3/9/231715Z
|
!FDC 3/5642 LCQ PART 1 OF 5 ODP LAKE CITY GATEWAY, LAKE CITY, FL.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1...
TAKEOFF MINIMUMS: RWY 5, 300-1 OR STANDARD WITH A MINIMUM CLIMB OF
248 FT PER NM TO 500.
RWY 28, 300-1 OR STANDARD WITH A MINIMUM CLIMB OF 255 FT PER NM TO
400.
TAKEOFF OBSTACLE NOTES:
NOTE: RWY 5: TERRAIN 118 FT FROM DER, 318 FT LEFT OF CENTERLINE,
200 FT AGL/371 FT MSL.
TERRAIN BEGINNING 140 FT FROM DER, 82 FT RIGHT OF CENTERLINE, UP TO
200 FT AGL/361 FT MSL.
TERRAIN BEGINNING 305 FT FROM DER, 156 FT LEFT OF CENTERLINE, UP TO
200 FT AGL/381 FT MSL.
TERRAIN 347 FT FROM DER, 244 FT RIGHT OF CENTERLINE, 200 FT AGL/368
FT MSL.
TERRAIN BEGINNING 534 FT FROM DER, 5 FT RIGHT OF CENTERLINE, UP TO
200 FT AGL/381 FT MSL.
TERRAIN BEGINNING 720 FT FROM DER, 233 FT LEFT OF CENTERLINE, UP TO
200 FT AGL/384 FT MSL.
TERRAIN BEGINNING 741 FT FROM DER, 167 FT RIGHT OF CENTERLINE, UP
TO 200 FT AGL/388 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2303091715-2503091713EST
END PART 1 OF 5
!FDC 3/5642 LCQ PART 2 OF 5 ODP LAKE CITY GATEWAY, LAKE CITY, FL.
TERRAIN BEGINNING 928 FT FROM DER, 41 FT LEFT OF CENTERLINE, UP TO
200 FT AGL/391 FT MSL.
TERRAIN, TREE BEGINNING 1135 FT FROM DER, 12 FT RIGHT OF
CENTERLINE, UP TO 200 FT AGL/391 FT MSL.
TREES BEGINNING 1540 FT FROM DER, 560 FT RIGHT OF CENTERLINE, UP TO
290 FT MSL.
TERRAIN, TREE BEGINNING 1572 FT FROM DER, 174 FT RIGHT OF
CENTERLINE, UP TO 200 FT AGL/394 FT MSL.
TERRAIN, TOWER BEGINNING 1966 FT FROM DER, 20 FT RIGHT OF
CENTERLINE, UP TO 200 FT AGL/397 FT MSL.
TOWER 5058 FT FROM DER, 611 FT RIGHT OF CENTERLINE, 163 FT AGL/351
FT MSL.
TERRAIN 5821 FT FROM DER, 1637 FT LEFT OF CENTERLINE, 200 FT
AGL/394 FT MSL.
TERRAIN BEGINNING 5842 FT FROM DER, 33 FT LEFT OF CENTERLINE, UP TO
200 FT AGL/397 FT MSL.
TERRAIN 1 NM FROM DER, 1313 FT LEFT OF CENTERLINE, 200 FT AGL/401
FT MSL.
TERRAIN BEGINNING 1 NM FROM DER, 51 FT LEFT AND RIGHT OF
CENTERLINE, UP TO 200 FT AGL/410 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2303091715-2503091713EST
END PART 2 OF 5
!FDC 3/5642 LCQ PART 3 OF 5 ODP LAKE CITY GATEWAY, LAKE CITY, FL.
TERRAIN BEGINNING 1.1 NM FROM DER, 213 FT RIGHT OF CENTERLINE, UP
TO 200 FT AGL/404 FT MSL.
TERRAIN BEGINNING 1.1 NM FROM DER, 18 FT LEFT AND RIGHT OF
CENTERLINE, UP TO 200 FT AGL/417 FT MSL.
TERRAIN BEGINNING 1.2 NM FROM DER, 58 FT RIGHT OF CENTERLINE, UP TO
200 FT AGL/417 FT MSL.
NOTE: RWY 10: TREE 85 FT FROM DER, 366 FT LEFT OF CENTERLINE, 200
FT MSL.
TREE 2452 FT FROM DER, 151 FT RIGHT OF CENTERLINE, 259 FT MSL.
