12/4/231928Z
|
!FDC 3/0498 HWD PART 1 OF 4 ODP HAYWARD EXEC, HAYWARD, CA.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1...
CHANGE TAKEOFF MINIMUMS TO READ:
RWY 10L, 300-1 1/4 OR STANDARD WITH MINIMUM CLIMB 211 FT PER NM TO
300.
CHANGE TAKEOFF OBSTACLE NOTES TO READ:
RWY 10L: SIGN BEGINNING 32 FT FROM DER, 116 FT LEFT OF CENTERLINE,
UP TO 6 FT AGL/43 FT MSL.
BUILDINGS, TREES BEGINNING 108 FT FROM DER, ON AND LEFT OF
CENTERLINE, UP TO 139 FT AGL/192 FT MSL.
TERRAIN BEGINNING 4731 FT FROM DER, 1712 FT LEFT OF CENTERLINE, UP
TO 273 FT MSL.
TERRAIN BEGINNING 1.2 NM FROM DER, 2520 FT RIGHT OF CENTERLINE, UP
TO 250 FT MSL.
RWY 10R: TREES, TERRAIN, POLES, WALL, FENCE, TRAVERSE WAY BEGINNING
20 FT FROM DER, 9 FT LEFT OF CENTERLINE, UP TO 107 FT MSL.
POLES, TERRAIN, FENCE, WALL, TREES, BUILDING BEGINNING 22 FT FROM
DER, 25 FT RIGHT OF CENTERLINE, UP TO 32 FT AGL/80 FT MSL.
TREES, BUILDING, TRAVERSE WAYS BEGINNING 412 FT FROM DER, 99 FT
LEFT OF CENTERLINE, UP TO 66 FT AGL/117 FT MSL.
TREES, TRAVERSE WAY, POLES, BUILDING, LIGHT POLES BEGINNING 587 FT
ALL OTHER DATA REMAINS AS PUBLISHED. 2312041928-2512041928EST
END PART 1 OF 4
!FDC 3/0498 HWD PART 2 OF 4 ODP HAYWARD EXEC, HAYWARD, CA.
FROM DER, 25 FT LEFT OF CENTERLINE, UP TO 120 FT MSL.
POLE, LIGHT POLES BEGINNING 728 FT FROM DER, 26 FT RIGHT OF
CENTERLINE, UP TO 30 FT AGL/82 FT MSL.
POLES, TREES, LIGHT POLES BEGINNING 803 FT FROM DER, 62 FT RIGHT OF
CENTERLINE, UP TO 35 FT AGL/85 FT MSL.
TREES, POLES, SIGN, BUILDING BEGINNING 953 FT FROM DER, 15 FT LEFT
OF CENTERLINE, UP TO 132 FT MSL.
BUILDING 1103 FT FROM DER, 2 FT RIGHT OF CENTERLINE, 42 FT AGL/92
FT MSL.
POLE 1193 FT FROM DER, 204 FT RIGHT OF CENTERLINE, 43 FT AGL/93 FT
MSL.
TREES, POLE BEGINNING 1222 FT FROM DER, 7 FT RIGHT OF CENTERLINE,
UP TO 79 FT AGL/129 FT MSL.
BUILDINGS, TREES, SIGN BEGINNING 2065 FT FROM DER, 654 FT LEFT OF
CENTERLINE, UP TO 101 FT AGL/155 FT MSL.
TERRAIN BEGINNING 5690 FT FROM DER, 2020 FT RIGHT OF CENTERLINE, UP
TO 200 FT AGL/250 FT MSL.
RWY 28L: TREE, NAVAID BEGINNING 95 FT FROM DER, 269 FT RIGHT OF
CENTERLINE, UP TO 13 FT AGL/39 FT MSL.
NAVAID, TRAVERSE WAY BEGINNING 170 FT FROM DER, 259 FT RIGHT OF
ALL OTHER DATA REMAINS AS PUBLISHED. 2312041928-2512041928EST
END PART 2 OF 4
!FDC 3/0498 HWD PART 3 OF 4 ODP HAYWARD EXEC, HAYWARD, CA.
CENTERLINE, UP TO 21 FT AGL/47 FT MSL.
TREES BEGINNING 655 FT FROM DER, 47 FT RIGHT OF CENTERLINE, UP TO
91 FT AGL/113 FT MSL.
TREES BEGINNING 752 FT FROM DER, ON AND LEFT OF CENTERLINE, UP TO
46 FT AGL/108 FT MSL.
TERRAIN BEGINNING 5609 FT FROM DER, 1978 FT LEFT OF CENTERLINE, UP
TO 214 FT MSL.
RWY 28R: BUILDING 45 FT FROM DER, 446 FT RIGHT OF CENTERLINE, 25 FT
AGL/55 FT MSL.
TREE, FENCE BEGINNING 390 FT FROM DER, 209 FT RIGHT OF CENTERLINE,
UP TO 81 FT MSL.
TREES BEGINNING 643 FT FROM DER, 459 FT RIGHT OF CENTERLINE, UP TO
95 FT AGL/128 FT MSL.
TREE, POLE BEGINNING 697 FT FROM DER, 4 FT RIGHT OF CENTERLINE, UP
TO 98 FT AGL/131 FT MSL.
NAVAID 727 FT FROM DER, 240 FT LEFT OF CENTERLINE, 21 FT AGL/47 FT
MSL.
TREES BEGINNING 1212 FT FROM DER, 5 FT LEFT OF CENTERLINE, UP TO 91
FT AGL/113 FT MSL.
TERRAIN BEGINNING 5317 FT FROM DER, 1856 FT RIGHT OF CENTERLINE, UP
ALL OTHER DATA REMAINS AS PUBLISHED. 2312041928-2512041928EST
END PART 3 OF 4
!FDC 3/0498 HWD PART 4 OF 4 ODP HAYWARD EXEC, HAYWARD, CA.
TO 220 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2312041928-2512041928EST
END PART 4 OF 4
|
