KLPR
LORAIN COUNTY RGNL
PublicPUB

6 miles S of LORAIN/ELYRIA, OH
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
41° 20' 39"N 82° 10' 39"W
793' MSL
1793' MSL
08W
Jet A, 100LL
CLEVELAND (CLE)
DETROIT
CLEVELAND (ZOB)
5/16/24-6/13/24
KLPR VFR
11:53 PM EDT
Overcast 12,000'
10sm
59°F
55°F
29.96"Hg
050° 3kts
AO2 SLP144 T01500128
KLPR 290353Z AUTO 05003KT 10SM OVC120 15/13 A2996 RMK AO2 SLP144 T01500128
List Your Business

KLPR FBOs, Flight Schools and Ground Support

Promote Listing
MRK Aviation
Freq: 122.7
Phone: (440) 323-7000
No Rating Available
0 Reviews (Read | Sign In To Write)
Titan
As of 5/28
 100LL Jet A Jet A+ Mogas UL94
Self Serve
Full Serve 6.59 6.63 6.69

KLPR Ground Transportation (Taxi, Limo, Car Service)

No ground transportation services are listed for this airport.

KLPR Hotels

No hotels are listed for this airport.

KLPR Restaurants

No restaurants are listed for this airport.

KLPR Other Airport-Related Businesses

No other airport-related businesses are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.7 122.7

ASOS

ASOS
440-323-7088
 118.925

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

Departure Procedures

Hotspot

  • No Documents

Standard Term. Arrival

Instrument Approach

Terminal Area Forecast

KCLE (15nm)
Tue, 5/28 10:43 PM EDT
Tue, 5/28 11:00 PM EDT - Thu, 5/30 2:00 AM EDT
VFR
11:00 PM EDT - 5:00 AM EDT
Broken 10,000'
6sm
320° 5kts
VFR
5:00 AM EDT - 10:00 AM EDT
Showers in vicinity
Overcast 6,000'
Scattered 4,000'
6sm
050° 4kts
VFR
10:00 AM EDT - 5:00 PM EDT
Showers in vicinity
Broken 4,000'
6sm
350° 7kts
MVFR
Temporary 2:00 PM EDT - 4:00 PM EDT
Light Showers and Rain
Broken 3,000'
5sm
Calm
VFR
5:00 PM EDT - 8:00 PM EDT
Broken 5,000'
6sm
350° 13kts
Gusts 22kts
VFR
8:00 PM EDT - 2:00 AM EDT
Scattered 10,000'
6sm
360° 9kts
KCLE 290243Z 2903/3006 32005KT P6SM BKN100
   FM290900 05004KT P6SM VCSH SCT040 OVC060
   FM291400 35007KT P6SM VCSH BKN040
   TEMPO 2918/2920 5SM -SHRA BKN030
   FM292100 35013G22KT P6SM BKN050
   FM300000 36009KT P6SM SCT100
KLPR
Domestic
6/4/242101Z !LPR 05/012 LPR NAV ILS RWY 07 U/S 2406042101-2407022100
5/27/240000Z !LPR 05/011 LPR OBST TOWER LGT (ASR 1000898) 412522.00N0820824.00W (5.0NM NNE LPR) 939.0FT (262.1FT AGL) U/S 2405270000-2408240400
5/6/241100Z !LPR 05/003 LPR RWY 07/25 CLSD 2405061100-2406042200EST
5/6/241100Z !LPR 05/002 LPR RWY 07 ALS U/S 2405061100-2406042100
5/6/241100Z !LPR 05/001 LPR NAV ILS RWY 07 U/S 2405061100-2406042100
4/19/241722Z !LPR 04/013 LPR OBST TOWER LGT (ASR 1014122) 412534.00N0821533.00W (6.1NM NW LPR) 961.6FT (349.4FT AGL) U/S 2404191722-2406031721
2/9/241508Z !LPR 02/006 LPR RWY 25 RWY END ID LGT U/S 2402091508-2406151800EST
FDC
5/29/241100Z !FDC 4/9830 LPR IAP LORAIN COUNTY RGNL, LORAIN/ELYRIA, OH.
ILS OR LOC RWY 7, AMDT 7...
PROCEDURE NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
DJB VOR/DME OUT OF SERVICE. 2405291100-2406042119EST
No
APR-OCT 0700-2200
NOV-MAR 0700-2100
LORAIN CO BOARD OF COMMISSIONERS
44050 RUSSIA RD
ELYRIA, OH 44035
Phone: 440-329-5000
DOUG MCCONNELL C/O MRK AVIATION
44050 RUSSIA RD
ELYRIA, OH 44035
Phone: 440-323-7000
CLEVELAND FSS (CLE)
Toll Free: 1-800-WX-BRIEF
LPR
--
HIRL RWY 07/25 PRESET LOW INTST, TO INCR INTST & ACTVT MALSR RWY 07; REIL RWY 25 - CTAF.
N/A
Yes - Lighted
Yes
Yes
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
75
10
1
3
0
0
Major
Major
None
High & Low Pressure
Avionics
Cargo Handling
Charter Service
Pilot Instruction
Aircraft Rental
Aircraft Sales

Runway 07/25

5002 ft. x 100 ft.
ASPH
Fair
GRVD
HIGH

80,000lbs
110,000lbs
180,000lbs
--
  Runway 07 Runway 25
True Heading 65°245°
Traffic Pattern Left Right
Markings PIR NPI
Markings Condition FAIR FAIR
Latitude 41° 20' 29"N 41° 20' 50"N
Longitude 82° 11' 09"W 82° 10' 10"W
Elevation 793' 787'
Threshold Crossing Height 52 ft. AGL 40 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights MALSR
Centerline Lights No No
Runway End Identifier Lights No Yes
A110-1PILOTS OPERG IN OBERLIN AREA REQD TO AVOID & RMN WELL CLR OF OBERLIN COLLEGE DUE TO MUSIC CONSERVATORY; ALL TFC OPNS NORTH OF ARPT AS PER FAR PART 93 SUBPART J.
A110-3DEER, BIRDS & OTHER WILDLIFE ON & INVOF ARPT.
A110-4FOR CD CTC CLEVELAND APCH AT 216-352-2323.
LORAIN COUNTY RGNL (ICAO: KLPR, IATA: LPR) is a public airport located in LORAIN/ELYRIA, OH.
