KHSB
HARRISBURG-RALEIGH
PublicPUB

4 miles N of HARRISBURG, IL
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
37° 48' 41"N 88° 33' 01"W
398' MSL
1398' MSL
00E
JET A, 100LL
SAINT LOUIS (STL)
ST LOUIS
KANSAS CITY (ZKC)
11/28/24-12/26/24
KHSB VFR
6:15 AM CST
Overcast 7,500'
Scattered 6,000'
10sm
40°F
23°F
30.27"Hg
190° 9kts
AO2 T00421050
KHSB 231215Z AUTO 19009KT 10SM SCT060 OVC075 04/M05 A3027 RMK AO2 T00421050
Add Your Business

KHSB FBOs

Promote Listing
Harrisburg-Raleigh Airport
UNICOM: 122.8
Phone: (618) 253-7806
No Rating Available
0 Reviews (Read | Sign In To Write)
Independent
As of 12/13
 100LL JET A JET A (FSII) MOGAS UL94
Self Serve 5.87 4.90
Full Serve 4.90
Fuel Notes
Prices include tax
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.8 122.8

AWOS-3PT

AWOS-3PT
618-253-3010
 135.925

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

KMVN (34nm)
Mon, 12/23 5:20 AM CST
Mon, 12/23 6:00 AM CST - Tue, 12/24 6:00 AM CST
VFR
6:00 AM CST - 10:00 AM CST
Overcast 7,000'
Scattered 6,000'
6sm
170° 8kts
VFR
10:00 AM CST - 9:00 PM CST
Overcast 5,000'
6sm
200° 10kts
MVFR
9:00 PM CST - 6:00 AM CST
Light Rain
Overcast 3,000'
5sm
220° 5kts
KMVN 231120Z 2312/2412 17008KT P6SM SCT060 OVC070
   FM231600 20010KT P6SM OVC050
   FM240300 22005KT 5SM -RA OVC030
KHSB
Domestic
12/22/241340Z !HSB 12/007 HSB OBST TOWER LGT (ASR 1009640) 380312.50N0883404.90W (14.6NM N HSB) 772.0FT (314.0FT AGL) U/S 2412221340-2502051340
12/5/241534Z !HSB 12/002 HSB OBST TOWER LGT (ASR 1009355) 374422.70N0883317.10W (4.3NM S HSB) 656.2FT (290.0FT AGL) U/S 2412051534-2501062300
9/25/240923Z !HSB 09/010 HSB OBST TOWER LGT (ASR 1009465) 374558.00N0883121.00W (3.0NM SSE HSB) 636.2FT (270.0FT AGL) U/S 2409250923-2412252359
FDC
8/9/231343Z !FDC 3/0867 HSB IAP HARRISBURG-RALEIGH, HARRISBURG, IL.
RNAV (GPS) RWY 24, AMDT 2B...
PBN REQUIREMENTS NOTE: RNP APCH -GPS.
NOTE: WHEN LOCAL ALTIMETER SETTING NOT RECEIVED, USE MARION ALTIMETER SETTING AND INCREASE LPV DA TO 759 FEET; INCREASE LNAV/VNAV DA TO 921 FEET AND ALL MDAS 80 FEET; INCREASE LNAV CATS C AND D AND CIRCLING CATS C VISIBILITY 1/4 MILE.
NOTE: VDP NA WHEN USING MARION ALTIMETER SETTING.
NOTE: BARO-VNAV NA WHEN USING MARION ALTIMETER SETTING.
2308091343-2508091343EST
8/9/231343Z !FDC 3/0866 HSB IAP HARRISBURG-RALEIGH, HARRISBURG, IL.
RNAV (GPS) RWY 6, AMDT 1A...
PBN REQUIREMENTS NOTE: RNP APCH - GPS.
CHANGE NOTE TO READ: BARO-VNAV NA WHEN USING MARION ALTIMETER SETTING.
CHANGE NOTE TO READ: VDP NA WHEN USING MARION ALTIMETER SETTING.
2308091343-2508091343EST
No
0800-1700
HARRISBURG RALEIGH AIRPORT
P.O. BOX 33
HARRISBURG, IL 62946
Phone: 618-253-7806
DALE SHELTON
P.O. BOX 33
HARRISBURG, IL 62946
Phone: 618-253-7806
SAINT LOUIS FSS (STL)
Toll Free: 1-800-WX-BRIEF
HSB
--
REIL RWY 06 & 24; MIRL RWY 06/24 PRESET ON LOW INTST; TO INCR INTST & ACTVT MIRL RWY 14/32 - CTAF.
N/A
Yes - Lighted
Yes
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
Minor
Minor
None
None
None

Runway 06/24

5013 ft. x 75 ft.
ASPH
Fair
NONE
MED

12,000lbs
--
--
--
  Runway 06 Runway 24
True Heading 63°243°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 37° 48' 32"N 37° 48' 55"N
Longitude 88° 33' 34"W 88° 32' 38"W
Elevation 387' 396'
Threshold Crossing Height 35 ft. AGL 35 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights No No
Runway End Identifier Lights Yes Yes

Runway 14/32

2764 ft. x 75 ft.
ASPH
Good
NONE
MED

26,000lbs
--
--
--
  Runway 14 Runway 32
True Heading 141°321°
Traffic Pattern Left Left
Markings BSC BSC
Markings Condition FAIR FAIR
Latitude 37° 48' 46"N 37° 48' 25"N
Longitude 88° 33' 02"W 88° 32' 40"W
Elevation 387' 382'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights No No
Runway End Identifier Lights No No
A110-1ULTRALIGHT ACTIVITY ON & INVOF ARPT.
A110-2FOR SVCS OR JET A FUEL AFT HRS CALL AMGR AT 618-499-5058 (CELL).
A110-324 HR SELF SERVE 100LL FUEL AVBL WITH CREDIT CARD.
A110-4FOR CD CTC KANSAS CITY ARTCC AT 913-254-8508.
HARRISBURG-RALEIGH (ICAO: KHSB, IATA: HSB) is a public airport located in HARRISBURG, IL.
