DER, 368 FT LEFT OF CENTERLINE, UP TO
992 FT MSL.
TREES BEGINNING 1.4 NM FROM DER, 276 FT LEFT OF CENTERLINE, UP TO
1003 FT MSL.
TREES BEGINNING 1.4 NM FROM DER, 353 FT LEFT OF CENTERLINE, UP TO
1004 FT MSL.
TREES BEGINNING 1.4 NM FROM DER, 221 FT LEFT OF CENTERLINE, UP TO
1011 FT MSL.
TREES BEGINNING 1.4 NM FROM DER, 240 FT LEFT OF CENTERLINE, UP TO
81 FT AGL/1025 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2412032121-2612032120EST
END PART 4 OF 5
!FDC 4/0982 HBI PART 5 OF 5 ODP ASHEBORO RGNL, ASHEBORO, NC.
TREES BEGINNING 1.7 NM FROM DER, 529 FT LEFT OF CENTERLINE, UP TO
80 FT AGL/1034 FT MSL.
TREES BEGINNING 1.7 NM FROM DER, 136 FT LEFT OF CENTERLINE, UP TO
1036 FT MSL.
TREE 2.2 NM FROM DER, 944 FT LEFT OF CENTERLINE, 1019 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2412032121-2612032120EST
END PART 5 OF 5
|
