10/31/231951Z
|
!FDC 3/4342 ILG PART 1 OF 3 ODP NEW CASTLE, WILMINGTON, DE. TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG... TAKEOFF OBSTACLE NOTES: RWY 1: LIGHT POLES 6 FT FROM DER, 153 FT RIGHT OF CENTERLINE, 3 FT AGL/62 FT MSL. VEGETATION 118 FT FROM DER, 385 FT LEFT OF CENTERLINE, 16 FT AGL/65 FT MSL.TREES BEGINNING 735 FT FROM DER, 509 FT LEFT OF CENTERLINE, UP TO 77 FT AGL/97 FT MSL. TREES BEGINNING 960 FT FROM DER, 494 FT LEFT OF CENTERLINE, UP TO 94 FT AGL/104 FT MSL. TREES BEGINNING 1049 FT FROM DER, 475 FT LEFT OF CENTERLINE, UP TO 97 FT AGL/105 FT MSL. TREE 1102 FT FROM DER, 580 FT RIGHT OF CENTERLINE, 81 FT AGL/115 FT MSL. TREE 1205 FT FROM DER, 438 FT LEFT OF CENTERLINE, 88 FT AGL/107 FT MSL. TREES BEGINNING 1226 FT FROM DER, 553 FT LEFT OF CENTERLINE, UP TO 104 FT AGL/113 FT MSL. TREES BEGINNING 1244 FT FROM DER, 528 FT RIGHT OF CENTERLINE, UP TO 87 FT AGL/121 FT MSL. TREES BEGINNING 1848 FT FROM DER, 667 FT LEFT OF CENTERLINE, UP TO 128 FT MSL. RWY 9: LIGHT POLES 10 FT FROM DER, 54 FT LEFT AND RIGHT OF CENTERLINE, 1 FT AGL/72 FT MSL. SIGN, LIGHT POLES BEGINNING 30 FT FROM DER, 149 FT RIGHT OF CENTERLINE, UP TO 3 FT AGL/73 FT MSL. SIGN 92 FT FROM DER, 439 FT RIGHT OF CENTERLINE, 4 FT AGL/74 FT MSL. SIGN 889 FT FROM DER, 399 FT LEFT OF CENTERLINE, 35 FT AGL/94 FT MSL. BUILDING 944 FT FROM DER, 458 FT LEFT OF CENTERLINE, 42 FT AGL/100 FT MSL. POLES ALL OTHER DATA REMAINS AS PUBLISHED. 2310311951-2510311951EST END PART 1 OF 3 !FDC 3/4342 ILG PART 2 OF 3 ODP NEW CASTLE, WILMINGTON, DE. BEGINNING 976 FT FROM DER, 388 FT RIGHT OF CENTERLINE, UP TO 38 FT AGL/115 FT MSL. TREE 1350 FT FROM DER, 538 FT LEFT OF CENTERLINE, 106 FT MSL. TREE 1410 FT FROM DER, 699 FT LEFT OF CENTERLINE, 126 FT MSL. TREES BEGINNING 1430 FT FROM DER, 2 FT LEFT OF CENTERLINE, UP TO 134 FT MSL. TREE 1569 FT FROM DER, 64 FT RIGHT OF CENTERLINE, 116 FT MSL. TOWER 2263 FT FROM DER, 1101 FT RIGHT OF CENTERLINE, 78 FT AGL/154 FT MSL. TREE 3119 FT FROM DER, 959 FT RIGHT OF CENTERLINE, 166 FT MSL. TRANSMISSION LINE 4090 FT FROM DER, 1428 FT LEFT OF CENTERLINE, 120 FT AGL/187 FT MSL. RWY 14: SIGNS BEGINNING 35 FT FROM DER, 113 FT RIGHT OF CENTERLINE, UP TO 3 FT AGL/75 FT MSL. TREES, POLES, ANTENNA, TOWER BEGINNING 88 FT FROM DER, 17 FT LEFT OF CENTERLINE, UP TO 100 FT AGL/176 FT MSL. TREES BEGINNING 109 FT FROM DER, 57 FT RIGHT OF CENTERLINE, UP TO 100 FT AGL/176 FT MSL. RWY 19: LIGHT POLE 4 FT FROM DER, 55 FT RIGHT OF CENTERLINE, 2 FT AGL/76 FT MSL. TREE 1574 FT FROM DER, 849 FT RIGHT OF CENTERLINE, 65 FT AGL/120 FT MSL. RWY 27: TERRAIN 49 FT FROM DER, 506 FT LEFT OF CENTERLINE, 82 FT MSL. POLES BEGINNING 670 FT FROM DER, 453 FT RIGHT OF CENTERLINE, UP TO 34 FT AGL/107 FT MSL. RWY 32: LIGHT POLES 10 FT FROM DER, 55 FT RIGHT OF CENTERLINE, 1 FT AGL/76 FT MSL. LIGHT POLES 11 FT FROM DER, 54 FT LEFT OF ALL OTHER DATA REMAINS AS PUBLISHED. 2310311951-2510311951EST END PART 2 OF 3 !FDC 3/4342 ILG PART 3 OF 3 ODP NEW CASTLE, WILMINGTON, DE. CENTERLINE, 1 FT AGL/76 FT MSL. SIGN, TERRAIN BEGINNING 16 FT FROM DER, ON AND LEFT OF CENTERLINE, UP TO 3 FT AGL/77 FT MSL. TREES BEGINNING 113 FT FROM DER, 65 FT LEFT OF CENTERLINE, UP TO 100 FT AGL/176 FT MSL.TREES, BUILDING BEGINNING 134 FT FROM DER, 11 FT RIGHT OF CENTERLINE, UP TO 100 FT AGL/176 FT MSL. ALL OTHER DATA REMAINS AS PUBLISHED. 2310311951-2510311951EST END PART 3 OF 3
|
