5/23/231632Z
|
!FDC 3/0753 OPL PART 1 OF 3 ODP ST LANDRY PARISH-AHART FLD,
OPELOUSAS, LA.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1...
NOTE: RWY 6: TREE, BUILDING, TRAVERSE WAY, POLE BEGINNING 75 FT
FROM DER, 1 FT LEFT OF CENTERLINE, UP TO 78 FT AGL/151 FT MSL.
TREES BEGINNING 576 FT FROM DER, 0 FT OF CENTERLINE, UP TO 34 FT
AGL/106 FT MSL. TREE 676 FT FROM DER, 82 FT RIGHT OF CENTERLINE, 35
FT AGL/107 FT MSL. TREES BEGINNING 704 FT FROM DER, 103 FT RIGHT OF
CENTERLINE, UP TO 45 FT AGL/117 FT MSL
TREES BEGINNING 805 FT FROM DER, 192 FT RIGHT OF CENTERLINE, UP TO
126 FT MSL. TREES BEGINNING 858 FT FROM DER, 100 FT RIGHT OF
CENTERLINE, UP TO 58 FT AGL/130 FT MSL. TREES BEGINNING 924 FT FROM
DER, 39 FT RIGHT OF CENTERLINE, UP TO 61 FT AGL/133 FT MSL. TREES
BEGINNING 935 FT FROM DER, 44 FT RIGHT OF CENTERLINE, UP TO 61 FT
AGL/134 FT MSL. TREES BEGINNING 945 FT FROM DER, 0 FT OF
CENTERLINE, UP TO 64 FT AGL/136 FT MSL. TREE, POLE BEGINNING 1170
FT FROM DER, 3 FT RIGHT OF CENTERLINE, UP TO 64 FT AGL/137 FT MSL.
TREE, POLE BEGINNING 1175 FT FROM DER, 15 FT LEFT OF CENTERLINE, UP
TO 79 FT AGL/152 FT MSL. TREE 1359 FT FROM DER, 365 FT RIGHT OF
CENTERLINE, 143 FT MSL. TREE, POLE BEGINNING 1360 FT FROM DER, 14
FT RIGHT OF CENTERLINE, UP TO 166 FT MSL.
TREES BEGINNING 3024 FT FROM DER, 457 FT LEFT OF CENTERLINE, UP TO
ALL OTHER DATA REMAINS AS PUBLISHED. 2305231632-2505231632EST
END PART 1 OF 3
!FDC 3/0753 OPL PART 2 OF 3 ODP ST LANDRY PARISH-AHART FLD,
OPELOUSAS, LA.
156 FT MSL. TREE 3151 FT FROM DER, 769 FT LEFT OF CENTERLINE, 158
FT MSL.
NOTE: RWY 18: TREE, TRAVERSE WAY BEGINNING 220 FT FROM DER, 20 FT
LEFT OF CENTERLINE, UP TO 107 FT MSL.
TREES BEGINNING 366 FT FROM DER, 184 FT LEFT OF CENTERLINE, UP TO
108 FT MSL. TREE 425 FT FROM DER, 417 FT LEFT OF CENTERLINE, 111 FT
MSL. TREE 751 FT FROM DER, 380 FT LEFT OF CENTERLINE, 117 FT MSL.
TREES BEGINNING 809 FT FROM DER, 434 FT LEFT OF CENTERLINE, UP TO
118 FT MSL. TREE 875 FT FROM DER, 577 FT LEFT OF CENTERLINE, 124 FT
MSL. TREES BEGINNING 924 FT FROM DER, 24 FT LEFT OF CENTERLINE, UP
TO 136 FT MSL. TREES BEGINNING 1059 FT FROM DER, 1 FT LEFT OF
CENTERLINE, UP TO 142 FT MSL. TREES BEGINNING 1717 FT FROM DER, 569
FT LEFT OF CENTERLINE, UP TO 143 FT MSL. TREES BEGINNING 1738 FT
FROM DER, 497 FT LEFT OF CENTERLINE, UP TO 161 FT MSL. TREES
BEGINNING 1791 FT FROM DER, 394 FT RIGHT OF CENTERLINE, UP TO 152
FT MSL. TREE, POLE BEGINNING 1796 FT FROM DER, 5 FT LEFT OF
CENTERLINE, UP TO 168 FT MSL. TREES BEGINNING 1938 FT FROM DER, 174
FT RIGHT OF CENTERLINE, UP TO 154 FT MSL. TREES BEGINNING 2053 FT
FROM DER, 16 FT RIGHT OF CENTERLINE, UP TO 158 FT MSL. TREES
BEGINNING 2139 FT FROM DER, 11 FT RIGHT OF CENTERLINE, UP TO 162 FT
ALL OTHER DATA REMAINS AS PUBLISHED. 2305231632-2505231632EST
END PART 2 OF 3
!FDC 3/0753 OPL PART 3 OF 3 ODP ST LANDRY PARISH-AHART FLD,
OPELOUSAS, LA.
MSL. TREE, POLE BEGINNING 3190 FT FROM DER, 103 FT LEFT OF
CENTERLINE, UP TO 179 FT MSL. TRANSMISSION LINE 3523 FT FROM DER,
1153 FT RIGHT OF CENTERLINE, 98 FT AGL/169 FT MSL. TREE 4096 FT
FROM DER, 590 FT RIGHT OF CENTERLINE, 110 FT AGL/181 FT MSL. TREE
4180 FT FROM DER, 592 FT RIGHT OF CENTERLINE, 112 FT AGL/183 FT
MSL. TOWER 6046 FT FROM DER, 896 FT LEFT OF CENTERLINE, 207 FT
AGL/269 FT MSL.
NOTE: RWY 24: TREES BEGINNING 43 FT FROM DER, 264 FT RIGHT OF
CENTERLINE, UP TO 134 FT MSL. TREE 92 FT FROM DER, 507 FT LEFT OF
CENTERLINE, 137 FT MSL. TREE, TRAVERSE WAY, POLE, BUILDING
BEGINNING 132 FT FROM DER, 14 FT RIGHT OF CENTERLINE, UP TO 138 FT
MSL. TREE, POLE BEGINNING 140 FT FROM DER, 74 FT LEFT OF
CENTERLINE, UP TO 73 FT AGL/141 FT MSL. TREE, POLE, TRANSMISSION
LINE BEGINNING 638 FT FROM DER, 5 FT LEFT OF CENTERLINE, UP TO 84
FT AGL/153 FT MSL. TREES BEGINNING 767 FT FROM DER, 113 FT RIGHT OF
CENTERLINE, UP TO 73 FT AGL/139 FT MSL. TREE, POLE, ANTENNA,
BUILDING BEGINNING 855 FT FROM DER, 16 FT RIGHT OF CENTERLINE, UP
TO 82 FT AGL/147 FT MSL.
NOTE: RWY 36: TREE, POLE BEGINNING 829 FT FROM DER, 16 FT RIGHT OF
CENTERLINE, UP TO 159 FT MSL..
ALL OTHER DATA REMAINS AS PUBLISHED. 2305231632-2505231632EST
END PART 3 OF 3
|
