2/14/232019Z
|
!FDC 3/6047 MEB PART 1 OF 3 ODP LAURINBURG/MAXTON, MAXTON, NC.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
TAKEOFF OBSTACLE NOTES: RWY 5, TREE 117 FT FROM DER, 492 FT RIGHT
OF CENTERLINE, 228 FT MSL.
TREE, TRAVERSE WAY BEGINNING 500 FT FROM DER, 3 FT RIGHT OF
CENTERLINE, UP TO 246 FT MSL.
TRAVERSE WAY BEGINNING 621 FT FROM DER, 5 FT LEFT OF CENTERLINE, UP
TO 216 FT MSL.
TREE 691 FT FROM DER, 601 FT RIGHT OF CENTERLINE, 254 FT MSL.
TREES BEGINNING 860 FT FROM DER, 494 FT RIGHT OF CENTERLINE, UP TO
256 FT MSL.
TREES BEGINNING 985 FT FROM DER, 481 FT RIGHT OF CENTERLINE, UP TO
260 FT MSL.
TREES BEGINNING 1133 FT FROM DER, 418 FT RIGHT OF CENTERLINE, UP TO
261 FT MSL.
TREES BEGINNING 1150 FT FROM DER, 755 FT LEFT OF CENTERLINE, UP TO
267 FT MSL.
TREE 1421 FT FROM DER, 571 FT RIGHT OF CENTERLINE, 265 FT MSL.
TREE 1553 FT FROM DER, 765 FT LEFT OF CENTERLINE, 269 FT MSL.
TREE 1753 FT FROM DER, 431 FT LEFT OF CENTERLINE, 274 FT MSL.
TREES BEGINNING 1761 FT FROM DER, 738 FT RIGHT OF CENTERLINE, UP TO
ALL OTHER DATA REMAINS AS PUBLISHED. 2302142019-2502142017EST
END PART 1 OF 3
!FDC 3/6047 MEB PART 2 OF 3 ODP LAURINBURG/MAXTON, MAXTON, NC.
270 FT MSL.
TREE 1767 FT FROM DER, 767 FT LEFT OF CENTERLINE, 282 FT MSL.
TREES BEGINNING 1770 FT FROM DER, 14 FT LEFT OF CENTERLINE, UP TO
294 FT MSL.
TREES BEGINNING 1918 FT FROM DER, 618 FT RIGHT OF CENTERLINE, UP TO
275 FT MSL.
TREE 2064 FT FROM DER, 536 FT RIGHT OF CENTERLINE, 281 FT MSL.
TREES BEGINNING 2116 FT FROM DER, 780 FT RIGHT OF CENTERLINE, UP TO
286 FT MSL.
TREES BEGINNING 2171 FT FROM DER, 13 FT RIGHT OF CENTERLINE, UP TO
287 FT MSL.
TREE 3026 FT FROM DER, 1187 FT RIGHT OF CENTERLINE, 288 FT MSL.
TREES BEGINNING 3186 FT FROM DER, 44 FT RIGHT OF CENTERLINE, UP TO
294 FT MSL.
TREE 3490 FT FROM DER, 258 FT LEFT OF CENTERLINE, 295 FT MSL.
RWY 13, TREE 78 FT FROM DER, 346 FT RIGHT OF CENTERLINE, 254 FT
MSL.
RWY 23, TREES BEGINNING 2533 FT FROM DER, 1082 FT LEFT OF
CENTERLINE, UP TO 300 FT MSL.
TREES BEGINNING 2773 FT FROM DER, 1128 FT LEFT OF CENTERLINE, UP TO
ALL OTHER DATA REMAINS AS PUBLISHED. 2302142019-2502142017EST
END PART 2 OF 3
!FDC 3/6047 MEB PART 3 OF 3 ODP LAURINBURG/MAXTON, MAXTON, NC.
301 FT MSL.
RWY 31, SIGN 22 FT FROM DER, 284 FT RIGHT OF CENTERLINE, 2 FT
AGL/217 FT MSL.
TREE 1565 FT FROM DER, 264 FT RIGHT OF CENTERLINE, 278 FT MSL.
TREE 1608 FT FROM DER, 575 FT LEFT OF CENTERLINE, 258 FT MSL.
TREES BEGINNING 1623 FT FROM DER, 210 FT RIGHT OF CENTERLINE, UP TO
281 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2302142019-2502142017EST
END PART 3 OF 3
|
