2/16/240928Z
|
!FDC 4/6154 MNI PART 1 OF 4 ODP SANTEE COOPER RGNL, MANNING, SC.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
TAKEOFF OBSTACLE NOTES: RWY 2, TREE 5 FT FROM DER, 334 FT LEFT OF
CENTERLINE, 58 FT AGL/152 FT MSL.
TREES BEGINNING 16 FT FROM DER, 310 FT LEFT OF CENTERLINE, UP TO 67
FT AGL/161 FT MSL.
POLE 131 FT FROM DER, 417 FT RIGHT OF CENTERLINE, 35 FT AGL/138 FT
MSL.
TREES, POLES, BUILDINGS BEGINNING 342 FT FROM DER, 310 FT RIGHT OF
CENTERLINE, UP TO 52 FT AGL/159 FT MSL.
TREE 471 FT FROM DER, 435 FT LEFT OF CENTERLINE, 70 FT AGL/175 FT
MSL.
TREE 659 FT FROM DER, 565 FT LEFT OF CENTERLINE, 83 FT AGL/176 FT
MSL.
TREES, POLES, CATENARY WIRE BEGINNING 670 FT FROM DER, 10 FT LEFT
OF CENTERLINE, UP TO 4 FT AGL/180 FT MSL.
TREES, POLES, CATENARY WIRE BEGINNING 731 FT FROM DER, 296 FT RIGHT
OF CENTERLINE, UP TO 74 FT AGL/173 FT MSL.
TREE, POLE BEGINNING 975 FT FROM DER, 261 FT RIGHT OF CENTERLINE,
UP TO 80 FT AGL/180 FT MSL.
TREE 1011 FT FROM DER, 482 FT RIGHT OF CENTERLINE, 83 FT AGL/182 FT
2402160928-2602160928EST
END PART 1 OF 4
!FDC 4/6154 MNI PART 2 OF 4 ODP SANTEE COOPER RGNL, MANNING, SC.
MSL.
TREES BEGINNING 1016 FT FROM DER, 321 FT RIGHT OF CENTERLINE, UP TO
86 FT AGL/185 FT MSL.
TREES BEGINNING 1196 FT FROM DER, 296 FT RIGHT OF CENTERLINE, UP TO
88 FT AGL/187 FT MSL.
TREES BEGINNING 1944 FT FROM DER, 411 FT RIGHT OF CENTERLINE, UP TO
89 FT AGL/195 FT MSL.
TREES BEGINNING 1980 FT FROM DER, 4 FT LEFT OF CENTERLINE, UP TO 91
FT AGL/197 FT MSL.
TREES BEGINNING 2079 FT FROM DER, 97 FT RIGHT OF CENTERLINE, UP TO
96 FT AGL/200 FT MSL.
TREES BEGINNING 3052 FT FROM DER, 145 FT RIGHT OF CENTERLINE, UP TO
93 FT AGL/202 FT MSL.
TREE 3177 FT FROM DER, 692 FT RIGHT OF CENTERLINE, 95 FT AGL/205 FT
MSL.
TREES BEGINNING 3328 FT FROM DER, 628 FT RIGHT OF CENTERLINE, UP TO
106 FT AGL/216 FT MSL.
TREE 3617 FT FROM DER, 20 FT LEFT OF CENTERLINE, 89 FT AGL/200 FT
MSL.
TREE 3873 FT FROM DER, 637 FT LEFT OF CENTERLINE, 90 FT AGL/203 FT
2402160928-2602160928EST
END PART 2 OF 4
!FDC 4/6154 MNI PART 3 OF 4 ODP SANTEE COOPER RGNL, MANNING, SC.
MSL.
TREE 4389 FT FROM DER, 911 FT LEFT OF CENTERLINE, 96 FT AGL/216 FT
MSL.
TREE 4637 FT FROM DER, 1679 FT RIGHT OF CENTERLINE, 89 FT AGL/220
FT MSL.
TREE 4746 FT FROM DER, 1081 FT LEFT OF CENTERLINE, 92 FT AGL/222 FT
MSL.
RWY 20, TERRAIN 10 FT FROM DER, 100 FT RIGHT OF CENTERLINE, 3 FT
AGL/95 FT MSL.
TERRAIN 19 FT FROM DER, 11 FT LEFT OF CENTERLINE, 2 FT AGL/96 FT
MSL.
POLE 62 FT FROM DER, 397 FT RIGHT OF CENTERLINE, 19 FT AGL/103 FT
MSL.
TREES, POLES, TANKS BEGINNING 92 FT FROM DER, 129 FT LEFT OF
CENTERLINE, UP TO 88 FT AGL/176 FT MSL.
TREE 125 FT FROM DER, 412 FT RIGHT OF CENTERLINE, 67 FT AGL/147 FT
MSL.
TREES BEGINNING 129 FT FROM DER, 299 FT RIGHT OF CENTERLINE, UP TO
76 FT AGL/161 FT MSL.
TREES BEGINNING 958 FT FROM DER, 393 FT RIGHT OF CENTERLINE, UP TO
2402160928-2602160928EST
END PART 3 OF 4
!FDC 4/6154 MNI PART 4 OF 4 ODP SANTEE COOPER RGNL, MANNING, SC.
73 FT AGL/163 FT MSL.
TREES BEGINNING 1530 FT FROM DER, 717 FT RIGHT OF CENTERLINE, UP TO
73 FT AGL/164 FT MSL.
TREES BEGINNING 1616 FT FROM DER, 287 FT LEFT OF CENTERLINE, UP TO
96 FT AGL/181 FT MSL.
TREES BEGINNING 1708 FT FROM DER, 160 FT RIGHT OF CENTERLINE, UP TO
81 FT AGL/167 FT MSL. ALL OTHER DATA REMAINS AS PUBLISHED.
2402160928-2602160928EST
END PART 4 OF 4
|
