!FDC 3/8828 MKL PART 1 OF 5 ODP MC KELLAR-SIPES RGNL, JACKSON, TN.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1...
TAKEOFF OBSTACLE NOTES:
NOTE: RWY 2: TREE 455 FT FROM DER, 596 FT RIGHT OF CENTERLINE, 424
FT MSL.
TREE 708 FT FROM DER, 677 FT RIGHT OF CENTERLINE, 429 FT MSL.
TREE, POLE BEGINNING 782 FT FROM DER, 569 FT LEFT OF CENTERLINE, UP
TO 477 FT MSL.
TREE 880 FT FROM DER, 598 FT RIGHT OF CENTERLINE, 442 FT MSL.
TREE, POLE, TRANSMISSION LINE BEGINNING 898 FT FROM DER, 717 FT
RIGHT OF CENTERLINE, UP TO 456 FT MSL.
TREE 1204 FT FROM DER, 770 FT RIGHT OF CENTERLINE, 464 FT MSL.
TREES BEGINNING 1488 FT FROM DER, 589 FT RIGHT OF CENTERLINE, UP TO
473 FT MSL.
TREES BEGINNING 1513 FT FROM DER, 92 FT LEFT OF CENTERLINE, UP TO
494 FT MSL.
TREE, ANTENNA, TOWER BEGINNING 1635 FT FROM DER, 113 FT LEFT OF
CENTERLINE, UP TO 496 FT MSL.
TREE 1688 FT FROM DER, 825 FT RIGHT OF CENTERLINE, 478 FT MSL.
TREES BEGINNING 1751 FT FROM DER, 428 FT RIGHT OF CENTERLINE, UP TO
482 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2303162019-2503162018EST
END PART 1 OF 5
!FDC 3/8828 MKL PART 2 OF 5 ODP MC KELLAR-SIPES RGNL, JACKSON, TN.
TREES BEGINNING 2413 FT FROM DER, 412 FT LEFT OF CENTERLINE, UP TO
104 FT AGL/506 FT MSL.
NOTE: RWY 11: POLE 133 FT FROM DER, 524 FT RIGHT OF CENTERLINE, 433
FT MSL.
TREES BEGINNING 731 FT FROM DER, 151 FT LEFT OF CENTERLINE, UP TO
468 FT MSL.
TREE 1763 FT FROM DER, 313 FT RIGHT OF CENTERLINE, 73 FT AGL/463 FT
MSL.
TREE 1783 FT FROM DER, 309 FT RIGHT OF CENTERLINE, 80 FT AGL/469 FT
MSL.
TREES BEGINNING 1795 FT FROM DER, 204 FT RIGHT OF CENTERLINE, UP TO
484 FT MSL.
TREES BEGINNING 1902 FT FROM DER, 669 FT RIGHT OF CENTERLINE, UP TO
488 FT MSL.
NOTE: RWY 20: LIGHT POLES 2 FT FROM DER, 5 FT RIGHT OF CENTERLINE,
2 FT AGL/436 FT MSL.
TREES BEGINNING 456 FT FROM DER, 554 FT RIGHT OF CENTERLINE, UP TO
465 FT MSL.
TREE 503 FT FROM DER, 562 FT LEFT OF CENTERLINE, 459 FT MSL.
TREE 834 FT FROM DER, 603 FT LEFT OF CENTERLINE, 481 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2303162019-2503162018EST
END PART 2 OF 5
!FDC 3/8828 MKL PART 3 OF 5 ODP MC KELLAR-SIPES RGNL, JACKSON, TN.
TREES BEGINNING 1292 FT FROM DER, 597 FT RIGHT OF CENTERLINE, UP TO
497 FT MSL.
TREE 2065 FT FROM DER, 1038 FT LEFT OF CENTERLINE, 486 FT MSL.
TREES BEGINNING 2193 FT FROM DER, 1004 FT LEFT OF CENTERLINE, UP TO
515 FT MSL.
TREE 2276 FT FROM DER, 688 FT RIGHT OF CENTERLINE, 504 FT MSL.
