iFlightPlanner



...
MADISON MUNI - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

KIMS
MADISON MUNI
PublicPUB

4 miles W of MADISON, IN
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
38° 45' 36"N 85° 27' 53"W
819' MSL
1819' MSL
03W
JET A, 100LL
TERRE HAUTE (HUF)
ST LOUIS
INDIANAPOLIS (ZID)
12/26/24-1/23/25
KIMS VFR
11:35 AM EST
Scattered 11,000'
10sm
12°F
0°F
30.46"Hg
200° 8kts
AO2
KIMS 221635Z AUTO 20008KT 10SM SCT110 M11/M18 A3046 RMK AO2
Add Your Business

KIMS FBOs

Promote Listing
Madison Municipal Airport
UNICOM: 123.0
Phone: (812) 273-1914
No Rating Available
0 Reviews (Read | Sign In To Write)
Titan
As of 1/21
 100LL JET A JET A (FSII) MOGAS UL94
Self Serve 4.69 5.15
Full Serve 5.65
Fuel Notes
Prices include tax
Great, clean, and easy to use self serve fuel farm. 6,000 gallon Jet-A truck. Titan rewards on Jet-A. Military Air Card accepted.
Fuel Hours
Self-Serve 24/7 for 100LL and Jet-A

Full Service Jet-A during business hours or with prior arrangement for after hours. Fees apply for after hours.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
123.0 123.0

AWOS-3

AWOS-3
812-866-1798
 119.175

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

KSDF (37nm)
Wed, 1/22 6:33 AM EST
Wed, 1/22 7:00 AM EST - Thu, 1/23 1:00 PM EST
VFR
7:00 AM EST - 10:00 AM EST
Broken 25,000'
6sm
140° 8kts
VFR
10:00 AM EST - 11:00 PM EST
Broken 20,000'
6sm
170° 6kts
VFR
11:00 PM EST - 1:00 PM EST
Overcast 12,000'
6sm
190° 7kts
KSDF 221133Z 2212/2318 14008KT P6SM BKN250
   FM221500 17006KT P6SM BKN200
   FM230400 19007KT P6SM OVC120
KIMS
Domestic
1/22/250828Z !HUF 01/242 IMS OBST TOWER LGT (ASR 1250181) 385024.30N0852949.80W (5.0NM NNW IMS) 1108.9FT (310.0FT AGL) U/S 2501220828-2502060728
1/22/250755Z !HUF 01/237 IMS OBST TOWER LGT (ASR 1028470) 384738.70N0852530.40W (2.8NM NE IMS) 1087.9FT (232.0FT AGL) U/S 2501220755-2504220500
1/22/250641Z !HUF 01/234 IMS OBST TOWER LGT (ASR 1314379) 384818.33N0852529.36W (3.3NM NE IMS) 1135FT (275FT AGL) U/S 2501220641-2502222300
1/7/250820Z !HUF 01/398 IMS OBST TOWER LGT (ASR UNKNOWN) 384322.49N0852554.56W (2.70NM SE IMS) 762FT (310FT AGL) U/S 2501070820-2502210820
1/5/252146Z !HUF 01/219 IMS OBST STACK LGT (ASN 2007-AGL-8378-OE) 384422N0852508W (2.5NM ESE IMS) 1447FT (982FT AGL) U/S 2501052146-2501312359
12/25/241315Z !HUF 12/642 IMS NAV GVR DME U/S 2412251315-2506252000EST
12/14/240722Z !HUF 12/410 IMS OBST TOWER LGT (ASN 2021-AGL-27042-OE) 385033N0853002W (5.2NM NNW IMS) 1113FT (340FT AGL) U/S 2412140722-2501280721
FDC
12/19/231701Z !FDC 3/7731 IMS IAP MADISON MUNI, MADISON, IN.
RNAV (GPS) Z RWY 3, AMDT 2...
LNAV/VNAV DA** CATS A/B/C 1143/HAT 331.
2312191701-2512191701EST
12/7/231902Z !FDC 3/2677 IMS IAP MADISON MUNI, MADISON, IN.
RNAV (GPS) Y RWY 3, ORIG-A...
CIRCLING CAT C MDA 1440/HAA 621.
2312071902-2512071902EST
12/7/231858Z !FDC 3/2676 IMS IAP MADISON MUNI, MADISON, IN.
RNAV (GPS) RWY 21, ORIG...
LNAV CAT A/B/C MDA 1400/HAT 581, CAT C VIS 1 5/8. CIRCLING CAT A/B MDA 1400/HAA 581, CIRCLING CAT C MDA 1440/HAA 621, CIRCLING CAT C VIS 1 3/4. VDP 1.65 NM TO RW21.
2312071858-2512071858EST
No
MAR-OCT 0800-1730
NOV-FEB 0800-1700
UNATNDD THANKSGIVING, CHRISTMAS & NEW YEARS.
MADISON BOAC
101 W. MAIN ST.
MADISON, IN 47250
Phone: 812-265-8316
BRENT SPRY
3919 W. IMS LANE
MADISON, IN 47250
Phone: 812-273-1914
TERRE HAUTE FSS (HUF)
Toll Free: 1-800-WX-BRIEF
HUF
--
ACTVT MALSF RWY 03; REIL RWY 21; PAPI RWY 03 & 21; HIRL RWY 03/21 - CTAF.
N/A
Yes - Lighted
No
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
Major
Major
None
None
Crop Dusting
Pilot Instruction
Aircraft Rental

Runway 03/21

5000 ft. x 75 ft.
ASPH
Good
GRVD
HIGH
23 /F/C/X/T
61,000lbs
82,000lbs
--
--
  Runway 03 Runway 21
True Heading 32°212°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 38° 45' 15"N 38° 45' 57"N
Longitude 85° 28' 10"W 85° 27' 36"W
Elevation 807' 819'
Threshold Crossing Height 42 ft. AGL 39 ft. AGL
Visual Glide Path Angle 3.5° 3°
Visual Slope Indicator P4L P2L
Approach Lights MALSF
Centerline Lights No No
Runway End Identifier Lights No Yes
A110-1FOR CD CTC LOUISVILLE APCH AT 502-375-7499
MADISON MUNI (ICAO: KIMS, IATA: IMS) is a public airport located in MADISON, IN.
