12/20/241247Z
|
!FDC 4/9283 LOU PART 1 OF 4 ODP BOWMAN FLD, LOUISVILLE, KY.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 4...
CHANGE TAKEOFF OBSTACLE NOTES TO READ:
NOTE: RWY 6: TERRAIN 57 FT FROM DER, 457 FT LEFT OF CENTERLINE, 535
FT MSL.
TREES BEGINNING 335 FT FROM DER, 121 FT LEFT OF CENTERLINE, UP TO
102 FT AGL/642 FT MSL.
TREES BEGINNING 360 FT FROM DER, 330 FT RIGHT OF CENTERLINE, UP TO
93 FT AGL/620 FT MSL.
NOTE: RWY 15: TRAVERSE WAY 94 FT FROM DER, 498 FT RIGHT OF
CENTERLINE, 533 FT MSL.
TREES, TRAVERSE WAY, BUILDINGS, POLES, ANTENNA BEGINNING 151 FT
FROM DER, 6 FT RIGHT OF CENTERLINE, UP TO 71 FT AGL/588 FT MSL.
TREE, BUILDING BEGINNING 546 FT FROM DER, 541 FT LEFT OF
CENTERLINE, UP TO 26 FT AGL/537 FT MSL.
TREE, POLES BEGINNING 671 FT FROM DER, 445 FT LEFT OF CENTERLINE,
UP TO 34 FT AGL/544 FT MSL.
POLES, TREE BEGINNING 761 FT FROM DER, 353 FT LEFT OF CENTERLINE,
UP TO 42 FT AGL/551 FT MSL.
TREES, POLE BEGINNING 850 FT FROM DER, 131 FT LEFT OF CENTERLINE,
UP TO 63 FT AGL/571 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2412201247-2412260000EST
END PART 1 OF 4
!FDC 4/9283 LOU PART 2 OF 4 ODP BOWMAN FLD, LOUISVILLE, KY.
TREES BEGINNING 888 FT FROM DER, 17 FT LEFT OF CENTERLINE, UP TO
107 FT AGL/607 FT MSL.
TREES BEGINNING 1599 FT FROM DER, 150 FT RIGHT OF CENTERLINE, UP TO
101 FT AGL/600 FT MSL.
NOTE: RWY 24: TANKS, FENCE BEGINNING 25 FT FROM DER, 378 FT LEFT OF
CENTERLINE, UP TO 16 FT AGL/554 FT MSL.
TREES BEGINNING 42 FT FROM DER, 443 FT RIGHT OF CENTERLINE, UP TO
53 FT AGL/592 FT MSL.
TREES BEGINNING 43 FT FROM DER, 372 FT LEFT OF CENTERLINE, UP TO 31
FT AGL/570 FT MSL.
TREES, FENCE, TRAVERSE WAY BEGINNING 72 FT FROM DER, 2 FT LEFT OF
CENTERLINE, UP TO 64 FT AGL/603 FT MSL.
TREES, FENCES, TRAVERSE WAYS BEGINNING 97 FT FROM DER, 10 FT RIGHT
OF CENTERLINE, UP TO 52 FT AGL/593 FT MSL.
TREES, BUILDING BEGINNING 289 FT FROM DER, 87 FT LEFT OF
CENTERLINE, UP TO 72 FT AGL/608 FT MSL.
TREES BEGINNING 290 FT FROM DER, 213 FT RIGHT OF CENTERLINE, UP TO
70 FT AGL/607 FT MSL.
TREES, BUILDINGS, POLES BEGINNING 302 FT FROM DER, 32 FT RIGHT OF
CENTERLINE, UP TO 615 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2412201247-2412260000EST
END PART 2 OF 4
!FDC 4/9283 LOU PART 3 OF 4 ODP BOWMAN FLD, LOUISVILLE, KY.
TREES, BUILDINGS, POLES BEGINNING 316 FT FROM DER, 26 FT LEFT OF
CENTERLINE, UP TO 78 FT AGL/613 FT MSL.
TREES BEGINNING 577 FT FROM DER, 18 FT RIGHT OF CENTERLINE, UP TO
89 FT AGL/616 FT MSL.
TREES, BUILDING BEGINNING 611 FT FROM DER, 4 FT LEFT OF CENTERLINE,
UP TO 95 FT AGL/636 FT MSL.
TREES, BUILDING, POLES BEGINNING 640 FT FROM DER, 5 FT LEFT OF
CENTERLINE, UP TO 103 FT AGL/645 FT MSL.
TREES BEGINNING 662 FT FROM DER, 32 FT RIGHT OF CENTERLINE, UP TO
95 FT AGL/622 FT MSL.
TREES, BUILDINGS, POLES BEGINNING 701 FT FROM DER, ON CENTERLINE,
UP TO 103 FT AGL/633 FT MSL.
TREES, BUILDINGS, POLES, ANTENNAS BEGINNING 831 FT FROM DER, 3 FT
RIGHT OF CENTERLINE, UP TO 107 FT AGL/645 FT MSL.
TREES, POLES, BUILDINGS BEGINNING 1159 FT FROM DER, 1 FT LEFT OF
CENTERLINE, UP TO 104 FT AGL/646 FT MSL.
TREES, POLE BEGINNING 1828 FT FROM DER, 7 FT RIGHT OF CENTERLINE,
UP TO 115 FT AGL/666 FT MSL.
TREES BEGINNING 2475 FT FROM DER, 24 FT LEFT OF CENTERLINE, UP TO
115 FT AGL/657 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2412201247-2412260000EST
END PART 3 OF 4
!FDC 4/9283 LOU PART 4 OF 4 ODP BOWMAN FLD, LOUISVILLE, KY.
TREES, BUILDING SPIRE BEGINNING 2617 FT FROM DER, 34 FT RIGHT OF
CENTERLINE, UP TO 113 FT AGL/668 FT MSL.
TOWER 4793 FT FROM DER, 1710 FT RIGHT OF CENTERLINE, 142 FT AGL/692
FT MSL.
NOTE: RWY 33: TREES, TRAVERSE WAYS, FENCE BEGINNING 23 FT FROM DER,
3 FT RIGHT OF CENTERLINE, UP TO 58 FT AGL/593 FT MSL.
TREES BEGINNING 99 FT FROM DER, 474 FT LEFT OF CENTERLINE, UP TO 51
FT AGL/583 FT MSL.
TREES, FENCE, TRAVERSE WAY BEGINNING 118 FT FROM DER, 3 FT LEFT OF
CENTERLINE, UP TO 53 FT AGL/585 FT MSL.
TREES, TRAVERSE WAYS BEGINNING 197 FT FROM DER, 213 FT RIGHT OF
CENTERLINE, UP TO 53 FT AGL/594 FT MSL.
TREES BEGINNING 419 FT FROM DER, 3 FT LEFT OF CENTERLINE, UP TO 131
FT AGL/669 FT MSL.
TREES BEGINNING 545 FT FROM DER, 23 FT RIGHT OF CENTERLINE, UP TO
106 FT AGL/646 FT MSL.
SMOKESTACK 1.4 NM FROM DER, 1422 FT RIGHT OF CENTERLINE, 222 FT
AGL/770 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2412201247-2412260000EST
END PART 4 OF 4
|