TREES BEGINNING 2291 FT FROM DER, 853 FT RIGHT OF CENTERLINE, UP TO
513 FT MSL.
TREE 2383 FT FROM DER, 990 FT RIGHT OF CENTERLINE, 519 FT MSL.
TREE, POLE BEGINNING 2417 FT FROM DER, 9 FT RIGHT OF CENTERLINE, UP
TO 532 FT MSL.
TREE 2934 FT FROM DER, 1251 FT LEFT OF CENTERLINE, 518 FT MSL.
TREES BEGINNING 2972 FT FROM DER, 837 FT LEFT OF CENTERLINE, UP TO
525 FT MSL.
TREES BEGINNING 3126 FT FROM DER, 937 FT LEFT OF CENTERLINE, UP TO
526 FT MSL.
TREES BEGINNING 3203 FT FROM DER, 1 FT LEFT OF CENTERLINE, UP TO
542 FT MSL.
TREES BEGINNING 3429 FT FROM DER, 20 FT RIGHT OF CENTERLINE, UP TO
539 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2303162019-2503162018EST
END PART 3 OF 5
!FDC 3/8828 MKL PART 4 OF 5 ODP MC KELLAR-SIPES RGNL, JACKSON, TN.
TREES BEGINNING 3439 FT FROM DER, 9 FT LEFT OF CENTERLINE, UP TO 98
FT AGL/543 FT MSL.
TREES BEGINNING 3470 FT FROM DER, 3 FT RIGHT OF CENTERLINE, UP TO
543 FT MSL.
TREES BEGINNING 3554 FT FROM DER, 756 FT RIGHT OF CENTERLINE, UP TO
549 FT MSL.
TREES BEGINNING 3662 FT FROM DER, 3 FT RIGHT OF CENTERLINE, UP TO
555 FT MSL.
TREES BEGINNING 3697 FT FROM DER, 6 FT LEFT OF CENTERLINE, UP TO
107 FT AGL/544 FT MSL.
NOTE: RWY 29: POLE, BUILDING, TREE, TRAVERSE WAY BEGINNING 40 FT
FROM DER, 93 FT LEFT OF CENTERLINE, UP TO 39 FT AGL/449 FT MSL.
FENCE 76 FT FROM DER, 497 FT RIGHT OF CENTERLINE, 412 FT MSL.
FENCE 186 FT FROM DER, 498 FT RIGHT OF CENTERLINE, 414 FT MSL.
BUILDING 284 FT FROM DER, 567 FT RIGHT OF CENTERLINE, 421 FT MSL.
BUILDING 523 FT FROM DER, 512 FT RIGHT OF CENTERLINE, 423 FT MSL.
POLE, TRAVERSE WAY BEGINNING 530 FT FROM DER, 82 FT RIGHT OF
CENTERLINE, UP TO 442 FT MSL.
TREE 1034 FT FROM DER, 512 FT RIGHT OF CENTERLINE, 485 FT MSL.
TREES BEGINNING 1063 FT FROM DER, 432 FT RIGHT OF CENTERLINE, UP TO
ALL OTHER DATA REMAINS AS PUBLISHED. 2303162019-2503162018EST
END PART 4 OF 5
!FDC 3/8828 MKL PART 5 OF 5 ODP MC KELLAR-SIPES RGNL, JACKSON, TN.
491 FT MSL.
POLE BEGINNING 1204 FT FROM DER, 506 FT LEFT OF CENTERLINE, UP TO
460 FT MSL.
TREES BEGINNING 1207 FT FROM DER, 464 FT RIGHT OF CENTERLINE, UP TO
88 FT AGL/500 FT MSL.
POLE BEGINNING 1311 FT FROM DER, 85 FT LEFT OF CENTERLINE, UP TO
461 FT MSL.
TREE, POLE BEGINNING 1342 FT FROM DER, 45 FT RIGHT OF CENTERLINE,
UP TO 88 FT AGL/502 FT MSL.
POLE 3913 FT FROM DER, 283 FT RIGHT OF CENTERLINE, 106 FT AGL/508
FT MSL.
POLE 3977 FT FROM DER, 1221 FT RIGHT OF CENTERLINE, 107 FT AGL/512
FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2303162019-2503162018EST