TREES BEGINNING 2489 FT FROM DER, 255 FT RIGHT OF CENTERLINE, UP TO
262 FT MSL.
TREE 2550 FT FROM DER, 120 FT RIGHT OF CENTERLINE, 267 FT MSL.
TREES BEGINNING 2596 FT FROM DER, 31 FT RIGHT OF CENTERLINE, UP TO
269 FT MSL.
TREES BEGINNING 2630 FT FROM DER, 59 FT LEFT OF CENTERLINE, UP TO
267 FT MSL.
TREES BEGINNING 2680 FT FROM DER, 93 FT RIGHT OF CENTERLINE, UP TO
284 FT MSL.
TREES BEGINNING 2870 FT FROM DER, 208 FT LEFT OF CENTERLINE, UP TO
273 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2303091715-2503091713EST
END PART 3 OF 5
!FDC 3/5642 LCQ PART 4 OF 5 ODP LAKE CITY GATEWAY, LAKE CITY, FL.
NOTE: RWY 23: TERRAIN BEGINNING 27 FT FROM DER, 127 FT LEFT OF
CENTERLINE, UP TO 200 FT AGL/351 FT MSL.
TERRAIN 49 FT FROM DER, 111 FT RIGHT OF CENTERLINE, 200 FT AGL/355
FT MSL.
TERRAIN BEGINNING 70 FT FROM DER, 33 FT RIGHT OF CENTERLINE, UP TO
200 FT AGL/361 FT MSL.
TERRAIN BEGINNING 608 FT FROM DER, 43 FT LEFT OF CENTERLINE, UP TO
200 FT AGL/358 FT MSL.
TERRAIN BEGINNING 1396 FT FROM DER, 197 FT LEFT OF CENTERLINE, UP
TO 200 FT AGL/361 FT MSL.
TERRAIN BEGINNING 1811 FT FROM DER, 35 FT LEFT OF CENTERLINE, UP TO
200 FT AGL/371 FT MSL.
TERRAIN BEGINNING 1875 FT FROM DER, 126 FT RIGHT OF CENTERLINE, UP
TO 200 FT AGL/365 FT MSL.
TERRAIN BEGINNING 2083 FT FROM DER, 49 FT RIGHT OF CENTERLINE, UP
TO 200 FT AGL/368 FT MSL.
TERRAIN BEGINNING 2828 FT FROM DER, 27 FT LEFT OF CENTERLINE, UP TO
200 FT AGL/374 FT MSL.
TERRAIN BEGINNING 3036 FT FROM DER, 57 FT RIGHT OF CENTERLINE, UP
TO 200 FT AGL/378 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2303091715-2503091713EST
END PART 4 OF 5
!FDC 3/5642 LCQ PART 5 OF 5 ODP LAKE CITY GATEWAY, LAKE CITY, FL.
TERRAIN BEGINNING 3803 FT FROM DER, 3 FT LEFT OF CENTERLINE, UP TO
200 FT AGL/384 FT MSL.
TERRAIN BEGINNING 4426 FT FROM DER, 65 FT RIGHT OF CENTERLINE, UP
TO 200 FT AGL/381 FT MSL.
NOTE: RWY 28: TREES BEGINNING 982 FT FROM DER, 360 FT LEFT OF
CENTERLINE, UP TO 260 FT MSL
TERRAIN BEGINNING 4783 FT FROM DER, 1772 FT LEFT OF CENTERLINE, UP
TO 200 FT AGL/351 FT MSL.
TERRAIN BEGINNING 5228 FT FROM DER, 1804 FT RIGHT OF CENTERLINE, UP
TO 200 FT AGL/378 FT MSL.
TERRAIN BEGINNING 5306 FT FROM DER, 1837 FT LEFT OF CENTERLINE, UP
TO 200 FT AGL/355 FT MSL.
TERRAIN BEGINNING 6049 FT FROM DER, 1976 FT RIGHT OF CENTERLINE, UP
TO 200 FT AGL/381 FT MSL.
TERRAIN BEGINNING 1 NM FROM DER, 1933 FT LEFT OF CENTERLINE, 200 FT
AGL/361 FT MSL.
TERRAIN 1.1 NM FROM DER, 2212 FT RIGHT OF CENTERLINE, 200 FT
AGL/381 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2303091715-2503091713EST
END PART 5 OF 5
|
